1mp wifi outdoor water proof security easy eye wifi compact wi fi kamera camera with wifi and gps

FOB Reference Price:Get Latest Price
$13.86 - $25.20 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Maglens
Model Number:
SEIPC2401
Type:
IP Camera
Style:
Dome Camera
Sensor:
CMOS
Special Features:
Waterproof / Weatherproof
IR range:
20M
Solution:
Hi3518E+OV9712S ; Hi3518C+AR0130 ; Hi3516C+ IMX222
Resolution:
1.0MP ; 1.3MP ; 2.0MP
Video compression:
H.264
Ingress protection:
IP66
ICR Switch:
Auto/Manual
Memory storage:
32GB SD card
User Interface:
WEB, CMS, NVR
Signal Noise Ratio:
>50dB
Day/Night Mode:
Auto, dual IR-Cut filter
Technology:
Infrared
Supply Ability
Supply Ability:
30000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Neutral Packing or customized packing
Port
Shenzhen
Lead Time :
Shipped in 7 days after payment
Product Description

Wireless home security led light cctv online with wide IR range wifi security camera,ip camera OEM/ODM

Main Characteristics:
24PCS LED lights
IR range: 20M
Intelligent analysis for 1.3MP
Corridor mode for 2.0MP
Board Lens 3.6mm /F2.0
Case:Aluminum / IP66,IK10
Internal POE
Optional 2.8mm-12mm varifocal lens

Solution:Hi3518E+OV9712S ; Hi3518C+AR0130 ; Hi3516C+ IMX222
Resolution:1.0MP ; 1.3MP ; 2.0MP
Carton Dimension:658*330*335mm 20pcs/ctn

Type:Digital Camera
Style:Dome camera
Sensor:CMOS
Video compression: H.264
IR distance: 20m
Ingress protection: IP66
Special features: Waterproof
Lens: 2.8mm~12mm/F1.4Manual lens
ICR Switch: Auto/Manual
Memory storage: 32GB SD card

> 1/3” 2.0 Megapixel Progressive Sony Exmor CMOS sensor
> Ti DaVinci Series DSP
> H.264 & MJPEG dual-stream encoding
> Max 1~25/30fps @ 1080P/720P
> Dual encoding streams supported
> 2.8~12mm /F1.4 Manual lens
> Built-in 1/1 alarm in/out
> Max IR Distance :20m
> True Day/Night ICR
> Micro SD memory, IK10, PoE
> Built-in Web server, NVR, CMS

Technical Specifications
Main Processor:DaVinci High Performance DSP of TI

Operating System :Embedded LINUX

Resource:Simultaneous remote monitoring, local recording and remote control

User Interface :WEB, CMS, NVR

Camera
Image Sensor:1/3" 2.0Megapixel Progressive Scan Sony CMOS Sensor

Effective Pixels:1920(H)*1080(V)

Electronic Shutter:1/5s to 1/50,000s

Mini. Illumination:Color:0.2Lux/F1.2 ;B/W:0.01Lux/F1.2;0Lux/F1.2(IR on)

Signal Noise Ratio : >50dB

Day/Night Mode:Auto, dual IR-Cut filter

Gain Control:Auto/Manual

White Balance:Auto/Manual

WDR Dynamic Range:DWDR

Lens:2.8mm~12mm/F1.4Manual lens

Max IR Distance:20m

Video

Video Compression:H.264/MJPEG Optional

H.264 Encode Type :H.264 Baseline/H.264 Main Profile/H.264 High Profile Optional

Video Bit Rate:
Main Stream:500Kbps~12Mbps
Sub Stream:100Kbps~6Mbps

Image Resolution:
1080P(1920×1020) / 720P(1280×720) / D1(704×576/704×480)

Encoding Speed:
Main Stream:1080P/720P(1~25fps/30fps)
Extra Stream:D1/CIF:(1~25fps/30fps)

Video Format:PAL/NTSC

Audio
Audio Compression:N/A
G.711a/G.711u/RAW_PCM Optional

Audio Bit Rate :N/A
G.711a(8kbps)/G.711u(8kbps)/RAW_PCM(16kbps)

Audio Input:N/A
1-channel 3.5mm audio interface MIC IN/Line IN

Audio Output:N/A
1-channel 3.5mm audio interface (line level,600Ω)

Network

Ethernet:RJ-45 (10/100Base-T)

Network Protocol:
IPv4/IPv6,RTSP/RTP/RTCP,TCP/UDP,HTTP,DHCP,DNS,FTP,DDNS,PPPoE,SMTP

ONVIF:
0NVIF Ver.2.3

Max User Access:10 users

Remote Operation:
Monitor, Playback, System setting, File download, Log information, Maintenance & Upgrade

Auxiliary Interface

Reset Input:
One Reset Button(Be effective after continues to hold down for 3 seconds)

Memory Slot:N/A ;TF Card, Max 32GB

RS485 PTZ Control

Alarm Input:N/A
1-channel input, Normally Open/Normally Close modes adjustable

Alarm Output:N/A
1-channel output,, 120VAC 1A/24VDC 1A

Video Output:N/A
1Vp-p Composite Output(75Ω/BNC)

Environmental

Power Supply:DC12V

Power Consumption:<10W

Operating Environment:-40ºC ~ +60ºC, Humidity less than95%(Non-condensing)

Max IR Distance:20m

IP Grade:IP66 only with External metal bracket

PoE:N/A
IEEE802.3af
N/A
IEEE802.3af
