2019 Hot Sale Model Industrial Resataurant Dish Washing Machine/China Dishwasher BN-XW03

FOB Reference Price:Get Latest Price
$2,000.00 - $4,000.00 / Set | 5 Set/Sets (Min. Order)
Lead Time:
Quantity(Sets) 1 - 10 >10
Est. Time(days) 25 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
CosBao
Model Number:
BN-XW03
Type:
Freestanding
Style:
Drawer Dish Washer
Certification:
CE, RoHS
Control Type:
Full-Integrated
Housing Material:
Stainless Steel
Inner Material:
Stainless Steel
Power (W):
13000
Voltage (V):
380
Product name:
China dishwasher
Washing capacity:
120 basket/hour
high temperature tank capacity:
20L
washing tank capacity:
45L
high temperature tank power:
18KW
washing tank power:
3KW
Total power:
21.75KW
Volts:
380V
Size:
730x690x1450mm
Supply Ability
Supply Ability:
50 Set/Sets per Week
Packaging & Delivery
Packaging Details
Export Carton + Crate (Dish washer machine)
Port
Guangzhou port, China
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 10 >10
Est. Time(days) 25 To be negotiated



 2019 Hot Sale Model Industrial Resataurant Dish Washing Machine/China Dishwasher  BN-XW03


4 advantages:
Install conveniently, time saving .
Save human resource, shorten the time.
Easy operating, do no harm to the dish.
Perfect cleaning ability.



Specification of China Dishwasher:

Unit size

730×690×1450mm

Washing basket size

500×500 mm

Washing capacity

120 basket/hour

Washing pump power

3KW

Power

380V 150HZ 13P

Inlet height

450 mm

Water consumption

120 basket/hour

Washing tank power

3KW

High temperature tank power

18 KW

Machine total: power

21.75KW

Washing temperature: 60-70 degree

Rinsing temperature: 80-92 degree



Advantage of China dishwasher:

(1) The machine is consisted of frame, up and down hood, washing and rinsing, control panel, and stainless steel water pump and electricity control systems.

(2) The water pump draws the water from the water channel to the up and down water spraying box for strong spraying and washing, then the high temperature water from the water tank is supplied to the spraying pipe for rinsing.

(3) Working table is available, you can use it together or not.

(4) To get the good washing result, you should not press the washing button until the water washing temperature up to the reset range. One washing period is 60 seconds---washing pump spraying for 40 seconds, delay for 5 seconds and rinsing for 15 seconds.

(5) The whole period is controlled automatically.



Installation and connection requirements:

Power requirements:380v/50hz/3ph+Neutral+Ground,with an external separate air circuit breaker.

Machine can be directly connected with water supply system,the lowest incoming water pressure should be 2kg/cm2

If a hood or vent needed,the minimum capacity should be 2.8m3/min.



Using note:

1. Turn on the water switch, check the water pipe, percolation net, then open the door of the machine.

2. Turn on the power and the power light will turn green.

3. Press down the watering button on the control table, temperature light will turn red, machine start working.

4. Dishwasher will start heating automatically after affusion finished.

5. Dishwasher will stop heating automatically once the temperature come up to the prearranged point.

6. All scour will be injected into the washing machine automatically after set up the distributor.

7. Do not put your hand into the washing bucket, put the cup and glass ware into the basket, all trays must be leaned onto the washing dishes and face up, silver dishes face down.

2019 Hot Sale Model Industrial Resataurant Dish Washing Machine/China Dishwasher


Company Information:

 Cosbao provides a varitey of kitchen equipments such as kitchen cabinet, sink bench, worktable, bain marie,service trolley, combination oven, warming showcase, barbecue oven, pasta cooker, griddle, fryer etc since 1998. Products exported to all over the world expecially the USA, Europe, Australia, Korea, and so on.

 OEM or ODM are welcomed.Trail orders are welcomed.

0102

Show Room:

Factory Showroom 2

Packing And Shipping

0102

Trade Shows

010203

Certifications

Certificates  2019 Hot Sale Model Industrial Resataurant Dish Washing Machine/China Dishwasher

FAQ

FAQ Time

1. Q: Are you a factory or trading company?
A: We are a factory. Heavy Duty Storage Rack for Industrial Warehouse Storage is one of our featured products.

2. Q: Where is your factory located? How can I visit there?
A: Our factory is located inFoshan City, Guangdong Province, China. You can fly to Guangzhou airport directly.

You are warmly welcome to visit us whenever you are available!



3. Q: What is the raw material of your products?

A: As general, the raw material of steel is 201#,430#,304#. Other steel is also available to clients’ requirements.



4. Q: What is the term of payment?

A: As general, 30% T/T down payment and balance before shipping.



5. Q: What is the delivery time?

A: It depends on the order quantity and racking types. General speaking, within 15-25 days, for ordinary order quantity of heavy duty storage rack of industrial warehouse storage



6. Q: Which port will be used as loading port?

A: Guangzhou port, the closest port to us, is recommended strongly as loading port. Shenzhen port is also available.



7. Q: May I know the status of my order?

A: Yes. We will send you information and photos at different production stage of your order. You will get the latest information in time.



Contact Information:



Ms Tely



Wechat/WhatsApp/Mobile:0086 13822795883



Skype:tely0826



QQ:2415906884



Email:tely@bnkitchen(dot)com



Website:www.bnkitchen.com
