2019 New Arrival Portable Pda Barcode Scanner Android Handheld PDA Handheld Terminal Data Collector 4G LTE GPS Bluetooth

  • 5-999 Sets
    $220.50
    $225.00
  • >=1000 Sets
    $194.04
    $198.00
2% OFF Discount ends in : : :
Color:
Black
$220.50
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Samples: $325.00 /Set, 1 Set (Min. Order): Buy Samples
Contact Supplier
Samples - $325.00 /Set, 1 Set (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
XYX
Model Number:
X80
Style:
Smartphone
Screen Size:
3.5"
Weight:
0.5kg
Memory Capacity:
2G
Processor Type:
OMAP
Operating System:
Android
Products Status:
Stock
Barcode scanner:
1D/2D Barcode Scanner Optional
Camera:
800W Pixels
Product name:
PDA Handheld Barcode Scanner
Battery:
3.7V
Communication:
2G/3G/4G/WIFI/BLUETOOTH
GPS:
Support A-GPS
Color:
Black
WIFI:
IEEE 802.11b/g/n
ROM:
16GB/32GB
Bluetooth:
Bluetooth V4.0+EDR

Packaging & Delivery

Selling Units:
Single item
Single package size:
20X15X3 cm
Single gross weight:
0.5 kg
Package Type:
Retail Box+Export Carton New Arrival portable pda barcode scanner android handheld PDA handheld terminal data collector 4G LTE GPS bluetooth
Lead Time :
Quantity(Sets) 1 - 100000 >100000
Est. Time(days) 5 To be negotiated
Video Description

We are PDA manufacturer for 10years experience with advantage of free SDK provided, professional technical team support and CE Rohs certificate.
New Arrival portable pda barcode scanner android handheld PDA handheld terminal data collector 4G LTE GPS bluetooth
Our product is the best choice of hand-held terminal for enterprise users to collect data due to its classic Android APPs and aggressive
performance, which is usually applied in the fields including government & public affairs, financial management, ticket business,
traceability, medicare, logistics, retailing stores and supermarkets, O2O e-commerce payment, etc.


Product Description



Structural Parameter
Dimensions166mm(L)X77.5mm(W)X22mm(D)
Weight<500g
Display Screen4.5inch IPS 480*854 px with Multi-point touch capactive screen
Expand PortSIM card, micro SD (TF) Card
Communication Interface

Type-C USB

Input ModeStandard Stylus, Handwriting, touching input or keyboard input
Battery CapacityRechargeable Li-polymer Battery 3.7V 4200mAh
Frequency8ohm 1W speaker
KeySilicone keyboard
Performance Parameter
OSAndroid 7.0
CPUARM CORTEX-A53 64bit Quad-Core 1.3G
RAM1G/2G RAM
Flash ROMStandard 8G/16G NAND Flash Storage
micro SD/TF port (Max up to 32G)
Data Communication
WI-FISupport IEEE802.11 a/b/G/n protocol, it need effective wireless LAN signal cover
FDD/TDD-LTE 4GTDD-LTE (B38,B39,B40,B41),FDD-LTE (B1,B3)
WCDMA 3GB1,B2,B5,B7,B8
GSM 2GGSM/edge/GPRS (850,900,1800,1900MHz)
btSupport bt 2.0+EDR/3.0+HS/4.1+HS, transmission distance is 5-10m
Standard Modules
Camera8MP autofocus camera with flash
GPSSupport A-GPS
Operating Environment
Operating-20°C to 55°C
Storage Temperature-25°C to 70°C
Environment Humidity5%RH-95%RH(no condensation)
Drop Specifications6 sides can bear impact from 1.5m drop to cement floor in the range of operating temperature
Roll Specifications1000 times/0.5m, roll on 6 sides contact area
Sealed EnvironmentIP66
1D Laser Scanner (OPTIONAL)
1D Laser ScannerSymbol 955, HoneywellN4313,Mingde966
Resolution4Mil minimum width
Ambient Light10000ft.candles(107640 lux)
Scanning Speed104(±)12/sec (bothway)
Scanning Angle47o±35o(Standard) / 35o±3o(narrow angle)
Support Bar Code TypeUPC/EAN, Code128, Code39, Code93,Code11, Interleaved 2 of 5, Discrete 2 of 5,Chinese 2 of 5, Codabar, MSI, RSS
2D CMOS (OPTIONAL)
CMOS ScannerHoneywell N6603,NewLand 3096
The Sensor Resolution752(level)×480(vertical)pels(gray level)
Ambient LightAll dark 9000ft.candles/96900 lux
focus element (VLD)655nm ± 10nm
Support bar code typePDF417,MicroPDF417,Composite, RSS,TLC-39, Datamatrix, QR code, micro QR code,Aztec, MaxiCode; Postal Codes: US PostNet,US Planet, UK Postal, Australian Postal, JapanPostal Dutch Postal (KIX)3
LF RFID Reader (Optional)
Frequency125kHz, 134kHz (FDX-B / HDX)
ProtocolISO11784/5, ISO18000-2
Range3-8cm
NFC Reader (Optional)
Frequency13.56MHz
ProtocolISO/IEC 18092 (ECMA 340)
Range2-4cm

High-speed operation performance:
With androd 7.0 operating system, matching 64 bit quad core 1.3GHz high speed processor with prefect compatibility and computing capability, high-speed operating efficiency is suitable for strict application requirement.
Excellent identification ability :
Fully support 1D and 2D barcode scanning,NFC(optional).
Convenient appearance design:
Slim and ergonomics design, it is convenient and comfortable for holding and carrying. 5.0 inch IPS (720x1280) Work even with water or Gloves.
Abundant means of data transportation(option)
2G,3G,4G,Wifi,Bluetooth,etc.
Industrial grade durability:
IP66 industrial grade, solid and light body can bear the height of 1.2m dropping and 1000 times tumbled within the scope of 0.5m. Waterproof,dustproof provide long time using without fatiguet.
HD Camera:
Postposition 8 mega pixel autofocus camera, is convenient for client to collect all kind of images and video.
Multiple extensions:
Support GPS , AGPS and Beidou compass navigation.
Always-available wireless connection:
Supports 802.11 a/b/g/n full-band wireless communications and maintains real-time connection with the system to ensure high efficient operation.

Hot Products

nigel 5 22 .jpg

Company Information

we are excellent Trade Assurance supplier !!!

Trade Assurance is a free service offered by Alibaba.com that’s designed to help create trust between buyers and suppliers.
Trade Assurance covers Alibaba.com buyers with 100% order protection from their selected Trade Assurance suppliers.

Xiang Yuxing Technology is a leading manufacturer with over 10-years history, specialized in all types of

RFID /NFC TAGSand quality is our culture ! And with us your buisness in safe and your moeny in safe

We have 4 factories in China, the main foreign business office in Shenzhen,near Shenzhen North Station.

 nfc tag production flowfactory (1)

FAQ

1.  Can you offer us few samples ?

After we know clearly what products you need, then we can offer similar existing sample for your reference.

Sample free with shipping cost you paid.

If you need customized tag sample based on your design and requirement,there is reasonable sample cost charged accordingly.



2.  We are not an expert buyer in your technology, what information do you need from us to quote ?

 Dear friend, please inform us clearly the tag's application, what goal do you want to achieve,

we would propose you the suitable product in good price



3. We have a concern that we paid, but you don't send us the goods .

 We are a leading company doing honest business in the internat market for years.

 We always get positive feedback from our worldwide customers.

 Furthermore, our company support Trade Assurance on Alibaba,

 you can place order through Alibaba that guarantees your money safe and order go smoothly.



4. Can we visit your factory ?

  Yes, warmly welcome your factory tour. And it's honored to be your guide in your China trip.

Contact us



Welcome to contact us for more information!
