2020 Good performance double mator vibrating feeder

  • 1 - 2 Sets
    $2,600.00
  • >=3 Sets
    $2,300.00
Model Number:
GZG Vibrating Feeder
Power:
0.18-5.5KW
Lead Time:
Quantity(Sets) 1 - 1 2 - 3 >3
Est. Time(days) 2800 2500 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Graphic customization (Min. Order: 1 Sets)

More

Customized packaging (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Applicable Industries:
Construction works , Energy & Mining, vibrating feeder
After Warranty Service:
Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location:
Viet Nam, Philippines, Brazil, Peru, Saudi Arabia, Indonesia, Mexico, Russia, Malaysia, Kenya, Argentina, UAE, Colombia, Algeria, South Africa, Kazakhstan, Uzbekistan
Showroom Location:
Viet Nam, Brazil, Peru, Saudi Arabia, Indonesia, Russia, Thailand, Kenya, Argentina, UAE, Colombia, Algeria, Sri Lanka, Romania, South Africa, Kazakhstan, Kyrgyzstan, Uzbekistan, Malaysia
Video outgoing-inspection:
Provided
Machinery Test Report:
Provided
Marketing Type:
New Product 2020
Warranty of core components:
6 months
Core Components:
Motor
Condition:
New
Application:
Coal,mineral,building
Power Type:
Electric
Capacity(t/h):
15-1000t/h
Place of Origin:
Henan, China
Brand Name:
Yingda
Dimension(L*W*H):
As required
Weight:
As required
Certification:
CE&ISO, ISO9001
Warranty:
1 Year, One year
After-sales Service Provided:
Video technical support, Free spare parts, Online support, Field installation, commissioning and training, Field maintenance and repair service
Items:
Vibrating Feeder
Model:
GZG110--4
Size of feeding slot:
1100X1500X300mm
Mode of operation:
Continuous
Max. material size:
350mm
Motor Power:
2.2KW
Capacity:
400t/h
Vibration frequency:
1450times/min
Supply Ability
Supply Ability:
30 Set/Sets per Month Vibrating Feeder
Packaging & Delivery
Packaging Details
Vibrating Feeder:
Standard packing.
Motor and gearbox packed in wooden cases.
Port
Qingdao/Shanghai/Tianjin
Lead Time :
Quantity(Sets) 1 - 1 2 - 3 >3
Est. Time(days) 2800 2500 To be negotiated

Good performance double mator vibrating feeder

Summary

Summary

GZG series motor vibrating feeder use of self-synchronization principle of two eccentric vibration motor, and form a horizontal 60 ° angle of the resultant  force, through periodic vibration, thus promoting the throw or gliding to the materials within the trough reached the granular, small block and powdered materials from storage silos  to the subject material equipment in uniform, quantitative, continuously.









Main Application

Main Application

This machine is widely used in metallurgy, coal, chemical industry, building materials, ceramics, food, light industry and other industries of quantitative feeding, automatic batching, quantitative packaging and automatic control feeding links.







Features

Features

The technical data are shown in the table below, the amount of feeding and vibration motor listed in the table are choiced according to horizontal position  of  feeder, and the feeder can downdip 0 °-15 °at install time , the production will increase with the increase of the slant angle, or in guarantee under the condition of production, and  the power consumption of the motor will decreases with increases of the Angle.









Technical Parameters

  Technical Parameters

Model

Feeding capacity

t/h

Size of funnel

L×W×H

Granularity

mm

Vibration Motor



Voltage

(v)

Frequency

(Hz)

Model

Power

(kw)

Vibration frequency

(r/min)

Weight

(kg)

GZG30-4

15

300×1000×160

120

380

50

YZDP2.5-4

0.18×2

1450

110

GZG40-4

30

400×1200×160

120

YZDP5-4

0.25×2

155

GZG50-4

50

500×1200×160

120

YZDP8-4

0.4×2

190

GZG60-4

80

600×1800×180

150

YZDP16-4

0.75×2

410

GZG70-4

100

700×1800×200

180

YZDP20-4

1.1×2

440

GZG80-4

200

800×2000×225

200

YZDP32-4

1.52×

640

GZG90-4

300

900×1500×300

250

YZDP50-4

YZDP50-4

YZDP50-4

2.2×2



730

GZG110-4

400

1100×1500×300

250

900

GZG130-4

500

1300×1500×400

350

1000

GZG70-6

80

700×1800×200

150

YZDP20-6

1.5×2

960

440

GZG80-6

160

800×2000×225

180

YZDP30-6

2.2×2

670

GZG90-6

240

900×1500×300

240

YZDP 40-6

3.0×2

740

GZG110-6

320

1100×1500×400

240

YZDP50-6



3.7×2



940

GZG130-6

400

1300×1500×400

320

1040

GZG150-6

500

1500×1800×500

320

2000

GZG180-6

800

1800×1800×500



YZDP75-6



5.5×2



2590

GZG200-6

1000

2000×2000×500

360

3700









Certification





Company Profile

Company Profile

Henan Yingda Heavy Industry Co., Ltd has more than 30 years' professional experience in processing belt conveyor, bucket elevator, screw conveyor, apron feeder, scraper conveyor, dust-proof equipment, crushers, vibrating screen, dewatering screen and so on. Now we've developed into more than 120 workers and an experienced team of 10 engineers. Recent years we focus on developing our business overseas and improve our quality constantly. Also, we provide customized service.

Our slogan: quality is the life of enterprise!





Customers visiting

 Customers visiting




FAQ

How to choose the machine suitable for you

1. How much about the throughput? Such as 5t/h,10t/h,20t/h etc.

2. What’s the max size of materials? Such as 5mm, 20mm, 50 mm, 100mm etc.

3. What’s material? Such as coal, powder, grain etc.

Tell me those data, we can help you choose the suitable machine for you.
