2020 hot sale 6040 laser engraving cutting machine for photo albums

FOB Reference Price:Get Latest Price
$9,900.00 - $10,000.00 / Set | 1 Set/Sets (Min. Order)
Power:
100W 60w 80W
Model Number:
LZ-6040
Lead Time:
Quantity(Sets) 1 - 1 2 - 5 6 - 10 >10
Est. Time(days) 7 10 15 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Laser Type:
CO2
Application:
Laser Engraving
Applicable Material:
Acrylic, Crytal, Glass, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Stone, wood
Engraving Area:
400mm*600mm
Engraving Speed:
0-1200mm/s
Graphic Format Supported:
AI, PLT, DXF, Dst
Condition:
New
CNC or Not:
yes
Cooling Mode:
water cooling
Place of Origin:
Shandong, China
Brand Name:
LEIZE
Dimension(L*W*H):
980*780*360mm
Certification:
ce, ISO, Sgs
Laser Source Brand:
RECI
Laser Head Brand:
LEIZE
Control System Brand:
RuiDa
Weight (KG):
185 KG
Key Selling Points:
Easy to Operate
Warranty:
1 Year
After-sales Service Provided:
Online support
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
After Warranty Service:
Video technical support, Online support
Local Service Location:
Canada, Turkey, United Kingdom, United States, Italy, France, Germany, India, Mexico, Russia, Spain, Japan, Australia, South Korea, Romania
Showroom Location:
Canada, Turkey, United Kingdom, United States, Italy, France, Germany, India, Mexico, Russia, Spain, South Korea, Romania, Japan, Australia
Machinery Test Report:
Provided
Video outgoing-inspection:
Provided
Marketing Type:
New Product 2020
Warranty of core components:
1 Year
Core Components:
laser engraving head
Product name:
C02 Laser Engraving Cutting Machine
Laser power:
50W/60W/80W/100W
Function:
Cutting Engraving Non-metal Materials
Keywords:
Co2 Laser Cuting Machine
Laser source:
RECI Laser Source
Working area:
600*400mm
Power:
60w/80w/100w
Cooling system:
Water Cooling
Engraving speed:
0-1200mm/s
Software:
Ruida Support
Supply Ability
Supply Ability:
30 Set/Sets per Month
Packaging & Delivery
Packaging Details
Packaging Details
1. Scratch-resistant and anti-static with professional packing film
2. Anti-collision for the whole machine with special mould
3. Waterproof and wetproof with tarpaulin materials.
LEIZE 5030 40w 60w desktop co2 laser cutting and engraving machine
Port
qingdao,dalian,shanghai,ningbo
Picture Example:
package-img
Lead Time :
Quantity(Sets) 1 - 1 2 - 5 6 - 10 >10
Est. Time(days) 7 10 15 To be negotiated
Video Description
Product Description



LZ-6040
CO2 Laser Engraving & Cutting Machine

LZ-STORM CO2 laser cutting & engraving machine is the latest generation of CO2 laser cutting and engraving machine of Shandong LEIZE Intelligent Technology. It is controlled by CNC and has the characteristics of high cutting precision, vertical cross-section. Its production model is flexible and production efficiency is high. This is a good choice for your company with less pollution and consumption.



Main parameter



Specifications of the Machine
Model
LZ-6040
LZ-6090
Woring Area
400*600mm
900*600mm
Machine Size
980*780*360mm
1280*910*380mm
Laser tube
60W/80W/100W
Machine Weight
130KG
185Kg
Cooling Method
Built-in Water Chiller (compressor type with temperature display)
Engraving Speed
0-1200mm/sec
Cutting Speed
0-1000mm/sec
Z-Axle Height
100MM Adjustable
150MM Adjustable
Laser Output Control
1-100% Set by Software
Minimum Engraving Size
Chinese Charator 2.0mm*2.0mm, English Letter 1.0mm*1.0mm
Max Scanning Precision
4000DPI
Locating Precision
<=0.01
Cutting Thickness
0-20mm(depends on different materials )
Graphic Format Supported
DSP/PLT/BMP/DXF/AI/DWG etc.
Compatible Software
CorelDraw/Photoshop/AutoCAD/All kinds of Embroidery Software
Air assist
Built In air pump 85W
Chiller
Built in compressor water chiller with temperature display
Power Supply
AC 220V+10%, 50Hz/60Hz
Driving System
Customized Stepper driving System.
Main parts suppliers
Power Supply
Customized, LIDE
Stepper Motor
Customized,Leadshine
Motor Driver
Leadshine
Control
Ruida
Linear Guide Rail
Customized
STANDARD
Auto Focus


Product feature

1.Customized linear slide, high precision, low wear and long service life
2. 6 series aluminum high-strength sports structure, high strength, low deformation
3. Top cover can hold on anywhere, independent feeding port, easy to operate
4. Integrated top cover with large visible area and bright lighting
5. Laser source mount structure, easy to upgrade and replace
6. Water cut-off protection system to protect laser source safety
7. High-quality laser source with stable and adjustable power and uniform spot energy
8.Built-in water cooling cycle and air blowing system, highly integrated design, small footprint
9. Removable basement, start engraving anytime, anywhere
10. Auto focusing
11. Dual-red focusing
12. High-speed motion system, acceleration, engraving speed, cutting speed
13. Singapore Laser lens and mirrors

Product Description

This CO2 laser engraving machine as an engraving machine features advanced CO2 laser technology, which can be a general-purpose model, with a rear focusing mode, small size, and high integration. In addition, it makes laser beam transmitted and focused on the surface of the material through the optical mechanism, and the material of the high energy density laser beam action point rapidly vaporizes to form pit points. Equipped with computer-controlled XY console, our CO2 laser engraving machine realizes the function to drive the laser head and control the laser switch as required, the image information processed by the software has been stored in the computer in some way.
When the information is read from the computer in sequence, the laser head will be scanned back and forth line by line from left to right and top to bottom.
Detailed Images

Sample display



PRE-SALES SERVICE

1. 12 hours quick pre-sales response and free consulting;
2. Any kind of technical support are available for users;
3. Free Sample Making is available;
4. Free Sample Testing is available;
5. Progressing solution design will be offered to all the distributor and users.

After-sales Service

1. 12 languages 24 hours Quick Feedback;
2. "Training Video", "Instruction Book", and "Operation Manual" will be offered;
3. Brochures for simple trouble-shootings of the machine is available;
4. Plenty of technical support online is available;
5. Quick Back-up Parts Available & Technical Assistance;
6. Free training service is available.
