20w 30w Raycus fiber laser source for laser marking machine

Feedback Ratings
$1,000.00 - $3,200.00 / Piece | 1 Piece (Min. Order)
Model Number:
RFL-P20QE
$1,000.00
- +
available
RFL-P30Q
$1,400.00
- +
available
RFL-P30QB
$1,500.00
- +
available
All 5 Options
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Customization:
Customized logo (Min. Order: 50 Pieces)
Customized packaging (Min. Order: 50 Pieces)

More

Graphic customization (Min. Order: 50 Pieces) Less
Contact Supplier
Samples - $3,200.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Carman haas
Product name:
laser source
Type:
Pulsed fiber laser source
Wavelength:
1064nm
Nominal average output power(W):
>20
Single pulse energy(mJ)@20kHz:
<120@30kHz
Pulse repetition(kHz):
20-60
Output Power Tunability(%):
10-100
Output fiber Cable length(m):
2
Working Voltage(WDC):
200
Cooling:
Forced Air Cooled

Packaging & Delivery

Selling Units:
Single item
Single package size:
75X43X23 cm
Single gross weight:
13.0 kg
Package Type:
1PC/CTN;CARTON SIZE:75CM*43CM*23CM;13KGS/CTN
Lead Time :
Quantity(Piece) 1 - 10 >10
Est. Time(days) 5 To be negotiated
Video Description

20w/30w/50w/100w Raycus fiber laser source

Product Description

 Raycus laser source parameter

MODELRFL-P20QERFL-P30QRFL-P50QRFL-P50QRFL-P100
                                                        Optical Properties
Average output power20305050100
Central wavelength1064nm1064nm1064nm1064nm1064nm
Frequency Range(kHz)20-6030-6050-10050-10020-200
Output Power Stability<3%<3%<3%<3%<5%
Output Beam diameter(mm)7±17±17±17±16.5±1
Polarization StateRandomRandomRandomRandomRandom
Pulse Width(ns)90-13090-13090-15090-15050-130
Max Single Pluse Energy(mJ)11111
Delivery Cabel Length(m)                                                2(Customizable)
                                                             Electrical Characteristics
Power supply                                                24V
Power range                                               10-100
Power consumption(W)170240340340450
                                                              Other characteristics
Dimensions(mm)391*260*120391*260*120396*360*123391*260*120396*360*123
Cooling                                                Forced Air
Operating Temperature                                                 0-40



Raycus laser source features

Echnical characteristics
Highly stable laser output
High single-pulse energy
High marking efficiency
Short pulse setup time
High reliability
Maintenance-free operation
