25 years warranty 4mm Black/red PV Cable With TUV Approval Safe,Reliable

FOB Reference Price:Get Latest Price
$0.74 - $0.84 / Meters | 5000 Meter/Meters (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
OEM/ODM/maywah
Model Number:
PV1-f
Insulation Material:
XLPE
Type:
High Voltage
Application:
Power Station
Conductor Material:
Copper
Jacket:
PVC
Cross-Section Area:
4mm2
Rated temperature:
-40~90℃
Rated Rating:
DC:1/1.8kv AC:0.6kv
Rated Current:
33~57A
Weathering Resistance:
Sun Res.
Burning Behavior:
IEC60332-1
Life time:
25 years
Supply Ability
Supply Ability:
1000000 Meter/Meters per Week
Packaging & Delivery
Packaging Details
25 years warranty 4mm Black/red PV Cable With TUV Approval Safe, Reliable package:
250M/Roll
Port
shenzhen
25 years warranty 4mm Black/red PV Cable With TUV Approval Safe,Reliable

MAIN FEATURES
  • Wire size: 4.0 mm2

  • Rated temperature: -40~ 90 centigrate

  • Rated Voltage: AC:0.6-1.0KV   DC:1.0-1.8kv

  • DC Voltage test of insulation: 900V, 240h(85 centigrate,3%Nacl) No Break

  • Test voltage of finished cable: 6.5KV, 50Hz, 5min  No Break

  • Max. conductor temperature: +120 centigrate

  • Short-circuit temperature: +200

  • centigrate(at the conductor max. 5 sec.)

  • Life Period: >25years

  • Certifcate:TUV


TECHNICAL DATA


Item



Unit



Technical parameter

Rated temperature

-40~90

 Rated Rating

ac/dc(kv)

0.6~1.0/1.8

Cable Core

No.

1

Cross-Section Area

mm2

2.5

4.0

6.0

Diameter of wires/ Number

NO./mm

51/0.25

52/0.30

84/0.3

Thickness of  the Insulation

mm

≥0.5

≥0.5

≥0.6

Thickness of the Sheath

mm

≥0.5

≥0.5

≥0.6

Outer Dia.

mm

5.2 ± 0.1

5.8±0.1

6.5±0.1

Conductor resistance(20℃)

Ω/km

≤8.21

≤5.09

≤3.39

Voltage test on completed cable

kV/min

6.5/5 No breakdown

Certificate



TUV








Maybe you like follows , Plz click it






AFTER-SALES




1.One stop solution

With a full range of on grid inverter and solar panels and PV cable, we provide comprehensive solution for residential, commercial and large scale plant.

2.Top logistics system

Maywah(DECEN) cooperates with many leading logistics companies which can ensure the on grid solar inverters reach to you safely and quickly.

3.Customer oriented service

Maywah(DECEN) on grid inverters and other solar services are based on the customer's feedback and requests. If the inverter isn't working well, the monitoring software will give us feedback automatically and our professional technical team can help you find out the reason of the fault. We'll replace the device if it's inverter problem. In addition, we also provide regular training to our partners and free solar design software make the intelligent power station more simple.

4. Distributors supporting

Maywah(DECEN) has an established global service network committed to offer all of our customers reliable and tailored inverters and other solar services.





PAYMENT TERM




Trade terms

EXW,FOB,CNF(CFR),CIF

Payment terms

TT

TT--30% in advance production, remains 70% before shipment

LC

LC amount below US$30,000.00 ,We need charge US $500.00 for LC fee.

LC amount above US$100,000.00,we can accept long

 term payment against different interests

LC 30days with 1.9% interests LC amount

LC 60days with 2.8% interests LC amount

LC 90days with 4.5% interests LC amount

LC 180days with 6.5% interests LC amount

Delivery time

7-10days for container quantity





ABOUT US




MayWah Electronics Co., LTD. is a comprehensive new energy Hong Kong enterprises in the rapid development of the global. They professional committed to solar energy, wind power generation system research and development, production, integration and sales.








MayWah has a complete product system - from off-grid& grid tie inverter to the solar tracker, from solar panel to wind turbines, we strive to keep improving; We have a number of patents, and provide the most advanced design and automation technology for the system integration. We have a strong independent research and development design team, and established the depth and rigorous relations of cooperation with the related expert in Tsinghua university. We put the system module and intelligent as our core products, and we take providing customers with the most ideal and economic technology products as own duty.







In terms of service, we always adhere to the principle of the supremacy of customers; Our goal is to make the new energy "more simple, more reliable, more effective", and at the same time, let the customer "easier and more affordable" to enjoy the new energy. In recent years we have established hundreds of & thousands of wind& light intelligent power system in multiple countries around the world







Contact: Tina

WhatsApp:+86-13825028291

Skype:tinating8799

Trademanager:maywahcn
