2bbl-5bbl copper brew kettle, beer brewing system for sale

  • 1 - 1 Sets
    $28,000.00
  • 2 - 2 Sets
    $27,000.00
  • >=3 Sets
    $26,800.00
Model Number:
YS-50L-5000L
Samples:
YS-50L-5000L
$28,000.00 /Set | 1 Set (Min. Order) | Buy Samples
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 2 - 2 >2
Est. Time(days) 45 60 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Report Suspicious Activity
Overview
Quick Details
Processing:
Fermenting Equipment
Applicable Industries:
Hotels, Food & Beverage Factory, Restaurant
After Warranty Service:
Video technical support, Online support, Spare parts
Local Service Location:
None
Showroom Location:
None
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
Yuesheng
Processing Types:
Carbonated Beverage
Voltage:
220v50HZ
Power:
adjustable according to volume
Dimension(L*W*H):
customized
Weight:
200KG-2000KG
Certification:
CE ISO
Warranty:
3 years
Machinery Capacity:
2-5BBL
Machinery Test Report:
Provided
Warranty of core components:
3 years
Core Components:
Motor, Pump, Pressure vessel, Bearing
Key Selling Points:
Easy to Operate
Marketing Type:
Ordinary Product
Video outgoing-inspection:
Provided
After-sales Service Provided:
Engineers available to service machinery overseas
Material:
SUS304/316, Red copper
SUS thickness:
inner wall 3mm, surface 2mm
Heating method:
Steam or electric or gas
Control method:
semi- auto control /PLC control
Finishing:
mirror polishing ≤ 0.4um
Fitting:
Sanitary grade
Working pressure:
1.5-2bar
Accessary:
valves, pipes, hoses...
Insulation thickness:
PU 100mm
Product Certification certification
CE Certified.
Valid from 2018-07-12 until 2023-07-12
Supply Ability
Supply Ability:
20 Set/Sets per Month
Packaging & Delivery
Packaging Details
iron crate, wood box,suitable for long distance sea transport packaging or Wooden case
Port
Qingdao
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 1 2 - 2 >2
Est. Time(days) 45 60 To be negotiated
Video Description

2bbl-5bbl copper brew kettle, beer brewing system for sale

Product Description

Specifications

1.Material: stainless steel 304, Red copper

2.capacity:100L-10000L per day

3.Service: install equipment

4.Certificate: ISO CE

Applications:
Widely used in brewery,bar,hotel,home brewing.

We are professional manufacturer of produce beer equipment. We are specialized in professional design,

 manufacture, installation and commissioning of various beer equipments and supporting facilities. With

 advanced technology, good quality and after-sale service, our products have been highly praised by our customers from many countries.

beer brewing kettle details displaying

Brewing process

Once equipment is installed to form the brewing "system", you can begin to produce fresh, craft beers.

Here are the steps of the brewing process as the ingredients flow through the system:

[ 1 ] - MILL

A high-quality, adjustable, two-roll mill crushes the barley to the desired coarseness to form grist.

[ 2 ] - COMBI VESSEL

Actually two tanks in one: In the top unit, called the Mash/Lauter Vessel, grist and hot water are mixed to produce mash.From this, a clear substance called wort is extracted. The bottom unit of the Combi VEssel holds the additional hot water (liquor) needed for brewing and clean-up.

[ 3 ] - MANIFOLD

During the brewing process, wort and hot and cold water must move easily through the brewhaouse. The Manifold is a nine-valve control station which allows all liquid to transfer in a safe, sanitary manner. This eliminates liquid spillage and contamination, which may occur when connections or disconnectiong hoeses and clamps, or using swing arm panels.

[ 4 ] - BREW KETTLE

Here wort is brought to boil and mixed with hops, which adds bitterness and aroma to the mixture. Depending on customer preference, the Brew Kettle can be directly gas-fired or steam heated. It mau ca clad in stanless steel and copper, or furnished with the classic onion0shaped dome.

[ 5 ] - PLATE HEAT EXCHANGER

Using tap water, chiled water, glycol or a combination of the three, this compact unit efficiently cools wort before it's transferred to the fermenter. The Exchanger also returns excess hot water to the Hot Water (liquor) Tank for use in the next brew.

[ 6 ] - FERMENTERS

Here yeast is added to wort to create the distinctive composition and flavor of beer. Our special disign allows for fermentation, aging, carbonation and lagering all in onetank, if desired. This saves the brewer time and minimizes space. Fermenters are individually temperature controlled. (ASME Code Approved Optional.)

[ 7 ] - FILTER

At this stage, yeast is removed from the mixture, eaving brillantly clear beer. A palte-and-frame or horizontal diatomaceous filter is employed to recover every last drop of beer to minimize and filter the product for packaging.

[ 8 ] - SERVING VESSELS

These units receive and hold the filteres beer for direct service to the bar. Or thay may be used as holding tanks for packaging the product. (ASME Code Approved Optional.)

Detailed Images

Details

Polishing:  Polishing is vital for tanks. Tanks should be polished wholly inside and outside.

Therefore it can ensure there is no place for the bacteria to hide in tanks.

Our polishing system consists of auto and semi-auto polishing machine and manual polishing.

Each tank is polished three times and more polish for the key place.

Welding: Our argon central system for welding provides 100% pure argon to protect tanks from

distorting during welding.

Accessories



Our Services

Pre-sale service:

1. Free of making offers, craft and technical guidance of our Alcohol Processing Types Glycol Jacket Conical Fermenter/ Industrial Fermentation.

If you are interested in any product, please don't hesitate to contact us. We will quote you, and give you all the details you need at first time.

2. We can provide company’s qualification certification and the drawings.

All of our products are passed CE, TUV, GMP , ISO test. We can show you our qualification and certification. And we can provide the drawings to make you use our products well as quickly as possible.

3. We can also make customized products according to customer’s needs.

We accept OEM production. You can inform us all you need. We'll make our best efforts to make your satisfaction.

After-sale service

1. We provide long-term after-sale service.

We don't just provide Alcohol Processing Types Glycol Jacket Conical Fermenter/ Industrial Fermentation, the service after sale is same important for us.

2. Owing to the quotation of our equipment is FOB price which excluded charges of door-to-door service. Thus, if necessary, we can appoint our technician to debug the machine with air ticket, visa, accommodation and labor cost provided by your party. Or you can send your technician to our company to learn techniques.

3. Meanwhile, you can call or E-mail to consult any relevant questions since we have a special line of after-sale service. Or you can communicate online and solve the problems.

Packaging & Shipping

FAQ

Why choose me?

1. Top cone is mirror polished

2. Shadowless manhole

3. Our skilled workers are with more than 10 years welding and related production experiences.

4. Our installation engineers are with more than ten years brewing experiences, which can train or help you

brewing customers-liked beers.

5. High quality milled falsed bottom installation method: special discharging hangle, easy to discharge and clean,;

6. Led cold light, bright , lower power consumption and lasting, other suppliers only use normal light ball;

7. Imported food grade rubber hose, long lift-span, safe and firm.

8. Large spent grain door, reliable sealing, with hopper, easy to make the spent grain out without ground pollution.

9. Mechanical pressure adjustable valves: plus and minus pressure protection, ensure the tank safty.

10. Complete quality control and management system: material IQC complete inspection, PQC production

process inspection, OQC inspection after finishing production brewhouse installation 24 water leakage test

and pressure test, fermenters cooling jacket pressure 24 hours test.

11. 3Years After-sales services for our goods.
