2km 3km 4km long range thermal imaging dome camera

FOB Reference Price:Get Latest Price
$3,000.00 - $5,000.00 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Santos
Model Number:
XT-SH05-T-3250
Type:
Analog Camera
Style:
PTZ Camera
Sensor:
CCD
Special Features:
Waterproof / Weatherproof
IR Distance:
4KM
Camera type:
Thermal image high speed dome
Image Sensor:
FLIR Vox
Resolution:
320x240 or 640x480
Certificate:
CE FCC RoHs
Warranty:
3 Years
Power Supply:
DC12V/AC24V
Keyword:
flir camera
Color:
White
Function:
thermal heat detection
Technology:
Pan / Tilt / Zoom
Supply Ability
Supply Ability:
10000 Set/Sets per Year
Packaging & Delivery
Packaging Details
Strong Export Carton Package.
Port
Shanghai,Shenzhen
Lead Time :
Shipped in 18 days after payment
Product Description

Specification:


Long range thermal image high speed dome camera

1.) Using the world’s most advanced uncooled VOx infrared focal plane array(FPA) with 336×256 pixels;
2.) Affords outstanding image quality and thermal sensitivity that can detect temperature difference less than or equal to 45mK at f/1.0;
3.) With a detection range over 3800m, the device is able to generate well-defined images in full darkness, haze and smog;
4.) The infrared thermal imager and the camera perform around-the-clock monitoring through video switch. The built-in heater ensures the display can show perfect monitoring images even in chilly and extremely harsh environments;
5.) Super strong protection for its critical parts meets the standard of US military Mil-Std-810 and IP66,.which is Moisture-resistant and waterproof, both components work well within the temperature range -32°C~+55°C;
6.) OSD function (English/Chinese)
7.) Clock wake-up function with various time-set tasks available.(Presets,Auto-scan,self-study,tracks etc.)
8.) 4 pattern tours (each one can record 200s)
9.) 6 cruising tracks and 128 preset positions;
10.) Power input for general monitoring purposes: AC 24V/2.5A;
11.) IP thermal camera supported;
Model
                     XT-H001-T-3250
XT-H001-T-3219
Sensor Type
Uncooled LWIR Thermal Imager,VOx Microbolometer
Uncooled LWIR Thermal Imager,VOx Microbolometer
Sensor Format
336x256 pixels
336X256 pixels
Spectral Band
7.5 ~ 13.5μm
7.5 ~ 13.5μm
Field of View
14°(H) ×11°(V),50mm lens
36°(H) ×27°(V),19mm lens
IFoV2 (milliradians)
0.760 mrad(50mm lens)
2 mrad(19mm lens)
Range performance
About 3.8km (Detection range)
About 1.6km (Detection range)

About 970m(Recognition range)
About 390m(Recognition Distance)
NEdT Performance
< 40 mK at F=1.0
< 40 mK at F=1.0
Analog Video
50Hz (PAL)
50Hz (PAL)
Focus
Factory-set at infinity focus; lens thread mount allows focus adjustment
Factory-set at infinity focus; lens thread mount allows focus adjustment
Digital Zoom
2x & 4x
2x & 4x
Image processing
DDE
DDE
Products Show
Our Company

Factory Enterance

Sweet memory in 2014 for Brazil customer to win world cup 120 units laser camera project.

Workshop

As original thermal & laser PTZ camera factory,our valued global customers never worry about our delivery & after-sale serives.

Military Laser camera project for Romania

One of old military customers ordered 150 units military laser PTZ camera from us. So far not any failure after 3 years passed.

PTZ assembly

Never should we forget the endeavor made by our professional assmebly workers. Salute to them!



Our Certifications

Certificates:

As professional night vision PTZ camera factory,

we passed ISO9001:2000 factory certificates,CE,FCC,ROHS certificates for laser & thermal cameras.

All these certificates ensures our high quality PTZ products as well as stable PTZ performances.

Just contact us for your night vision PTZ requirements!

Our Service

Professional

With more than 10 years night vision PTZ camera factory exprience;

CE,FCC,ROHS product certificates;

ISO9001:2000 factory certificates;

10 year professional night vision PTZ sales & market team;

Enthusiasm

Our sales team supports 24hr-7day unlimited supports on any PTZ questions!

Customers can either enjoy skype online instant supports or 30-mins mail supports all the time!

Crazy

We clearly know each project,each customer has always invidivual technical requests.

And our 10 year R&D team always working on efficient & customized night vision PTZ solution!

Packing & Delivery

Packing Details: We only use double layer strong export carton to ensure shipping safety.

Delivery Details : We support courier shipping,sea shipping,air shipping as well.

1. Double Layer Strong Carton
2. Inner carton show
3. Six units thermal waiting delivery.
FAQ

Q: Are you trading company or manufacturer ?

A: We are original PTZ factory for thermal & laser cameras.

Q: How long is your delivery time?

A:  Usually it takes 7-15 days. But depending on order qty.

Q: Do you provide samples ? is it free or extra ?

A: Yes. Customers need to pay sample & freight.
