300L 500L1000L Stainless Steel Beer Brewery Equipment Micro Brewing Machine Turnkey Project For Sale

$6,630.00 - $12,900.00 / Set | 1 Set (Min. Order)
Model Number:
HG-300L
$6,630.00
- +
available
HG-500L
$9,600.00
- +
available
HG-1000L
$12,900.00
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Customization:
Customized logo (Min. Order: 1 Sets)
Customized packaging (Min. Order: 1 Sets)

More

Graphic customization (Min. Order: 1 Sets) Less
Samples: $6,600.00 /Set, 1 Set (Min. Order): Buy Samples
Contact Supplier
Samples - $6,600.00 /Set, 1 Set (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Processing:
Fermenting Equipment
Applicable Industries:
Food & Beverage Factory, Restaurant, Food & Beverage Shops, Breweries
After Warranty Service:
Video technical support, Online support, Spare parts, Field maintenance and repair service
Local Service Location:
United States, France, Germany, India, Russia, Spain, Japan, Malaysia
Showroom Location:
Canada, Turkey, United Kingdom, Italy, France, Germany, Viet Nam, Philippines, Brazil, Indonesia, India, Russia, Spain, South Korea, Chile, UAE, Colombia, Romania, Bangladesh, South Africa, Ukraine, Kyrgyzstan, Japan, Malaysia, Australia
Condition:
New
Place of Origin:
Shandong, China
Brand Name:
HG
Processing Types:
Alcohol
Voltage:
According to client's need
Power:
According to client's need
Dimension(L*W*H):
According to client's need
Weight:
According to client's need
Certification:
CE ISO TUV
Warranty:
3 years
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
Machinery Test Report:
Provided
Warranty of core components:
1 Year
Core Components:
Motor, Pressure vessel, PLC
Key Selling Points:
Easy to Operate
Marketing Type:
New Product 2020
Video outgoing-inspection:
Provided
Material:
SUS304
Usage:
Beer Brewing
Cooling way:
Dimple plate cooling
Capacity:
300L-1000L
Thickness of inner jacket:
3mm
Welding:
TIG Welding
Insulation Materials:
PU Foma Insulation
Polish:
Ra0.4
Control system:
PLC
Product Certification certification
CE Certified.
Valid from 2017-06-26 until 2022-06-26

Packaging & Delivery

Selling Units:
Single item
Single package size:
10X10X10 cm
Single gross weight:
36.000 kg
Package Type:
Container shipping and Iron frame packaging
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 15 To be negotiated
Video Description
300L 500L1000L commercial brewery beer brewing equipment craft beer making machinery
Architecture
Main Components
Brewing process
1.Milling System
01.Malt Mill
Malt crushing in mille
2.Heating Method
01.Steam Boiler (Optional)
02.Burner (Optional)
03.Electric Heating (Optional)
For heating saccharification system
3.Saccharification System
01.Mash Tun / Lauter Tank& Brew Kettle/ Whirlpool Tank (2 Vessels)
02.Mash Tun & Lauter Tank & Brew Kettle / Whirlpool Tank (3 Vessels)
03.Mash Tun / Lauter Tank & Brew Kettle & Whirlpool Tank (3 Vessels)
04.Mash Tun & Lauter Tank & Brew Kettle & Whirlpool Tank (4 Vessels)
Extraction of sugar from malt for subsequent fermentation
4.Fermentation System
01.Fermentation Tank
02.Bright Tank
Use for cool wort fermentation or maturation
5.Cooling System
01.Glycol Tank
02.Glycol Unit
Use for glycol water chilling and keep cooling wort in the late of fermentation period
6.CIP System
01.Disinfection Tank
02.Alkali Tank
Use for cleaning tanks
7.Control System
01.PID
02.PLC (Siemens)
Plays a controlling role in the brewing process
Item
Production capacity
Volume in US Gallon
Heating area
Tank diameter
Height
HG-100
100L/day
26US Gallon
0.25㎡
650mm
2000mm
HG-200
200L/day
53US Gallon
0.25㎡
850mm
2200mm
HG-300
300L/day
79US Gallon
0.3㎡
950mm
2500mm
HG-500
500L/day
132US Gallon
0.5㎡
1160mm
2800mm
HG-1000
1000L/day
264US Gallon
1.0 ㎡
1360mm
3000mm
HG-2000
2000L/day
528US Gallon
2.0㎡
1760mm
3150mm
HG-3000
3000L/day
792US Gallon
3.0㎡
1860mm
3800mm
HG-5000
5000L/day
1320US Gallon
5.0㎡
2260mm
4400mm
1.High cost performance
2.Good abrasion resistance materialcopper beer equipment
3.We all adopt SUS304 to produce our equipment. The inner jacket and seal head of the tanks are all 3.0mm. The external jacket is 2.0mm. It ensure the good pressure resistance and good abrasion resistance.
4.Polishing accuracy up to Ra0.4μ m
5. Strict tank pressure test
6. Energy conservation and pollution emissions
7.It can be customized according to the process and requirements of customers
No.
Item
Specification
01
Gross capaity
1300L
02
Useful capacity
1000L
03
Thickness
Inner (SUS304)thickness: 3.0mm;
External-Jacket(SUS304) thickness: 2.0mm
04
Material
Stainless steel 304
05
Cooling way
Dimple jacket plate
06
Cleaning way
CIP in situ cleaning, with rotary spray cleaning ball
07
Insulation
Polyurethane-thickness: 100mm
08
Accessories
Sample valve, Pressure gauge, Breath valve, Temperature gauge,
Top manhole, Washing ball, Butterfly valves, CIP Arm, Hop port, Discharge arm and so on.
Item
Production capacity
Volume in US Gallon
Heating area
Tank diameter
Height
HG-100
100L/day
26US Gallon
0.5㎡
650mm
1500mm
HG-200
200L/day
53US Gallon
0.8㎡
850mm
1600mm
HG-300
300L/day
79US Gallon
1.2㎡
960mm
1700mm
HG-500
500L/day
132US Gallon
1.8㎡
1160mm
2300mm
HG-1000
1000L/day
264US Gallon
2.6㎡
1360mm
2500mm
HG-2000
2000L/day
528US Gallon
3.6㎡
1560mm
2850mm
HG-3000
3000L/day
792US Gallon
4.5㎡
1760mm
3800mm
HG-5000
5000L/day
1320US Gallon
7.2㎡
1960mm
4400mm
FAQ Q:How many years of experience in brewing equipment do you have? A: We have more than 20 years in brewing and beer filling equipment. Q: Where is your factory located? A: Our factory is located in New Town, Jiyang Zone, Jinan, Shandong, China, 2 hours high speed train to Beijing. Q: How could we confirm the details of the products? A: We will provide all the drawings for you to confirm before production. Q: How long the warranty will be? A: 3 years warranty for the whole tank and the main equipment, 1 year for the accessories and auxiliaries. Q: How about the installation? A: We can supply the installation. There are two options. The first option: We could appoint our engineer to your company to debug and repair, as for the cost of this trip such as ticket, visa, accommodation and labor cost shall be on your side. The second option: On-line service will be provided. If still under guarantee period, the necessary accessories and parts will be provided free, the buyer afford the transportation cost. Q: How do you guarantee the filling machine operation? A: Before the delivery, we will test and debug all machines in good condition and record the video for your checking.
Our service 1.Pre-Service:  -Layout:Sent us your building floor plan, or the sketch, or tell us the size (length, width, height), we will offer you an equipment footprint according to your requirement.  -Technical Drawings : We will offer Technical Drawings of each tank based on the equipment layout .  -3D effective sketch: We will 3D effective sketch to make sure ensure you have a more intuitive experience.

 2.After-Service:  -We guarantee the quality of the electrical elements within one year and tanks body within 1 years. If the electrical elements go wrong without artificial factors within one year, we will freely provide them or maintain them for you. -After warranty, if you need to change parts, we will kindly provide you with the best price or maintain it in your site. Whenever you have technical question in using it, we will freely do our best to support. -We can also dispatch our engineer to your brewery to install and adjust the machines for you. He can also train your staff to use the equipment.
