360 degree indoor outdoor wireless 3g 4g ip ptz dome camera outdoor ptz cctv camera with sim card

Feedback Ratings
  • 2-4 Pieces
    $280.00
  • 5-9 Pieces
    $265.00
  • 10-49 Pieces
    $255.00
  • >=50 Pieces
    $245.00
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Customization:
Customized logo (Min. Order: 1 Pieces)
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
YUZUN
Model Number:
YZ-N420M4FG64G
Type:
IP Camera
Style:
Dome Camera
Sensor:
CMOS
Special Features:
Waterproof / Weatherproof
Lens:
2.8-12 motorized zoom lens
IR Distance:
40-80m
Resolution:
960P,1080P
Feature:
Night Vision
Product name:
360 indoor outdoor wireless 3g 4g ip ptz dome camera outdoor ptz
Certificate:
ISO9001
Color:
White and Black
Power Supply:
DC12V/2A
Keyword:
360 indoor outdoor wireless 3g 4g ip ptz dome camera outdoor ptz
Warranty:
1 years
Technology:
Infrared

Packaging & Delivery

Selling Units:
Single item
Single package size:
22X32X33 cm
Single gross weight:
2.5 kg
Package Type:
Gas column bag for the camera And then a kraft paper as box outside
Lead Time :
Quantity(Piece) 1 - 5 6 - 10 11 - 50 >50
Est. Time(days) 5 7 15 To be negotiated

360 degree indoor outdoor wireless 3g 4g ip ptz dome camera outdoor ptz

outdoor wireless 3g ip ptz dome camera

ip camera wireless outdoor ptz

4g ip camera p2p

Product feature

- Support 2g 3g 4g  micro SIM card

- The price is for 1080P/2MP 3g 4g ptz camera with 64G sd card.

   Pls cotact the seller if you want other definition or sd card

- Here is several type of 4g Module,

  pls kindly check which one is suit for the bands of your SIM card,

  and contact the seller with the right module



 Model(PCIE)Support bands
 EC20-CFDD LTE:B1/B3/B8;
TDD LTE:B38/B39/B40/B41;
TDSCDMA:B34/B39;
WCDMA:B1/B8;
GSM:900/1800
 EC25-VFDD LTE:B4/B13
 EC25-AUFDD LTE:B1/B2/B3/B4/B5/B7/B8/28;
TDD LTE: B40;
WCDMA:B1/B2/B5/B8;
GSM:B2/B3/B5/B8;
 EC25-EFDD LTE:B1/B3/B5/B7/B8/B20;
TDD LTE: B38/B40/B41;
WCDMA:B1/B5/B8;
GSM:B3/B8;
 EC25-AFDD LTE:B2/B4/B12;
WCDMA:B2/B4/B5;
 EC25-JFDD LTE:B1/B3/B8/B18/B19/B26;
TDD LTE:B41;
WCDMA:B1/B6/B8/B19;





- Support several monitor way:

  1.Remotely monitor by 4g

  2.Locally monitor by the WiFi of the camera

  3.Network cable

- After insert the SIM for the camera, its like a wifi router, you can connect its wifi to surf the Internet

- 360 degree horizontal continuous rotation, 90 degree verticle rotation

- Plug and play, just need to insert the SIM card and power on the camera

- IP66 waterproof, suitfor outdoor rainy day

- Support audio monitor, 1 way audio input

- Mobile APP: CamHi, support p2p function.

- Support motion detection, email alarm

- Storage video by sd card

Storage timetable

(It's the time for main stream,the stream is adjustable)

Storage/Definition720P/960P1080P
16GAbout 3 daysAbout 1 day
32GAbout 7 days2-3 days
64GAbout 14 days6-7 days
128GAbout 28 days13-15 days
     Note:This is for your reference only,
               storage time is little different base on the environment
Product parameter
Model

YZ-H413M4FG

YZ-H420M4FG

Video and audio

Video compression

H.264 High Profile @Level 4.0

Main processor

Hisilicon 32Bit RSIC Embedded performance DSP

Image sensor

1/3” CMOS

1/2.8” CMOS

Effective pixels

1.3 mega pixels

2.0 mega pixels

Maximum resolution

First stream:1280*960

First stream:1920*1080

Second stream:640*352

Second stream:640*352

Video frame rate

First stream:1280*960@25fps

First stream:1920*1080@25fps

Second stream:

640*352@25fps

Second stream:

640*352@25fps

Video bit rate

32kbps-8Mbps adjustable

Video stream

Multiple H.264,M-JPEG video stream, at maximum resolution to 25 FPS while the sync output of multi-channel video stream

Camera module

Lens

2.8-12mm motorized zoom lens

Min. illumination (LUX)

Color : 0.01/F1.2 ;  Monochrome : 0.001/F1.2 ;  IR : 0

White balance

Automatic white balance / manual

Auto control

AWB/WGC/AE/AIC, automatic day/night double filter switch

3D noise reduction

Support

Low illumination enhanced

Support

Network

Network protocols

IPv4 ,  TCP/IP ,  UDP ,  HTTP ,  RTP/RTCP/RTSP ,  FTP ,  UPnP ,  DDNS ,  NTP ,  IGMP ,  ICMP ;

3G/4g

Support 4G (mobile, Unicom, telecom), compatible with 3G (mobile, Unicom, telecom) network transmission

Access protocol

Standard ONVIF2.0 protocol

Safety

Password protection , multi-user access , access authorized

System integration

APP interface

Support integrated API,SDK

IR distance

6 pieces IR 850nm light source, IR distance up to 40-80 meters

Alarm

Support motion detection

Alarm upload

Support upload the alarm and time by email and FTP

Local storage

Support micro-SD card, max 64GB

P2P

Support P2P remote monitoring, no cabling, plug and play

PTZ function

Rotate speed : horizontal and vertical 0-40°/s ,

Rotate range : horizontal 360° ,  vertical 120°

Other

Power supply

DC12V/2A (50Hz/60Hz)

Power consumption

<20W

Working environment

Working temperature -20℃~+55℃;working humidity ≤ 95%

Housing

Aluminium alloy and engineering plastic materials

IP rating

IP66

Dimension (mm)

No package: 222*136 ,  Package: 260*255*155

Weight (kg)

No package : 1.7 ,  Package : 2.5

Installation

Wall mounted, ceiling installation


Product show

Packaging & Shipping



DELIVERY TIME:

5-30 days after confirming order,detail delivery date should be decided according to
production season and order quantity.

Company Information

FAQ

1) What's your MOQ?

Sample order >=1pcs
Normal Order >=10pcs per model after sample test

2) How long can I expect to get the product?

Sample or general order can be delivered from our factory in 5-10 working days, bulk order can be delivered from our factory in 10-15 working days.

3) Are you manufacturer or trading company?

We are a manufacturer located in Shenzhen China, you are welcomed to visit our factory.

4) Could you provide OEM&ODM service?

Yes, we provide the OEM&ODM service, our company is focusing on improving video processing technology, we provide the complete system solution and customized products, our R&D team have rich experience of surveillance products.

5) How is your technical Support?

We have strong R&D team to support our customers, and if you have any question for the technology of our products, please email to us and our reply will be sent to you immediately;Also if you have any doubt for the information on our website or any feedback for the quality of our products, please email to us and thanks for your all comments in advance.
