3G 4G Gprs Gsm Sms modem IO Module remote terminal unit Telemetry Controller Data Logger Rtu

$59.00 / Unit | 1 Unit (Min. Order)
- +
- +
- +
All 6 Options
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
3 day(s) after payment received
Customized logo (Min. Order: 1000 Units)
Customized packaging (Min. Order: 1000 Units)


Graphic customization (Min. Order: 1000 Units) Less
Samples: $60.00 /Unit, 1 Unit (Min. Order): Buy Samples
Contact Supplier
Samples - $60.00 /Unit, 1 Unit (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Quick Details
Place of Origin:
Fujian, China
Brand Name:
Model Number:
UC1214 GSM SMS Controller
Item name:
3G 4G GPRS GSM SMS Data Logger Rtu Controller
Baud Rate:
2 x DI + 2x DO
Input Voltage:
5-24V DC
Ingress Protection:
Desktop or Wall Mounting
Operating Temp:
-40°C to 70°C
Micro SIM
1 x TTL Intraface

Packaging & Delivery

Selling Units:
Single item
Single package size:
20X15X10 cm
Single gross weight:
2.0 kg
Package Type:
GSM Controller in one Standard Package
Lead Time :
Quantity(Units) 1 - 10 >10
Est. Time(days) 3 To be negotiated
Product Description

 Ursalink UC1214 3G 4G GPRS GSM SMS modem IO Module Remote Terminal Unit Controller Data Logger RTU

Ursalink UC1214 is an industrial GSM controller developed for the controlling and monitoring of remote equipment or machines with 2 digital inputs and 2 drivable relay outputs.

The UC1214 allows 2 phone numbers to send commands via SMS/USSD, and up to 6 phone numbers can be informed when alarm toggle condition is sufficient. It also supports multiple trigger conditions and actions, enabling users to create various combinations of commands according to their needs.

With rich functionalities and small form-factor design, the UC1214 is able to be attached to many electronic devices at homes, in offices, or on any other sites.

Detailed Images

                       Comprehensive Interface - Bottom

                        Power Connector
                        Serial Port & I/O

Comprehensive Interface - Top

LED Indicator

Antenna Connector

3 Years Warranty Included

With 7x24 Real-Time Online Technical Support

Cellular Interface
1 × 50 Ω SMA (Center PIN: SMA Female)
Micro SIM (Inside the device)
Configuration Interface
1 × TTL Intraface
Baud Rate
Terminal block
Digital Inputs
2 x Opto-isolated Digital Inputs.
Can accept any DC signals of any types, including:
➢ Dry Contacts
➢ DC Voltage (3-24V)
Digital Outputs
2 x SPDT Relay Contact Rating:
3 Amp DC (Max: 30 V) or 3 Amp AC (Max: 250 V)
Power Supply
Terminal block
Input Voltage
5-24V DC (Standard adapter: DC 12V/0.5A)
Physical Characteristics
Ingress Protection
79 x 60 x 24 mm (3.11 x 2.36 x 0.94 in)
Desktop or Wall Mounting
LED Indicators
1 × STATUS, 1 × ACT
Operating Temperature
-40°C to 70°C
Relative Humidity
0% to 95% (non-condensing) at 25ºC/77ºF
Related Products
Application Example
Shipping & Delivery

Superior Customer Services

- 3 year Warranty
- Free firmware upgrade for life
- 24 hours Technical support through phone calls, emails, skype, and remote assistance
- Various training, including sales and technical training like online Webinar
- Customizable products with OEM/ODM service


- Within 2-3 days after the payment
- Support any delivery methods as you require, such as:

Meet Us Worldwide
Company Information

About Ursalink

Ursalink is a professional high-tech enterprise specializing in the design and manufacture of best-in-class industrial-grade M2M/IoT hardware and solutions with relentless reliability, reliable security and remarkable performance for the global market. The strong experience of Ursalink's research and development team allows the integration of proven technologies and open customizable functionality to the user for enhanced solutions to an ever-changing world of IoT & M2M challenges, without sacrificing stability and security. With the future in mind, Ursalink designs and delivers customer-tailored products and services with an emphasis on the most minor details that enhance our products longevity.


We spare no efforts in quality control and product innovation. The strong R&D capability empowers Ursalink to provide remarkable reliability and usability for the global marketplace. With future in mind, Ursalink designs, deploys and delivers custom-tailored services with an emphasis on the most minor details that enhance our products longevity.
