3G Industrial Wireless Dual SIM Card Load Balance 4 Lan Ethernet Port Router Wifi Dual Sim 3G Router

FOB Reference Price:Get Latest Price
US $159-299 / Piece | 1 Piece/Pieces industrial 3g router (Min. Order)
Supply Ability:
2000 Piece/Pieces per Month industrial 3g router
Port:
XIAMEN
Overview
Quick Details
Place of Origin:
Fujian, China (Mainland)
Brand Name:
Four-Faith
Model Number:
F3836
Description:
industrial 3g router
CPU:
Industrial 32bits CPU
FLASH:
4MB(Extendable to 16MB)
SDRAM:
32MB(Extendable to 64MB)
Standard Power:
DC 12V/1.5A
Power range:
DC 5~35V
Consumption:
<450mA (12V)
Housing:
Iron, providing IP30 protection
Dimensions:
206x135x28 mm
Operating Temperature:
-25~+65C (-13~+149℉)
Packaging & Delivery
Packaging Details
Standard four-faith carton or neutral carton package
industrial 3g router
Delivery Time
1 working day for sample/small order after payment received

3G Industrial Wireless Dual SIM Card Load Balance 4 Lan Ethernet Port Router Wifi Dual Sim 3G Router

Product Description

1. General Information

F3836 LTE/WCDMA WIFI ROUTER is a kind of cellular terminal device that provides large data transfer function by public LTE/WCDMA network.

It adopts high-powered industrial 32-bits CPU and embedded real time operating system. It supports RS232 (or RS485/RS422), Ethernet and WIFI port that can conveniently and transparently connect one device to a cellular network, allowing you to connect to your existing serial, Ethernet and WIFI devices with only basic configuration.

It has been widely used on M2M fields, such as self-service terminal industry, intelligent transportation, smart grid, industrial automation, telemetry, finance, POS, water supply, environment protection, post, weather, and so on.



2. Product Feature

Design for Industrial Application

  • High-powered industrial cellular module
  • High-powered industrial 32bits CPU
  • Support low-consumption mode, including sleep mode, scheduled online/offline mode, scheduled power-on/power-off mode(optional)
  • Housing: iron, providing IP30 protection
  • Power range: DC 5~36V
  • Stability and Reliability
  • Support hardware and software WDT
  • Support auto recovery mechanism, including online detect, auto redial when offline to make router always online
  • Ethernet port: 1.5KV magnetic isolation protection
  • RS232/RS485/RS422 port: 15KV ESD protection
  • SIM/UIM port: 15KV ESD protection
  • Power port: reverse-voltage and over-voltage protection
  • Antenna port: lightning protection(optional)

Standard and Convenience

  • Support standard RS232(or RS485/RS422), Ethernet and WIFI port that can connect to serial, Ethernet and WIFI devices directly
  • Support standard WAN port and PPPOE protocol that can connect to ADSL directly
  • Support intellectual mode, enter into communication state automatically when powered
  • Provide management software for remote management
  • Support several work modes
  • Convenient configuration and maintenance interface(WEB or CLI)

High-performance

  • Support multiple WAN access methods, including static IP, DHCP, L2TP, PPTP,PPPOE,2G/3G/4G
  • Support double link backup between LTE/WCDMA and WAN(PPPOE, ADSL)(optional)
  • Support VPN client(PPTP, L2TP, IPSEC)(only for VPN version)
  • Support VPN server(PPTP, L2TP, IPSEC)(only for VPN version)
  • Support local and remote firmware upgrade,import and export configure file
  • Support NTP, RTC embedded
  • Support multiple DDNS provider service
  • Support VLANs, MAC Address clone, PPPoE Server
  • WIFI support 802.11b/g/n. support AP, client, Adhoc, Repeater, Repeater Bridge mode
  • WIFI support WEP,WPA,WPA2 encryption,Support MAC address filter
  • Support multiple online trigger ways, including SMS, ring and data. Support link disconnection when timeout
  • Support APN/VPDN
  • Support DHCP server and client, firewall, NAT, DMZ host , URL block, QoS, traffic statistics, real time link speed statistics etc
  • Full protocol support , such as TCP/IP, UDP, ICMP, SMTP(optional), HTTP, POP3(optional), OICQ(optional), TELNET, FTP(optional), SNMP, SSHD, etc
  • Schedule Reboot, Schedule Online and Offline,etc



 F3946 Dual-Module WIFI Router


• Samart Link Switch Backup
• Powerful WIFI
• Provide More Security Deployment Scenarios
• Reliable Networking And Communication
• Support APN/VPDN
• Convenient configuration and maintenance interface
• Support Local and Remote Firmware Upgrade



F3826 LTE-FDD WIFI 802.11b/g/n Single Port Router


Provides large data transfer function by LTE&WCDMA
• Powerful WIFI, WIFI support 802.11b/g/n
• Support AP, client, Repeater, Repeater Bridge mode.
• Supports RS232 (or RS485/RS422), Ethernet and WIFI port
• Support VPN link
• Support auto recovery mechanism, including online detect, auto redial when offline to make router always online
• Provide management software for remote management
ater, Repeater Bridge mode.




 F3836 FDD-LTE Industrial 4G Router



• FDD-LTE networks
• WIFI hotspot coverage, high data throughput
• High speed 4G module, strong wireless communication ability, real-time transmission for volume data
• Supports APN/VPDN, IPSEC, PPTP, L2TP, GRE, OPENVPN etc
• Stable work for 7 * 24 hours
• Support devices configuration, upgrade and maintenance remotely
• GPS(optional)
• ZigBee(optional)
• Allocation of bandwidth resources is under control(optional)

F3427 WCDMA Small Industrial Cellular Router



• Low-consumption mode
• OPENVPN, IPSEC
• Easily remote transmit data and Remote access solutions
• Easily Access your remote PLC
• Application for ATM,Kiosk,Vending machine,LED Advertisement screen,Lottery machine etc.
• Support link disconnection when timeout
• Scheduled online/offline mode
• Provide management software for remote management
• Note:No WIFI





F7436 GPS+WCDMA WIFI ROUTER



• Support GPS Positioning Function
• UMTS/WCDMA/HSDPA/HSUPA/HSPA+ networks
• WIFI hotspot coverage, high data throughput
• High speed 4G module, strong wireless communication ability, real-time transmission for volume data
• Supports APN/VPDN, IPSEC, PPTP, L2TP, GRE, OPENVPN etc
• Stable work for 7 * 24 hours
• Support devices configuration, upgrade and maintenance remotely
• Allocation of bandwidth resources is under control(optional)

F3936-3636H Media Bus WIFI Operating Router



• Advertisement push
• 3G/4G Router as WI-FI hotspot
• Provide powerful business platform
• Email or cellphone No. to verify for free Wi-Fi
• Local entertainment (APP,movies,musics,games) by Wi-Fi
• No limited ads
• Data storage with SSD, ensure the data security and stability on high speed read and write
• Support SSD(Solid State Disk) and TF card for local storage ( TF card is optional )




                             F3X27 WCDMA Small Industrial Cellular Router
Interface1*Ethernet, *1 RS232(or RS485/RS422) 1* SIM/UIM
Power RangeDC 5~36V
Standard PowerDC 12V/1.5A
HousingIron, providing IP30 protection
Dimensions100x97x25 mm
Weight320g
Operating Temperature(-35°C t~ +75°C) / (-31°F ~ +167°F)
Warranty1 year
AccessoriesPower Adapter, RS232 serial cable, Cellular Antenna
                           F3X26 LTE-FDD WIFI 802.11b/g/n Single Port Router
Interface1*Ethernet, 1* WAN, 1 RS232(or RS485/RS422) 1* SIM/UIM
Power RangeDC 5~36V
Standard PowerDC 12V/1.5A
HousingIron, providing IP30 protection
Dimensions157x97x25mm
Weight440g
Operating Temperature-35°C t~ +75°C) / (-31°F ~ +167°F)
Warranty1 year
AccessoriesPower Adapter, RS232 serial cable, Cellular Antenna,Wifi Antenna
                          F3x36 FDD-LTE Industrial 4G Router
Interface4*Ethernet, 1* WAN, 1 RS232(or RS485/RS422) 1* SIM/UIM
Power RangeDC 5~36V
Standard PowerDC 12V/1.5A
HousingIron, providing IP30 protection
Dimensions207×135×28 mm
Weight790g
Operating Temperature-35°C t~ +75°C) / (-31°F ~ +167°F)
Warranty1 year
AccessoriesPower Adapter, RS232 serial cable, Cellular Antenna,Wifi Antenna
                         F3x46 Dual Sim Card WiFi Router
Interface1*Ethernet, 4* WAN, 1 RS232(or RS485/RS422) 2* SIM/UIM
Power RangeDC 5~36V
Standard PowerDC 12V/1.5A
HousingIron, providing IP30 protection
Dimensions207×135×28 mm
Weight790g
Operating Temperature-35°C t~ +75°C) / (-31°F ~ +167°F)
Warranty1 year
AccessoriesPower Adapter, RS232 serial cable, Cellular Antenna,Wifi Antenna

Detailed Images for industrial 3g router

Product Application
We provide loT solutions for various vertical markets including Smart Grid, Industrial Automation,
Smart Vending, Smart City, Retail and more.
