5 Ton Pay Loader 3 Cubic Meters Bucket XCMG ZL50GN Wheel Loader with Factory Price

  • 1 Units
    $45,500.00
  • >=2 Units
    $45,300.00
Rated Load:
5000kg
Model Number:
ZL50GN
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Machine Weight:
17300KG
Dimension(Long * Breadth * High):
8165x3016x3485mm
Warranty:
1 Year
After-sales Service Provided:
Field installation, commissioning and training, Field maintenance and repair service, Video technical support, Online support, Free spare parts, Engineers available to service machinery overseas
Applicable Industries:
Hotels, Garment Shops, Building Material Shops, Machinery Repair Shops, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Energy & Mining, Food & Beverage Shops, Advertising Company
Condition:
New
Brand Name:
XCMG
Place of Origin:
Jiangsu, China
Type:
Front Loader
Moving Type:
Wheel Loader
Certification:
CE ISO
Hydraulic Cylinder Brand:
From USA
Hydraulic Pump Brand:
From USA
Hydraulic Valve Brand:
From USA
Engine Brand:
Shanghai Diesel engine
UNIQUE SELLING POINT:
High load Moment
Power(W):
162 KW
Bucket capacity:
3m3, 3.0(m3)
Engine:
SC11CB220G2B1
Rated Power:
162kw
Operating weight:
17300kg
Tire specification:
23.5-25(L3)
Max. traction force:
165kn

Packaging & Delivery

Selling Units:
Single item
Single package size:
816X301X348 cm
Single gross weight:
17500.0 kg
Package Type:
main machine nude packing, tools by standard export carton
Picture Example:
package-img
package-img
Lead Time :
Quantity(Unit) 1 - 1 >1
Est. Time(days) 7 To be negotiated
Video Description






XCMG 5ton 3m3 wheel loader ZL50GN

Product Description

 Parameters



ltem
Parameters
Unit
Rated load
5000
kg
Rated bucket capacity
3
Total weight
17500
kg
Dumping height(from ground to main blade plste)
3090
mm
Dumping distance(from the front wheel to main blade plate)
1130
mm
Maximum breakout force
170
KN
Max.tractive force
165
KN
Lifting time of swing arm
≤6.5
s
Total cycling time
≤11
s
Minimum turning radius(outer edge of bucket)
7300
mm
Minimum turning radius(tire center)
6400
mm
Articulated angle
35
°
Gradeability
30
°
tire size
23.5-25

Overall demension of machine(L×W×H)
8165×3016×3485
mm
Engine model
SC11CB220G2B1

Rated power/rotate speed
162/2000
kW/r/min
Travel speed
Gear I(F/R)
0~11.5/0~16.5

Gear II(F)
0~38

Main configurations:
1. Model: ZL50GN
2. Shanghai engine SC11CB220G2B1 under Caterpilla C6121 license
3. Rated Power: 162kW/2200r/min
4. Rated load: 5 ton
5. Planetary power shift transmission
6. Arvin Meritor dry brake axle
7. Hydraulic pilot control system
8. Cooling  and heating air conditioner standard cab
9. 3.0m3 standard bucket
10. 23.5-25-16PR tires
11. Operating weight: 17500kg
12. Dimensions: 8165x3016x3485mm

Tom
WhatsApp: +86 18217305485
WeChat: 18217305485
Facebook: OriemacTom
Product photos



Packaging & Shipping



1 unit can be loaded into a 40HQ container with wheels, bucket, and cabin,  axles disassembled.
