5000W 48V High Efficiency 80A 48VDC WIFI USB RS485 GPRS Monitoring MPPT Solar Inverter

  • 10-49 Pieces
    $507.00
  • >=50 Pieces
    $487.00
System Type:
Hybrid Solar System
Solar Power (W):
3000W
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
15 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
SAKO
Model Number:
SUNON-PLUS 5KW
Output Frequency:
50HZ60HZ
Application:
HOME
Work Time (h):
24 Hours
Controller Type:
80A
Product name:
Solar Inverter
Solar Controller Type:
MPPT
Solar charger controller:
80A MPPT charge conroller built inside
DC input voltage:
12V/24V
Power factor:
0.8
AC charging current:
10A/20A
Specification:
Normal
Solar Panel Type:
Grade A Polycrystalline
Battery Type:
Lead Acid
Output Voltage (V):
110/120/220/230V
Load Power (W):
5000w 10kw 15KW

Packaging & Delivery

Selling Units:
Single item
Single package size:
72X55.8X29.5 cm
Single gross weight:
33.6 kg
Package Type:
Standard international paper box packing.
Lead Time :
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 15 To be negotiated
Video Description

5000W 48V High Efficiency MPPT Solar Inverter 80A 48VDC WIFI USB RS485 GPRS Monitoring

Features

1. Real MPPT charge controller built inside, 15 % - 2 0 % higher than PWM charge controller, use solar utmost, 3KVA is 60A MPPT, 5KVA is 80A MPPT.



2. Pure sine wave, high frequency technology, wall amounted design , light weighted and easy to operate.



3. Selectable input voltage range for home appliances and personal computers.



4. Selectable charging current based on applications.



5. Configurable AC/Solar input priority via LCD setting.



6. Compitable to grid power or generator power.



7. Parallel operation with up to 6 units only available for 4KVA/5KVA.



8. Auto restart while AC/ Solar is recovering, auto charge and switch, unattended operation.



9. Smart battery charger and management for optimized battery performance.



10. Remote control panel is optional.



11. High Efficient DC to AC Conversion. Minimizing Energy Loss and self power consumption .



12. All around protection functions: Overload,short circuit protection,high voltage,low battery voltage,high temperature ,etc.







Specification

This is a hybrid inverter, Equipped with 60A AC charger and 60A/80A solar charger, Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, Its also have opposite connection protection .





Product Description



ModelSUNON-PLUS-1KSUNON-PLUS-2KSUNON-PLUS-3KSUNON-PLUS-4KSUNON-PLUS-5K
The rated power1000VA/800W2000VA/1600W3000VA/2400W4000VA/3200W5000VA/4000W
INPUT
Voltage230 VAC
Selectable Voltage Range170-280VAC (For Personal Computers), 90-280VAC (For Home Appliances)
Frequnecy Range50Hz/60Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Model)230VAC ± 5%
Surge Power2000VA4000VA6000VA8000VA10000VA
Efficiency(Peak)90%93%
Transfer Time10ms (For Personal Computers), 20ms (For Home Appliances)
Wave formPure sine wave
BATTERY
Battery voltage12VDC24VDC48VDC
Floating Charge Voltage13.5VDC27VDC54VDC
Overcharge Protection16VDC32VDC60VDC
MPPT SOLAR CHARGER & AC CHARGER
Maximum PV Array Power420W1440W3840W
MPPT Range Operation Vol15-33VDC18-145VDC36-145VDC
Maximum PV Array Open Circuit Vol.50VDC145VDC145VDC
Standby Power Consumption15W28W56W
Maxmum Solar Charge Current30A60A80A
Maxmum AC Charge Current10A or 20A60A60A
Maxmum Charge Current50A120A140A
Maxmum Efficiency98%
BEST PANEL CONFIGUTATION
Max. generated from solar charger30Amp, 420W60Amp, 1440W80Amp, 3840W
Best Panel configuration200Wp*2pcs (420Wp)300Wp*4pcs *30V(1400Wp)  4pcs in parallel connection300Wp*4pcs *30V(3360Wp) 6 strings, and 2pcs in each string in series connection
PHYSICAL
Dimension, D*W*H(mm)128*272*355543*394*204mm549*394*224mm
Net Weight (kgs)7.58.4kg10.81kg
OPERATING ENVIRONMENT
Humidity5% to 95% Relative Humidity (Non-condensing)
Operation Temperature0℃-50℃



new products

other Products

Company Information

Company Information

_03_04_05


Certifications

_06

Packaging & Shipping


FAQ



Q1: How to choose a right inverter?
A1:Tell us your demand, then our sales will recommend a suitable inverter to you.

Q2: What's the different between inverter and solar inverter?
A2: Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.

Q3: How about the delivery time?
A3: 7 days for sample; 25 days for bulk order.

Q4: What is the warranty of inverter?
A4: One year warranty on SAKO-Solar product.

Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
