500W 41A 12V DC Power Supply Switching For Led Strip Light DC12V Transformer AC-DC SMPS With Display Billboard Industrial LAMP

Feedback Ratings
  • 10-49 Pieces
    $12.50
  • 50-99 Pieces
    $12.40
  • 100-499 Pieces
    $12.30
  • >=500 Pieces
    $12.29
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
3 day(s) after payment received
Customization:
Customized logo (Min. Order: 1000 Pieces)
Customized packaging (Min. Order: 2000 Pieces)

More

Graphic customization (Min. Order: 1000 Pieces) Less
Contact Supplier
Samples - $15.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
NRSky
Model Number:
NRN-12-500
Output Power:
500W
Output Type:
Single
Input Voltage:
100-240V/AC
Output Voltage:
12V/DC
Output Frequency:
47-63Hz
Output Current:
41.3A
Protections:
Short Circuit/Over voltage/Overload/Over-Temperature
Efficiency:
87%
Size:
241*124*65mm
Weight:
1.1kg
Certificates:
CE ROHS
Application:
LED related products
Warranty:
2 Years
Packing:
pcs/CTN
Gross Weight:
kg

Packaging & Delivery

Selling Units:
Single item
Single package size:
25X13X7 cm
Single gross weight:
1.5 kg
Package Type:
1pc in a gift box, 21pcs in a carton
Lead Time :
Quantity(Piece) 1 - 100 101 - 1000 >1000
Est. Time(days) 3 7 To be negotiated
Product Description
SPECIFICATIONS FOR NRN-12-60
Item No.
NRN-12-500
Dimension
241*124*65mm
Net Weight
1.1kg
Packing
pcs/CTN
INPUT
Voltage Range
100-240V/AC
Frequency Range
50~60Hz
AC Current
0.12A/175V 0.1A/230V
Leakage Current
0.5mA/240V/AC
OUTPUT
Output Voltage
12V±0.5%
Rated Current
41.3A
Rated Power
500W
Current Range
0~41.3A
Voltage Tolerance
±0.5%
Line Regulation
±0.5%
Hold Up Time(Typ)
50ms/230VAC 16ms/115VAC at full load
Efficiency
≥87%
PROTECTION
Over Current
105~150% Rated output power
Protection Type: Hiccup Mode, recovers automatically after fault condition is removed.
Over Voltage
13.8~16.2V
Protection Type: Shut down o/p voltage, re-power onto recover.
Short Circuit
Auto Recover
Protection Grade
IP20
ENVIRONMENT
Working Temp
-20~40℃ refer to output load derating curve
Working Humidity
20~95% RH-Nondensing
Storage Temp
-40~85℃
Storage Humidity
10~95% RH
Temp Coefficient
±0.03%/℃(0~50℃)
Warranty
3 Years
Vibration Frequency
10~500Hz, 2G 10 min/1 circle, period of 60 min, each long X, Y, Z axes.

Main Features

1) 100% full load aging test.

2) Conform safety standard and EMC.

3) Wide input voltage suitable for all the countries .

4) We support OEM/ODM.

5) Built-in EMI filter, very low ripple.
