500vac capacitor cbb61 0.5uf-1uf 1.5uf 450vac 40 85 21 50 60hz cbb61 fan capacitor

FOB Reference Price:Get Latest Price
$0.28 - $0.40 / Pieces | 10 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HBC KAY
Model Number:
CBB61
Type:
Polypropylene Film Capacitor
Application:
Fan
Package Type:
Through Hole
Capacitance:
1-35μF
Rated Voltage:
200-500VAC
Operating Temperature:
-40°C- +85°C
Product name:
CBB61 Motor Capacitor
Capacitance tolerance:
±5%
Reference standards:
GB/T 3667.1 (IEC60252-1)
Climatic category:
40/70/20, 40/85/21
Class of operation:
Class B (10000h) Class C (3000h)
Class of safety protection:
P0
Dissipation factor:
20x10-4 (100Hz,20℃
Test voltage terminal to terminal Utt:
2 Un for 2 seconds
Test voltage terminal to case Utc:
(2Un+1000)VAC or 2000VAC-50Hz for 60 seconds
Insulation Resistance:
≥3000MΩ.μF(100Hz,20℃,1min)
Supply Ability
Supply Ability:
50000 Piece/Pieces per Day cbb61 capacitors 1uf 500vac
Packaging & Delivery
Packaging Details
Customized carton
Port
Shenzhen/ShanTou/HK
Products Show

CBB61 COHERER POLYPROPYLENE CAPAClTORS SERlES

Main Feature:
Low dissipation factor,small inherent temperature rise.excellent self-healing stability,safety and high voltage withstand,etc.
Applications:
Used widely in washing machine,water pump,air conditioner and as well household electric appliances etc. to start and run single phase motors in alternating current usage.


Product Feature
Rated Voltage
400VAC/450VAC/500VAC  50/60Hz
Class of operation
Class C
Capacitance Range
0.4µF~15µF
Climatic Category
40/85/21
Voltage Proof Between Terminals
2.0UN(2S)
Voltage Proof Between Terminals And Case
2.0UN+1000VAC≤2000VAC(60S)
Capacitance Tolerance
±5% ±10%
Dissipation Factor
≤0.0020 ( 20℃ 100HZ)
Insulation Resistance
≥3000 S
Maximum Permissible Voltage
1.1UN
Maximum Permissble Current
1.3 IN
Class of safety Protection
S0 (P0)
Product Type

Which type you need?

Packing & Feedback
FAQ

Q: Are you trading company or manufacturer ?

A: We are the professional factory in China.

Q: What is the material of your products?

A: The material is metallized film for capacitors used Grade A+. We can also choose material as customers' requirement.

Q: How can us get some samples?

A: We are honored to offer you samples. if you need!

Q: How does your factory do regarding quality control?

A: "Quality is priority. All people always attach great importance to quality controlling from the very beginning to the very end. Our factory has gained ISO9000;SGS authentication,We are the National High-Tech Enterprise.We have the professional technical personnel team,advanced equipments;Skilled production technology by fifteen years.

Q: What is the delivery time?

A: Normally,the time is 7~30days as we can;we must do our best to do it much quickly.
