50L integrated mini beer making machine for homebrewing

FOB Reference Price:Get Latest Price
$3,000.00 - $10,000.00 / Sets | 1 Set/Sets mini beer making machine (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Processing:
Fermenting Equipment
Condition:
New
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Tiantai or OEM
Model Number:
50L
Processing Types:
Alcohol
Voltage:
3phase/380(220,400,415,440)v/50 (60)Hz
Power(W):
15-70Kw depends on size
Dimension(L*W*H):
Various in different models
Weight:
Various in different models
Certification:
CE ISO
Appearance:
Stainless steel or Red Copper clading
Thickness of Tanks:
3mm for interior shell/2mm for exterior shell
Color Available:
Mirror SUS, Luxury red copper
Heating:
Electric/Steam/Direct fired
Heat Insulation:
Heat Insulation
Inner Polishing Precision:
0.4 Micrometer
Volume Design:
Properly according to the capacity request
Controlling System:
Temperature, Pressure auto control
Plants Type:
Turnkey or Customerized
Application:
mini beer making machine
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
3 years from commissioning
Supply Ability
Supply Ability:
300 Set/Sets per Year mini beer making machine
Packaging & Delivery
Packaging Details
Wooden/Veneer case for LCL; Plastic film wrapped and iron frame fixing for FCL
Port
QINGDAO PORT CHINA
Lead Time :
Shipped in 60 days after payment

50L integrated mini beer making machine for homebrewing



Introduction

Mini beer making machine produced by us is a set of technological equipment for

the production of "live" and filtered beer, which includes miller-brewhosue(mash/lauter/kettle/whirlpool tun)

-fermenter-bright beer tank-filter-glycol chilling unit-CIP-control panel -keg filler and rinser etc.

Brew master make their beer attractive to consumers by unique brewing process and distinctive

beer taste. If desired, these beer brewingplant can be placed directly in places of consumption

of beer: restaurants,brewpub, bars, hotels, tourist and shopping centers. Interpreter may

be faced with polished brass, copper besides stainless steel.







Configuration



1.Miller of mini beer making machine

Particle adjustable rolling crusher

Flexible or steel auger for optional

This kind of grain mill was designed to help you get most of the grain. The nickel alloy rollers,

with optimized spiral fluting patterns on it, can be easily adjusted to provide suitable gap

for making different grain types, which can meet both decoration brewing and infusion brewing.





2. 50L Brewhouse of mini beer making machine









The Heating

Way

Steam

The steam heating would require a boiler/generator.

It heat evenly and fast, also easy to control temperature,

not scorch the pot.



Direct fire

The burner and agitator are equipped with kettle.

If you adopt decoction mashing way,

the wort is easier to scorch.

If so, the steam heating is more suitable.



Electric

The electric heating behaves well for the volume

under 500L, saving the investment on the boiler/burner,

if there is no condition to use the boiler/burner

or it is more economical by using electricity.

 The structure

Single vessel

Single vessel for mashing, lautering, boiling and whirlpool



The Manway

Stainless steel

Affordable

Glass

Easy to observe the tank inside







False bottom/filter







False bottom/filter

We use the Laser cutting V-wire False Bottom/Filter.

This kind of False Bottom/Filter is more stronger, even

and nonpollution of welding.Using this false bottom

when lautering, you will find that the grain bed

is easy to form well and it will be also easy to clean

when you finish the lautering.







   Rake







    Rake

We now use the Long-style rake;

the teeth of the rake is varied

so that it can agitate the wort lengthways and transversely,

plus its length, the rake can help to make the malts mix

with the water soon and make the wort flow smoothly

and help to form a efficient grain bed for better lautering.

In addition, the automatic rake lifting units is optional

for customer.







3. 50L or 100L Fermenter of home beer machine

Function

Wort Fermentation or maturation

Tank Capacity

50L or 100L (+25% Headspace minimum)

Interior Shell

SUS304 full welded; TH=2mm

Exterior Shell

SUS304 full welded; TH=2mm

Insulation

Polyurethane; TH=50mm

Glycol Jacket

Dimpled plate on cone and side

Head and Bottom

Dished head and 60 degree cone bottom

Sampling valve

Full sanitary perlick style sampling valve

Safe valve

Mechanical relief valve 2 bar on CIP arm

Pressure gauge

Shockproof pressure gauge with two gauges on CIP arm

Beer outlet

Rotating racking arm and port on cone with butterfly valve







4. Glycol chilling unit of mini beer making machine

Function

Glycol water supply for wort cooling and fermentation cooling

Structure

Glycol water tun+1 chiller







5. Control panel of mini beer making machine

Function

Brewhouse, fermenter, BBT, glycol chilling unit, CIP controlling

Assembling Style

Floor Type/Wall hanging

Electrical Parts

World wide brand CE certificated

Exterior Shell

SUS304 full welded; TH=2mm

Category

Instrument Panel; PLC Panel with Touch Screen









6. Portable CIP cart of mini beer making machine

Function

Clean in place for tanks

Structure

Caustic Tank+ Sterilization Tank

Shell

SUS304 full welded; TH=2mm

Interior Finish Polish

 0.4~0.6 μm





Our service

 a.) Free consultation service before, during, and after sales;

Your questions would be replied within 24 hours by our sales team.



b.) Project planning and design services;

There are professional engineers and technicians in our company, so we can customize the equipment

according to your requirements. What is more, both 2D and 3D drawings can be supplied for your reference.



c.) Free debugging instruction of equipment Training of equipment maintenance and operating;

We would send profession engineers to help you assemble all of the tank and train the operator freely.



d.) Warranty;

Provide 36 months complete warranty for tanks body and lifetime maintenance service;

All of the accessories and auxuliaries facilities are guaranteed for one year.



Company Information

Jinan tiantai beer equipment Co.,Ltd is a professional mini beer making machine manufacturers .

We are specialized in professional design,manufacture,installation and commissioning of various beer brewing equipment and supporting facilities, which includes miller, auger, brewhouse, fermenter, filter,

bright beer tank, glycol water tank, chiller, control panel, CIP for small and mediumsized brewery,

hotel,bar and etc. What is more, we can supply CE and ISO certificate for customers.



At the same time, we have a deep foundation of cooperating with many of domestic and foreign companies

and research institutions, which help us to cultivate and to attract a number of outstanding technical

engineers, production workers,and to laid a solid foundation for the development of enterprises.



Friends, if you are interested in 50L mini beer making machine, please contact us freely to get

detailed configuration and price list. Looking forward to talking with you.
