58MM USB Portable Handheld Android Dot Matrix Printer With Free SDK HCC-T7

Feedback Ratings
  • 1-10 Units
    $90.00
  • 11-50 Units
    $86.00
  • 51-100 Units
    $84.00
  • >=101 Units
    $82.00
Color:
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Customization:
Customized logo (Min. Order: 100 Units)
Customized packaging (Min. Order: 100 Units)
Contact Supplier
Samples - $90.00 /Unit, 1 Unit (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Products Status:
Stock, Used
Type:
Dot-matrix
Style:
Black And White
Use:
Document Printer
Interface Type:
Bluetooth
Max Paper Size:
58mm
Black Print Speed:
5.5mm/s
Color Print Speed:
none
Max. Resolution:
240 dots/line
Brand Name:
HCCTG
Model Number:
HCC-T7BT
Place of Origin:
Guangdong, China (Mainland)
Printing Method:
Dot Matrix
Printing Speed:
5.5mm/s
Resolution:
240 dots/line
Effective Printing Width:
48mm
Character per Line:
40
Paper Width:
57.5±0.5mm
Paper Roll Diameter:
40mm(max.)
Roll Core Inner Diameter:
13mm(min.)
Paper Thickness:
0.06~0.08mm
Paper Supply Method:
Semi-auto paper loading

Packaging & Delivery

Selling Units:
Single item
Single package size:
21X16X9 cm
Single gross weight:
1.0 kg
Package Type:
Nuetral Packing for 58MM USB Portable Handheld Android Dot Matrix Printer with Free SDK HCC-T7 1 pc/box; Box Size: 21*16*9 cm; Weight: 1 kg; 17 pcs/carton; Carton Size: 47*39*35 cm; Weight: 15 kg;
Lead Time :
Quantity(Unit) 1 - 50 51 - 100 >100
Est. Time(days) 7 14 To be negotiated



58MM USB Portable Handheld Android Dot Matrix Printer with Free SDK HCC-T7

Specification

Print

Printing Method

Dot Matrix

Printing Speed

5.5mm/s

Resolution

240 dots/line

Effective Printing Width

48mm

Character

Character Set

ASCII, GB18030 (Chinese), BIG5

Print Font

Code page: 7*9,

Chinese: 16x16; 12*12

Character per Line

40

Paper Spec

Paper Type

Plain paper

Paper Width

57.5±0.5mm

Paper Roll Diameter

40mm(max.)

Roll Core Inner Diameter

13mm(min.)

Paper Thickness

0.06~0.08mm

Ribbon Cassette

ERC09

Paper Supply Method

Semi-auto paper loading

Printer Mechanism

EPSON Brand

Reliability

MCBF(Mean Cycles Between Failure)

1 million lines

TPH

1.5 million lines

Smart Card

N/A

MSR

N/A

Barcode

1D: EAN-13, EAN-8, UPC-A, UPC-E, CODE39, CODE93, CODE128, CODABAR, INTERLEAVED 25

Emulation

ESC/POS

Driver

Windows 98 / ME / 2000 / NT / XP / 2003 Server/Vista/Win7

Sensor

Paper End Sensor

Interface

USB/Bluetooth/RF

Others

Button

Power, Feed, Mode

Indicator

Power, Feed, Mode

LCD

Yes

Display Content

Yes

Memory

Flash: 512kb; RAM: 128kb

Receive Buffer Size

32K

SDK

Windows CE; Windows Mobile 5.0/6.0; Symbian; Blackberry and Android

Multi-languages

46 codepages

Setup Software

Support set bitmap download, baud rate, font, speed, density, password, black mark, Bluetooth etc.

Power

Power Supply (Adapter)

DC9V/2A

Battery Power

7.4V, 1.5A rechargeable Li-ion battery

Battery Charge

35m continuous printing

Charge Time

Less than 3 hours

Battery Duration

360 hours

Auto Cutter

Type

N/A

Life

N/A

Cutting Method

N/A

Physical

Net Weight

256g

Gross Weight

516g (Including battery & roll paper)

Printer Dimension(WxLxH)

103mm x99mm x 46mm

Color

Black

Environment

Operating Temp

0-50°C

Storage Temp

-20-60°C

Operating Humidity

10%-80%

Storage Humidity

10%-90%

Application

Restaurants, Department Stores, Kitchen, Convenience Stores, Specialty Retail, Supermarket

Accessories

Battery,Charger USB Cable,CD Driver,Leather Case and Paper-roll

Option: vehicle charger

Inner Package(WxLxH)

210mm x 155mm x 90mm(1.5kg)

Outer Package(WxLxH)

N/A
