6 inch double suction water pump with motor

FOB Reference Price:Get Latest Price
$3,000.00 - $13,000.00 / Units | 1 Unit/Units (Min. Order)
Horsepower:
5.5-1600kw
Maximum Flow Rate:
12500m3/h
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China
Brand Name:
Y&L / DEFU
Model Number:
TPOW
Structure:
Single-stage Pump
Usage:
Water
Application:
Fire
Power:
Electric
Fuel:
Diesel
Pressure:
Low Pressure
Standard or Nonstandard:
Standard
Theory:
Centrifugal Pump
Suction diameter:
50-300mm
Color:
Blue/yellow/black/white etc as per your demand
Engine type:
Air Cooling or Water cooling
Connection way for pump with engine:
pin coupling (hard to hard), high elastic coupling
Control panel::
Normal/intelligent control panel
Trailer::
Two or four wheels trailer
Accessories::
Weather-proof or silence-box etc
Keywords:
motor water pump
Supply Ability
Supply Ability:
100 Unit/Units per Month motor water pump
Packaging & Delivery
Packaging Details
Standard Exported Plywood Case, motor water pump
Port
Shanghai /Ningbo

6 inch double suction water pump with diesel motor

Product Description

1.TPOW series Double suction centrifugal water pump with motor :

Bare pump: TPOW series double suction centrifugal water pump is single-stage double-suction split volute casing centrifugal pump and is specially designed and manufactured by our company which based on the market requirement and introducing in German lead technology. Pump through original impeller and modified impeller and cutting, the pump is with full and broad, high efficiency. In the performance scope, according to consumers’ needs, may provide pump with any flow and head.

Accessories:  Trailer : 2 wheels or 4 wheels trailer for convenient mobile ,silence-box for reduce noise , weather-proof for protect, vacuum assisted system for increasing the suction lift.



2.Specification about water pump :



Outlet diameter:
DN80-800mm
Flow rate(capacity):  Q≤11600m3/h(3222L/S)
Head(H): H ≤200m
Working Pressure:
up to 25bar (2.5Mpa)
Suction ability :  wet primining , vacumm system assisted

Operation temperature:

up to +105°C

Working temperature :
 - 10 °c ~  105°c
Power :  Diesel engine or electric motor

Trailer :
two wheel or four wheel

Silenbox canpoy :
available
Voltage:
U=380V, 6kV,10kV
Diesel engine:cummins/perkins/deutz/ABB/Chinese diesel engine


Performance Curve :

 Dear reader, if your take interested, welcome tell us your details specification requirements ,such as flow rate ,head ,motor ( diesel engine or electric motor ) ,then we will choose the suiatble model for you ASAP.

Structure:

The advantages : its hydraulic capability is distributed reasonably ,wide option for user , conveniently check and repair , the efficency and throw is up to advanced international level .

Part   Material
Pump casing:cast iron standard, stainless steel optional
Impeller:stainless steel standard, bronze, cast iron optional
Shaft:ASTM420 standard, ASTM304, ASTM316, ASTM1045 optional
Shaft seal

Mechanical seal standard



4.Applications :

Constructional engineering: Clear water transportion,pressurization system,air

condition water,circulation system,fire extinguishing system,swimming pool and water circulation system.

Industry: circulating cooling system ,process water for  papermaking and  paper pulp,steel production, shipbuilding,sea trasportion,and other mafacturing industry.

Mini industry: water supply,mine drainage,generating station,ect.

Other: municipal water supply,agricultural irrigation,and some others.

Packaging & Shipping


Company Information



FAQ

1. Q: Whats the MOQ ?

A: 1 set for regular product ,the special one we need to discuss.



2. Q : What're your payments ?
A: For small order valve < 4000USD, our customer chose 100% T/T.

For order valve >4000USD, we can accept 30 % T/T inadvance , 70 % should be paid before shipping.



3 . Q : How long is the deliver time ?
A : For the order in stock ,we will deliver goods at once against payment.
For the orders out of stock , the products time is 7 days for bare pump, 25days for electric pump set or diesel engine pump set , the deliver time is base on the shipping date and your order by sea.



4. Q: What about the package ?
A : Standard export Plywood case .



5.Q : How is the pump delivered to us ?
A : For small order will be delivered by internation express ,like DHL,TNT ,FEDEX,UPS.
For large order ,it will be delivered by air ,sea ,vehicle or multi-modal transport.



6. Q : How long is the warranty ?

A: According to the internation standards , pump in standard operation is 1 year ,3 monthes for spare parts.
