6000B/H Capacity PET Bottle Non-Carbonated Soft Drinks / Juice Monoblock Rinser,Filler and Capper

FOB Reference Price:Get Latest Price
$7,000.00 - $28,000.00 / Pallets | 1 Pallet/Pallets mineral water plant (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Packaging Type:
Barrel, Bottles, carbonated machine
Packaging Material:
Plastic, carbonated machine
Type:
Filling Machine
Condition:
New
Application:
Beverage, carbonated machine
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
220V/380V
Power:
4.8KW
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Proman carbonated machine
Model Number:
CGF Water plant
Dimension(L*W*H):
2750*2180*2400mm
Weight:
800KG
Certification:
CE ISO
Name:
CSD carbonated machine
Material:
Ss304
Certificate:
Ce,ISO,SGS
Composition:
carbonated machine
Electrics:
Siemens,Mitsubishi,etc
Control System:
PLC with Touch Screen
Workshop Layout:
Free Design
Bottle Volume:
200ml-2000ml
Capacity:
2000bph to 20000bph
Warranty:
Two Years
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
200 Piece/Pieces per Year carbonated machine
Packaging & Delivery
Packaging Details
1) The special packaging box is according to the immunity standard in China,it suits for long-distance transport, damp proof, rustproof, land way and seaway.
2) Transportation ways: Ocean transportation
Port
shnaghai
Lead Time :
40-70 days
carbonated machine
6000B/H Capacity PET Bottle Non-Carbonated Soft Drinks / Juice Monoblock Rinser,Filler and Capper
Product introduction
This Series water washing filling capping 3-in-1 machine is mainly used for washing,filling sealing Non-Areated carbon dioxide drink such as mineral water,pure water,non-gas wine drink and so on.The machine design is shorten the time for the drink material contact with outside,increase the sanitation condition throught economy benefit.

Feature of Water Filling Machine:
1 Direct connection technology between air conveyor and in-feeding starwheel is applied to replace in-feeding screw and conveying chain to ease bottle changing process with only to change few parts. Newly-designed bottle-separating grippers are assembled to starwheel.
2 We adopts Neck-hanging technology in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to make bottle-size-changing easily , without equipment height adjustment ,only few parts need to be adjusted
3 Specially-designed rinser grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution.
4 High-speed, easily-cleaned filling valves with big flow volume are equipped with well CIP system and control system to rinse the equipment thoroughly.
5 splint of starwheel using twist descending way to simplify the process of bottle-size-changing. Only need to change arch board and starwheel, within ten minutes.

A) Washing part of Bottled Mineral Water Filling Machine:
l All 304 stainless steel rinser heads, water spray style inject design, save water consumption & more clean
lI 304 Stainless steel Gripper with plastic pad, ensure minimal bottle crash during washing
lII 304 stainless steel washing pump

B) Filling Part of Bottled Mineral water filling machines :
l High precision filling nozzle, PLC variable signal control, ensure high filling precision & filling smoothly & steadily,
lIFilling volume adjustable in fine rank, same liquid level after filling
lII All 304 stainless steel contact parts & liquid tank, fine polish, no death corner, easy to clean
lV 304 stainless steel filling pump
V no bottle no filling

C) Capping part of Bottled Mineral water filling machine:
l Place & capping system, electromagnetic capping heads, with burden discharge function, make sure minimum bottle crash during capping
lI All 304stainless steel construction
lII No bottle no capping,
lV Automatic stop when lack of bottle


Capability Character
It adopts hanging type conveying-bottle structure to make changing bottle more convenient,faster and easier.Themain machine adopts advanced PLC control technology.The key electric elements adopt international famous products.



Contact us

Technical Parameter
modelCGF8-8-3CGF14-12-4CGF18-18-6CGF24-24-8CGF32-32-10CGF40-40-12
Number of rinsing head81418243240
Number of filling head81218243240
Number of capping head34681012
(500m)Rated production capacity1000-20002000-40006000-80008000-1200012000-1600016000-20000
(KW)Installed capacity33.544.87.68.3
LxWxH(mm)Overall size1900×1420×2002200×1600×23002450×1900×23002750×2180×24004600×2300×23004550×2650×2300

S.N.NameRemark
1Washing head with bottle neck hangingMade by our factory
2Filling valveMade by our factory
3Sealing headMade by our factory
4Touch screenSiemens
5TransducerDelixi
6PLCSiemens
7Approach switchAutonics
8Light fiber switcAutonics
9Pneumatic elementsAirtac


Company Information

Zhangjiagang Proman Machine Co. Ltd,is a production manufacturer and exporter specialized in water treatment plants,beverage filling machine, packing machine, bottle blowing machine, injection moulding machine and spare parts of filling line.
Our factory was established in the year of 1998, with the long history of accumulated experience in filling machine industry in south Jiangsu. There are many development engineers of filling machine in our company. We devote ourselves to the development, research and production of liquid food and beverage packing and filling industry.

Proman Machine cooperated with many customers in recent years, we win the trust of customers from our high-quality products. And we are looking forward to the future cooperation with you if our products can impress you deeply


Customer vist



Certifications




FAQ
1.How to tell us your enquiry?
:You can contact us by email, phone call, fax, Instant Messenger (Trademanager, WhatsApp, Skype) and let us know your requirement.
2.Where is your factory?
Our Factory is located in Zhangjiagang City, it is very near to Shanghai and Wuxi (airplame and train both available). If you arrive at Shanghai or Wuxi, we can pick you up to visit our factory.
3. Do you have any technical supports with your Beverage Filling Machines?
Yes, We have a professional team of engineers who owned many installation, debug and training experiences abroad, are available to service machinery overseas.
4.What's your guarantee or the warranty of the quality if we buy your machines?
We offer you high quality machines with 1 year guarantee and supply life-long technical support.


We Warmly Welcome Customers All Over The World To Our Company If You Have Interests In Our Products. Please Contact Us If You Have Any Problems.
