600cc Quad Bike

FOB Reference Price:Get Latest Price
8 Piece/Pieces (Min. Order)
Supply Ability:
1600 Piece/Pieces per Month
Port:
Shanghai
Report Suspicious Activity
Overview
Quick Details
Fuel:
Gas / Diesel
Displacement:
>300cc
Engine Type:
4 Stroke
Transmission Type:
Automatic
Transmission System:
Shaft Drive
Certification:
EEC & EPA
Brand Name:
Lannmarker
Place of Origin:
Shanghai, China (Mainland)
Model Number:
KINGMAX EX600
Fuel System:
Delphi EFI
Fuel Capacity:
18L
Cooling System:
Liquid-Cooled
Starting System:
Electric Start & Hand Pull Start
Final Drive:
Shaft Drive 4WD
Parking Brake:
Mechanics Parking Brake
Suspension Front:
Twin-A Arm Independent Suspension
Suspension Rear:
Twin-A Arm Independent Suspension
Brakes Front / Rear:
Hydraulic Disk Brake
Warranty:
12 Months
Packaging & Delivery
Packaging Details
Iron Framework & Carton
Delivery Time
25 Days

600cc Quad Bike, 600cc 4X4 Utility ATV













Lannmarker 600cc Utility ATV 4X4 Quad Bike with CVT Automatic Transmission



SPECIFICATION
ENGINE
Engine Type 2 Cylinder, V-Twin, 4-Stroke, SOHC
Engine Displacement 552cc
Bore x Stroke 70 X 71.7mm
Fuel System Delphi Electronic Fuel Injection
Cooling System Liquid-Cooled
Ignition ECU Control Start
Max. Power Output27kw/6500r/min
Max. Torque45N.M/5000r/min
Fuel Capacity 18L
Lubrication SystemSplash & Press
Starting SystemElectric Start & Hand Pull Start
Transmission ModeAutomatic CVT with H/L/N/R
Final DriveShaft Drive 4WD
Shift Switch(2WD/4WD)YES
Battery12V  14Ah
Wheels and Brakes
Tyres Front25X8-12
Tyres Rear25X10-12
ParkingMechanics Parking Brake
Suspension Front / RearTwin-A Arm Independent Suspension
Brakes Front / RearHydraulic Disk Brake
Dimensions and Weight
Product Dimension(LxWxH)2,150x1,195x1,210mm
Carton Dimension(LxWxH)2,300x1,370x865mm
Seat Height905 mm
Wheelbase1,295mm
Ground Clearance 250mm
Dry Weight365kg
Gross Weight440kg
Container Loading8 units/20'GP
26 units/40'HQ
