80Tons 90Tons 3 Axles Side Tipper Semi Truck Trailer

  • 1 - 4 Sets
    $14,300.00
  • >=5 Sets
    $13,400.00
Model Number:
Side Tipper Semi Truck Trailer
Lead Time:
Quantity(Sets) 1 - 3 >3
Est. Time(days) 25 Negotiable
Customization:
Customized logo (Min. Order: 1 Sets)
Graphic customization (Min. Order: 1 Sets)
Report Suspicious Activity
Overview
Quick Details
Use:
Truck Trailer
Place of Origin:
Shandong, China
Brand Name:
ZW-Trailer
Size:
11000*2500*3500mm
Type:
Semi-Trailer
Material:
Steel
Certification:
CE DOT
OEM No.:
Optional
Max Payload:
50T
Product name:
Side Tipper Semi Truck Trailer
Suspension:
Mechanical Suspension
Function:
Transport Heavy Duty Equipment
Axle:
13 Ton Fuwa Brand
Tire:
11.00r20 12r22.5
Color:
Customers Optional
Landing Gear:
Standard 28Ton
King pin:
2"(50mm)or3.5"(90mm) JOST
Axle Brand:
FUWA 13TON Axle
Name:
Simi Trailer
Supply Ability
Supply Ability:
200 Set/Sets per Month Semi Truck Trailer
Packaging & Delivery
Packaging Details
Nude Packing,small type can be put into 20'GP or 40'GP,big type can be carried by bulk carriers or ro-ro ship or according to your requirments.
Port
Any Port In China for Side Tipper Semi Truck Trailer
Lead Time :
Quantity(Sets) 1 - 3 >3
Est. Time(days) 25 To be negotiated





80Tons 90Tons 3 Axles Side Tipper Semi Truck Trailer



Product Description

Side Tipper Semi Truck Trailer mainly used in the transportation of earth, ore, building materials and other bulk cargo.With the hydraulic dumping system,it can realised self dumping saving both time and effort. Side dump type semi trailer  can discharge the cargo through the dide of the box.This special design are  aim to heavy duty vehicle,it can make sure the safety when discharge.

QQ20190807094618

 57

Trailer Parameters



Product name

Side Tipper Semi Truck Trailer

Overall Dimension

(L*W*H)mm

13000x2500x3630mm(height of cargo box is 600- 1800mm)

Loading capacity

60-80 ton

Axle

3*13 ton Fuwa Brand

Suspension

mechanical suspension with 10-pcs leaf spring (Optional: air suspension)

Main Beam

The height of the beam is 500 mm,upper plate is18mm,down plate is

18mm,middle plate is 10mm.

Side beam

20 channel or H steel

Steel sheet

Floor thickness 4mm, side wall thickness 3mm

Hydraulic Jack

Full of Chinese brand hydraulic system

Tire type and quantity

11.00R20 Chinese brand, 12pcs+1 spare tyre

King Pin

Adjustable king pin, size 50# (2'') or 90#(3.5’’)

Landing Gear

Standard 28T

Spare Tire Carriers

2 pieces

Tool box

One set standard

Brakes

Dual lines pneumatic brake system, (Optional: ABS); 6 air chamber; parking brake

Air/Elec. Connector

ISO standard air connector, 24V 7 pin plug socket

Tailgate

One-piece tailgate with upper articulation, safety lock system

Lights & Reflectors

Rear light, rear reflector, turn indicative light, side reflector, fog lamp, number plate light

Wiring

24V, 6 lines

Paint

1 coat of anticorrosive prime,twice coats of final paint.



Trailer Drawing

 Semi Truck Trailer

Our Services



1: Our company promise a one-year warranty period, during this period, under normal use if there is damage to the accessories, we will provide our customers with free new accessories.



2: Operational problems, technical configuration issues, etc., We will promptly provide feasible solutions for our customers. We are investing in the construction of a number of foreign service department, will be better to serve the global customers.



3: We are serious about after-sales service.

Truck Trailer

1.Q: Do you have your own factory?
   A: We have our own factory and we have 10 years experience in semi trailer production.We sincerely welcome you to visit our factory.
2. Q: Where is your factory located?
   A: Our factory is located in Industry Park, Liangshan Town, Jining City, Shandong province,China.
3. Q: How about the warranty?
   A: Our company promise a one-year warranty period, during this period, under normal use if there is damage to the accessories, we will provide our customers with free new accessories.

4. Q:If Customized Service Provided ?

A:Yes, Please Contact Our Sales Manger, We Can Offer Customized Service On Vehicle Design / Painting/Logo, Etc.

5. Q:If Our Vehicle/Trailer Can Couple With Your Tractor Head ?

A:You can tell me that you are using the Tractor/Primer Mover model or the distance between fifth wheel and the ground, we can design a height that matches your Tractor.

6. Whats The Time For Delivery ?

A: If standard model we have in stock can ship it out within 10 days after payment.

If uesd trailer or truck,we can ship it out within 10 days after payment. Because we have to renovate and paint it.

If it is a new production,ordinary cases in 20 days can be finished for shipment.

7. Q:If We Can Provide Terms For Reducing Your Import Duties ?

A:Yes, Please Contact With Us, We Are Nationalized Manufacture With Tax Reduction, Will Also Offer You The Best Way For Import Duty Reduction.

Main Parts Showing

 Side Tipper Semi Truck Trailer

The side dump semi-trailer is generally larger than the rear dump semi trailer. The general shape is like a slab and a van. The cargo volume is flexible and can be designed to have a large load range and is suitable for various transportations.

The side dump semi-trailer hydraulic cylinder can be selected: 110/130/150 model.

(1)The length is about 13 meters, the load is less than 60T, and the 110 model 5+1 hydraulic cylinder is used;

(2)The length is 15 meters, the load is less than 80T, and the 130 model 6+1 hydraulic cylinder is used;

(3)When the load reaches 100 tons or more, use the 150 model and select the X+1 hydraulic cylinder according to the length. Both sides can be dumped.

Packaging & Shipping

Shipping method: Ro-Ro, Bulk cargo, Container These three modes of transportation, we can provide customers with the most economical semi-trailer transportation plan according to the number of semi-trailers required by customers.

 Semi Truck Trailer

Our Customer

We welcome you to visit our factory, where you will find professional welding technology, and mature production workshops, you can also talk to our engineers to discuss important configurations. Looking forward to your visit.
Below is a photo of us and some of our customers.

Truck Trailer
