865-868Mhz Long Range UHF RFID OEM Reader Module PR9200

  • 5-49 Pieces
    $60.00
  • 50-199 Pieces
    $53.00
  • >=200 Pieces
    $45.00
Model Number:
FM-502A
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Customization:
Customized logo (Min. Order: 10 Pieces)
Samples: $60.00 /Piece, 1 Piece (Min. Order): Buy Samples
Contact Supplier
Samples - $60.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
fonkan
Product Name:
UHF RFID MODULE(PR9200 Chip)
Frequency:
902-928MHz/ 865-868MHz(Optional)
Air protocol:
UHF Class 1 Gen 2 / ISO 18000-6C
Data Output Range:
18-26 dBm
Interface options:
TTL Uart
GPIO:
2 In, 2 Out (3.3V electrical level )
Work voltage:
DC 3.5V~5 V
Work current:
260mA @ 3.5V(26 dBm Output,25°C). 110mA @ 3.5V (18 dBm Output,25°C).
Work Temp.:
- 20 °C - + 70 °C
Storage Temp.:
- 20 °C - + 85 °C

Packaging & Delivery

Selling Units:
Single item
Single package size:
10X10X5 cm
Single gross weight:
0.2 kg
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 5 6 - 200 >200
Est. Time(days) 5 20 To be negotiated

UHF RFID READER MODULE FM-502 PR9200 RF CHIP







FM-502 UHF RFID Embeddable Module Advantages:



  • PHY Chips PR9200 inside with outstanding performance and cost-effective.
  • Read distance with 3m above. (Tested with Impinj E41b inlay and 2dbi Antenna, 8dBi circular polarization panel antenna>8m, 12dBi Linear polariztion antenna>15m, multi-tag read ability>50 tags, tag read speed>50 tags/s
  • Stable performance with less affected by rising temperature.
  • Super low power consumption; no additional cooling devices required.
  • Good consistency in terms of RF parameters.
  • Simple peripheral circuit design(refer to 4-1: circuit design reference)
  • Full compatible with different communication interfaces of HUAYUAN INDY R2000 series products.

FM-502 Moudle Parameter:

Operating voltage

DC 3.5V – 5 V

Standby current

<80mA (EN Feet high level)

Sleeping current

<100uA (EN Feet low level)

Operating current

260mA @ 3.5V (26 dBm Output,25°C).

110mA @ 3.5V (18 dBm Output,25°C).

Starting time

<100mS.

Operating temperature

 - 20 °C  -  + 70  °C

Storage temperature

- 20 °C  -  + 85  °C

Operating humidity

< 95% ( + 25 °C)

The air interface protocol

EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C

Work spectrum range

902Mhz – 928Mhz

865MHz – 868MHz(Optional)







Working area support

US, Canada and other regions following U.S. FCC

Europe and other regions following ETSI EN 302 208

Mainland China

Japan, Korea, Malaysia

Taiwan

Output Power Range

18-26 dBm

Output power precision

+/- 1dB

Output power flatness

+/- 0.2dB

Output RFID connector

I-PEX

Receiving sensitivity

< -70dBm

Peak speed of inventory tags

> 50tags/Second

Label buffer

200 PC labels  @ 96 bit EPC

Tag RSSI

support



Communication interface

TTL Uart interface

Wigan 26

Wigan 34

GPIO

Two route enter two route output (3.3 V level)

Communication baud rate

115200 bps(Default and recommended)

38400bps

heat-dissipating method

Air cooling (Without extern set heat sink)

















Shenzhen Fonkan Technology Co., Ltd. was established in 2016. We are a professional UHF RFID hardware(Reader/antenna/tags) provider. We have our own R&D team and production workshop in Shenzhen, China. We are committed to providing our customers with quality products and services that help them build their successful RFID cases and solutions. Our customers are located all over the world, we provide reliable products and excellent services, continue to create value for our customers, inspire their creativity, and provide innovative RFID solutions and applications to the world.



In Fonkan you can get:

1. High quality and reliable products

2. Cordial and continuous service

3. Committed fast delivery

4. Adequate after-sales support



We believe that creating value for customers, serving with heart and developing together is the best choice for the company. We are willing to be your most reliable long-term partner.





       Web: https://fonkan.en.alibaba.com                                     Skype: shaokun_sk
      E-mail: kevinshao(at)fonkan.com                                         Wechat: kevinlusia
      Tel: +86-755-2320 2996                                                     Mobile: +8613902961040










FAQ



1, Q:Who are we?
A:We are a leading Chinese professional UHF RFID Hardware manufacturer with more than 10 years. We are
located in Shenzhen, a city near to HongKong.


2, Q: What products do you manufacture?
A: we can be able to manufacture all kinds of UHF RFID reader, antenna and tag (comply the protocol of EPC
C1G2 and ISO-18000/6C). we can help you customize all kinds of reader, antenna and tag.


3, Q: What are your advantages?
A: we have many advantages.
Firstly, we have been focusing on R&D, productions, sales and implementation of UHF RFID reader, UHF RFID
antenna and UHF RFID Tag for more than 10 years.
Secondly, we are good at designing all kinds of RFID solution for different industries or applications.
Thirdly, our products has been sold to all over the world, they are serving for government, big retailer,
school, big manufacturing company and logistic company as well as vehicle managmenent/transportation etc.
Fourth, we have own professional staffs in RFID, no matter what production, research or engineer or sales.



4, Q: What are your client type?
A: As a RFID hardware manufacturer, we usualy work with system integrator, solution provider or IT software
company directly because we can supply hardware to them and they can develop software and
implement/install/integrate hardware and software for their end-user directly.



5, Q: If I want to buy your products, what should we do first?
A: as RFID product is complex system (need further development), so you need to tell us your project
requirement, for example,
what is the tracked item?
What is the reading distance required?
What type of reader do you want to use on your project?
Fixed reader or handheld reader?
After we are clear your requiements, we will send you datasheet and quotation for your reference.
After confirming well, we will send you PI for paying fund to us and then we will send you goods ASAP once
we got your payment already.



6, Q: Do you supply software?
A: we don’t have any management software, but we have SDK of readers for your further developing interface
with your current management software.
