8km Wireless Car Parking Space Lock Automatic Manual Suppliers

FOB Reference Price:Get Latest Price
$230.00 - $280.00 / Set | 1 Set/Sets (Min. Order)
Height (mm):
440
Width (mm):
380
Parking lot:
1
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
KINO.S
Model Number:
KS-R-05
Type:
smart car parking
Warranty:
1
Product Name:
smart car parking
Motor working voltage:
3.6V
Battery:
3.6V-38Ah-rechargeable Li/SOCl2 battery
Battery life:
>5 years in the frequency of 4 times per day, family use
Service life:
>500,000 times
Working power:
<3.6mW
Communication:
LoRaWAN wireless(overseas) NB-IoT wireless(China domestic)
Wireless communication distance:
≤8km(without obstruction)
Protection class:
IP67
Product dimension(W*D*H):
380*440*355mm Ascending 380*440*66mm Descending
Supply Ability
Supply Ability:
1000 Set/Sets per Month
Packaging & Delivery
Packaging Details
Carton
Port
Guangzhou
Video Description

8km Wireless Car Parking Space Lock Automatic Manual Suppliers

Product Description



· Ksmart parking reservation lock is installed in front of parking space. When it goes up, it can block space from being occupied.

· Working with APPs, it can be used for car parking space reservation, outdoor parking guidance system, etc.

· It also works with gateway. One gateway can manage all parking locks within 8 square kilometers.

· Installed in front of parking bay, when space is available, it will rise to protect unauthorized parker from parking there.

· Remarks: It cannot lock vehicle.



Motor working voltage

3V

Battery

3.6V-38Ah battery

Battery life

3 years at the working frequency of 10 times per day.

5 years at the working frequency of 4 times per day.

Service life

>500,000times

Working power

3.6mW

Standard by current

10uA

Communication

Lora

Lifting speed

3-5S

Lifting height

355mm

Descending height

66mm

Material

ABS G30, thickness 8mm

Control method

APP control or Bluetooth activated sensor

Ingress protection

IP67

Working temperature

-20℃~+60℃

Dimension

380(L)*440(W)*66(H)mm

Packaging

400*470*12.5mm

Weight

5KGS



Features of parking reservation lock

· Occupancy detection. Build in vehicle detector, real time monitor occupancy status. Backend software monitor and management simultaneously.

· Dual communication option. “NB-IoT”wireless communication for China domestic market, while“LoRaWan” for overseas market.

· Low power consumption pure battery power. Unique low power consumption circuit design, purely battery power. Theoretically  service life more than 5 years under normal use (family use, 4 times/day), no need for power grid, easy installation and save construction cost.

· Abnormal self diagnosis. Self diagnosis of battery capacity, up/down process, arm in position/over position. Buzzer alarm in abnormal status, and interface prompt in backend software.

· Remote control. Multi remote control ways, like Bluetooth, mobile App and backend control.

· Anti-collision. 180° degree front and back anti-collision. Go back if blocked when ascending and go down along hit direction.

· Waterproof. Unique seal design, working properly even sinking in water.

· Anti-crush. 360° degree direction anti crush, weight resistant up to 3 tons from different direction.

· Dust-proof. High degree seal design for completely dust proof.

· Protect from occupancy. Buzzer alarm and backend alarm if unauthorized park or vandalism.

· Anti-theft. Bolts are installed inside the device. High strength housing material. Without keys, it cannot open cover to dismantle key.
