Ac/Dc Adaptor Input 100 240vac Output 5va 6v 100ma 300ma 0.3a 0.4a 400ma 500ma 600ma 1a Power Adapter With 3 Years Warranty

Feedback Ratings
  • 1-99 Pieces
    $3.50
  • >=100 Pieces
    $2.50
Quantity:
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
12 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
YHY
Model Number:
YHY-WL-060yyyy
Output Type:
DC
Connection:
Plug In
Product Name:
240v 220v 110v ac to 6v 500ma 600ma ac dc power adapter
Input Voltage:
100-240Vac
Input Frequency:
50/60Hz
AC Plug:
Plug in Type
DC Cable:
4 Feet
DC Wire:
2464/2468/26AWG
Output Voltage:
6V DC
DC Dimension:
OD5.5*ID2.1*L10mm
Usage:
Swithing

Packaging & Delivery

Selling Units:
Single item
Single package size:
11X11X11 cm
Single gross weight:
0.2 kg
Package Type:
Inner Box+Carton
Lead Time :
Quantity(Piece) 1 - 100 >100
Est. Time(days) 12 To be negotiated

Ac/Dc Adaptor Input 100 240vac Output 5va 6v 100ma 300ma 0.3a 0.4a 400ma 500ma 600ma 1a Power Adapter With 3 Years Warranty

Detailed Images
Specifications
Input Voltage RangeVAC100-240Vac 50/60Hz
Input Current(Max)A0.5A(100VAC Input)
Power Factor-Meets EN61000-3-2
Temperature Coefficient±0.05%/℃
Voltage Accuracy%±2%
Adjustment Range-None
Min. LoadANone
Total Regulation-±5%
Ripple & NoisemV120mV
Short Circuit Protection%Continuous - hiccup mode
Over Voltage Protection110-150% of nominal (Cycle input power to reset)
Efficiency at Average Load-88% min
Operation Temperature-0 to +60℃, derating linearly to 50% load above 40℃
Storage Temperature--10 to +85℃
Humidity (non condensing)-10-90% RH
Cooling-Convection
Withstand Voltage-Input to Ground 1.5kVAC, Input to Output 3kVAC (Output is connected to Ground)
Vibration (non condensing)-23.52m/s2 (10 - 55Hz: constant sweep 1 min X, Y, Z for 1 hour)
Shock-< 196.1 m/s2 (20G)
Safety Agency Certifications-UL60950-1, EN609501-1, IEC60950-1, CE Mark
DOE Regulation-VI
Off-Load Power ConsumptionmW<210mV
Conducted & Radiated EMI-EN55023-B, FCC Class B
Immunity-EN55024
WeightG110g
Size(WxLxH)mm68x40x48mm
Cable Length and Thicknessmm1200mm
AC Input Connector-EU/US/AU/UK/KR/JP/CN AC Plug (Accept more request)
Output Connectormm5.5x2.1mm (Accept more request)
MTBF 100%, 25℃Hours50,000 hours
WarrantyYears3 years



POWERMODELINPUTOUTPUT AC
VoltageCurrentPlug-in
  5W SeriesYHY-05001000100-240VAC5V1.0AAU
EU
UK
US
KR
JP
Interchangeable
YHY-060010006V1.0A
YHY-090006009V0.6A
YHY-1200050012V0.5A
YHY-1500040015V0.4A
YHY-2400025024V0.25A
12W SeriesYHY-05002500100-240VAC5V2.5AAU
EU
UK
US
KR
JP
Interchangeable
YHY-060020006V2.0A
YHY-090013009V1.3A
YHY-1200100012V1.0A
YHY-2400050024V0.5A
YHY-3000040030V0.4A























































Shipping&Payment

Packing:

  • Packaging Details:White Box+Carton or as customer's requirement.
  • v Size: 51*39*17.2CM

    v Qty:100PCS/Carton

    v Weight:11KG/Carton

    v Package : Carton and White Box

    v OEM Package Design

Payment:

  •  T/T in advance, Paypal, Western Union,Visa and Trade Assurance

Shipping:
  •  The delivery time is strarting from we confirm the payment.
  •  In case of delay the delivery,so hope you charge it as soon as possible .
  • Exact lead time is based on your amounts and fact. so you'd better show me your exact qty,not uncertain
  • Some delivery time as follow:
  • Qty

    (pcs)

    Delivery Time

    (working days)

    less than 100

    5-7

    100-800

    7-10

    800-3K

    10-12

    3K-10K

    15-18

    10K-20k

    20-22

    *Data is a reference for buyer, Specification situation will be given to you after asking us.

    Remark

    1.Samples (less than 10pcs) can be provied, lead time with 3days.

    2.Please carefully check all the details before you take a order.



Company Information

YHY Power

ShenZhen YingHuiYuan Electronics CO.,LTD is a professional manufacturer of switching power supply manufacturers, independent research and development, production and sales agencies; company's complete product specifications and curvaceous design of the company's products in strict accordance with the standards of safety: CE CB GS EK PSE FCC UL certified production.  Being exported to over 50 countries such as and regions for 8 years,UK, US, France, Germany, Poland, Canada, South Africa, Spain,Italy,Argentina.  Israel,Malaysia.



The British the hui source power covers all small power AC and DC power adapter, special power and various types of battery chargers.



FAQ

 1.Q: Do you offer samples for testing?

A: Yes,we offer samples for testing with cost paid by buyer.Besides we welcome our customers to take sample as we believe seeing is believing.

2.Q: What's your MOQ?
A:we have no moq if stocked and 2000pcs if OEM order.

3.Q:Do you have warranty?
A :Yes,we have warranty of 1 year period.

4.Q:Do you have certificates for your products?
A:Yes,we have UL/CUL,FCC,RoHS,CE,KC,SAA,TUV GS Certifications.

5. Can you design the new housing based on our design?
A: We can design. one week make up sample. 30days sample test 45days start to MP?

6. What's the main product of you factory?
A: We are the supplier for 0-500W global power adapter, including wall plug adapter,usb adapter/charger,desktop adapter, metal case switching power supply,led power supply, waterproof power supply,led driver,open frame power supply and ect.

7. Do you have some new product coming?
A: We will design more and more new product with differenct high quality.

8.Q: What's your payment item?

A: Our standard payment is T/T in advance, Paypal and Western Union.

Our Services
  • Your inquiry related to our products or prices will be replied in 24hrs.
  •  Well-trained and experienced staffs to answer all your enquires in fluent English
  • OEM&ODM, any your custo mized lightings we can help you to design and put into product.
  • Distributoership are offered for your unique design and some our current models
  • Protection of your sales area, ideas of design and all your private information
