African popular type double layer 950 / 1000 Metal roof slate, shake roll forming machine for galvanized tile

FOB Reference Price:Get Latest Price
$7,500.00 - $12,500.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
Tile Forming Machine
Production Capacity:
10-15m/min
Power(W):
4+4KW
Certification:
ISO CE
Condition:
New
Tile Type:
Colored Steel
Use:
Wall
Place of Origin:
Hebei, China (Mainland)
Brand Name:
Dongchang
Model Number:
Roll Forming Machine
Voltage:
380V 50Hz 3phases
Dimension(L*W*H):
6800*1550*13500mm
Weight:
5.2T
Control system:
totally automatic PLC control system
material of rollers:
45# forged steel,with hard chrome plating
Shaft material:
45# steel, quenched
Material:
color steel
Cutting blade material:
Cr12 mould steel with quenched treatment
Thickness of the plate:
0.2mm-0.8mm
suitable to process:
color steel plate,PPGI,galvanized steel sheet, Aluminum plate
feature:
high speed, low energy consumption
Roller:
10-12 rows
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
12 Months
Supply Ability
Supply Ability:
200 Set/Sets per Month
Packaging & Delivery
Packaging Details
1.Tighten to container with steel wire rope and welded angel iron.
2.Main forming machine and unciler is naked (if you need we can also packed with water-proof plastic)
3.Roll forming machine PLC control system and moter pump are packed with water-proof plastic coverage.
Port
Tianjin
Lead Time :
Within 10-20 working days after receipt of deposit

 lets talk more online



Parameters of machine

ItemsParametersPicture

Suitable material

Color steel plate, galvanized sheet, and etc.

0.3-0.8mm thickness



Feeding width

1000mm



Effective width

828mm



Shaft

high grade 45# steel heated and quenched cylindrical grinding

Diameter of shaft 70mm

Electroplate coating  0.04-0.05mm

Roller

high grade 45# steel heated and quenched hard chrome coated 0.05mm

13 rows

Electroplate coating 0.04-0.05mm



Chain

1.3 inch

Chain transmission

Frame

400H steel



Middle plate

16mm thickness

steel plate welding

Dimensions

5700*1500*1200mm



Product Overviews

1 set of manual decoiler



Un-coiler

Single head;
Max. Capacity: 5000kg;
Coil inner-diameter: 508mm

1 set of main roll forming machines





Steps: 16

Roller Material: 45# steel
Voltage: 380V/50Hz.

Line speed: 12m/min;
Rolling chromium thickness: 0.05 mm

1 set of computer control cabinet





It adopts Taida PLC to control. The target piece length is adjustable and digit of it can be adjusted.  It contains transducer, which can ensure the accuracy of length is

± 1mm.

5.7 inch touch screen, easy to operate

Computed mode has two modes: Automatic and manual one.

1 set of hydraulic System





It is controlled by gear wheel oil pump. After filling the hydraulic oil into the hydraulic oil tank, the pump drive the cutter machine to begin the cutting job.
Match equipment: A set of hydraulic tank, a set of hydraulic oil pump, two hydraulic pipes and two sets of electromagnetism valves.
Power of the oil pump: 3kw Hydraulic oil: 40#

1 set of cutting mechanism





It adopts hydraulic drive and automatic location to decide the dimention and cut the target products.
Match equipment: One set of cutting tool, one hydraulic tank, one cutter machine.
Stop to cut, Post cut cutting length tolerance: ± 2mm
Cutting tool material: GCr12 with quenched treatment 60-62° C

1 set of counter





One counter gauges length, pulses, and decides length

1 set of output table



It used to load the finished products



Our main products:



1corrugated/ trapezoid/ glazed roof making machine
2floor deck roll forming machine
3highway guardail roll forming machine
4C/Z/U Purlin roll forming machine
5curving machine/ arch machine
6EPS sandwich panel roll forming machine
7C/Z/U roll forming machine
8

sheet bending/shear machine




If you have any questions for the Roofing roll forming Machine, send your Inquiry Details in the Below, Click "Send" Now!We will be 24 hours services for you.
