Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line
with water cooling, turbo-charging & intercooling
Displacement: 9.726 liters
Mean Position Speed: 9.53m /s
Specific fuel consumption: 198g /Kwh
Gear box: HW19710
Clutch: Φ430 pull-type diaphragm clutch
Front axle: HOWO Front axle 7t
Rear axle: HW1697
Tyre : 12.00-20 (rim: 8.0-20)
No of tyre: 10+1
Max. speed (km/h): 102
Max. gradeability(%): 28
Kerb. mass: 11000 kg
Total mass: 25000kg
Wheel base (mm): 4325+1350
Fuel tank(L):400 Aluminium Alloy Tank
Front overhang (mm):1500
Rear overhang (mm): 2600
Front track (mm): 1958
Rear track (mm): 1830
Approach angle: 16 degree
Departure angle: 15 degree
Dimension (mm): 9800X2480X3210
Capacity of tank: 18m3(including Pump)
Material: Q235B Normal black Steel metal sheets of in down of in down 5mm and side 4mm thickness
Tanker has 3 connectings sections and flaps for filling and essential valve and taps with all required connecting
Discharge Opening: DN80
No. Compartimenter: 5
l Ladder fixed on tank
l Tank to be coated with epoxy from outside to resist all climate factors, sun heat and oil product
l A place for fire extinguisher 12 kg capacity.
l Pump group with metering box to be present on right side of tank in metal box.
l Flow not less than 100 L/Min vertically @ 50 m height.
l Pump to work for discharge and suck to other tanks.
l Pump group to have non return valve.
Packaging & Shipping
Q1. Are you factory or trading company ? we are trailer factory and we also do trading of heavy duty trucks and machineries.
But we have acquired export authorization form, we are the distributor of Sinotruk, Shacman, BEIBEN, for their overseas business. The price you get is very completetive in same specifiation and we confirm all original quality. Q2. What’s the MOQ ? Normally, If the items are in stock,there is no MOQ. The quantity is according to the clients requires. Q3.Which payment can be acceptable ? We could accept the payment by T/T, L/C, D/P, D/A, Cash etc. Q4. How about your delivery time? A: Generally, within 30 days after receiving your advance payment. Depend on the quantity. Q5. How about your company's service, especially after-sale service? A: We have been in this field for nearly 20 years and has strong distribution capability, and after-sales service. We also have four branches oversea for management, sale and maintenance.
Q6: I want to transport the truck by container, is it ok?
A: Yes, it is ok . SCD is avaible. But we need take apart the truck/trailer/machinery.You should reinstall in your country. For some high sea freight charges Destination port, it is suitable.
Q7:How about your product quality?
A: All our spare parts are from the original manufacturers, the quality is 100% guaranteed.
Q8:I want to be your agent in my country , is that ok?
A:It’s ok, If your quantity is big, we will consider. For the first time 50 units is ok.
Q9: I want the front two tyres are bias tyre and the rear 9 tyres are radial tyres, is it ok?
A: We can make the tyres as your requirement to suit your country's need.
