Aluminum high precision ball screw linear rail guide

  • 5-9 Pieces
    $896.00
  • 10-49 Pieces
    $851.00
  • 50-99 Pieces
    $806.00
  • >=100 Pieces
    $762.00
Guide Width or Diameter:
120mm
Guide Length:
1800mm
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
12 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Applicable Industries:
Hotels, Manufacturing Plant, Food & Beverage Factory, Farms, Restaurant, Home Use, Retail, Construction works , Energy & Mining, Advertising Company
Model Number:
FSL120E1800
Place of Origin:
Sichuan, China
Brand Name:
FUYU
Material:
Aluminum
Drive Type:
Ball Screw
Horizontal Load Capacity:
100kg
Vertical Load Capacity:
50kgs
Without loading speed:
400-650mm/s
Position Accuracy:
0.05mm
Motor holding torque:
7N.m
Maximum thrust:
1572N
Max Honrizontal Full Speed:
360-600mm/s
Max Vertical Full Speed:
350-450mm/s
Movement Life:
30000km

Packaging & Delivery

Selling Units:
Single item
Single package size:
235X21X22 cm
Single gross weight:
33.8 kg
Picture Example:
package-img
Lead Time :
Quantity(Piece) 1 - 5 6 - 10 11 - 50 >50
Est. Time(days) 12 21 30 To be negotiated
Video Description
Product Description

Ball screw linear guideway

FUYU  FSL120 Series

FSL120 linear module, fully enclosed structure, body width 120mm, two guides and four sliders, with high precision, multi-segment repeat positioning, compact structure, strong versatility, suitable for use in special environments.


Range of application:

It can be used in combination with single or multiple axes. It is easy to match the required workpieces in various industries and it becomes a simple and practical mechanical arm. It is mainly used in dustfree workshops or special fields such as electronics and medical equipment, such as film, Depreciation, IC printing, CCD on-line inspection, precise positioning detection of soldering automation equipment, laser plus(laser cutting/laser marking/laser engraving/laser drilling,etc.) precision assembly, precision machine tools, semiconductor production equipment, location detection, electronic production equipment , and 3D printing equipment and other fields.

TECHNICAL PARAMETER
Motor holding torque
7N·m
Ball Screw Diameter
φ20mm
Ball Screw Stroke
20mm
Max Horizontal Loadings
100kg
Max Vertical Loading
50kg
Without Loading Speed
400mm/s
Max Honrizontal Full Speed
360mm/s
Max Vertical Full Speed
270mm/s
Rated Acceleration
1000mm/s2
Position Accuracy
0.05
Maximum thrust
1572N
Dynamic Permissible Torque
MA=550         MB=390        MC=390
Movement Life
30000km

Main Features

1) Fully enclosed structure, suitable for use in special environments.

2) Body width 120mm with high precision.

3) Two guides and four sliders.

4) Strong versatility, compact structure.

Mechanical Dimension
Motor Parameter
3-phase Nema 34 Stepper Motor
Model: FM86128SJT03
Motor
Specs
Step angle
1.2°
Torque
7N.m
Current
3A
Length
128mm
Lead
3
leads Weight
4kgs
Detailed Images





Nema 34 stepper motor

to provide good power








Alu.made panel to support

loading up to 100kgs






Alu.body + Steel belt

offer excellent rigidity






M6 screws at the baseboard

for easy installnation
