Amensolar Hot sale High efficiency mono 385w solar panel for home with 72 cells solar panel system

  • >=100 Watts
    $0.34
Material:
Monocrystalline Silicon
Max. Power:
375W
Number of Cells:
72 pcs
Lead Time:
Quantity(Watts) 1 - 2000000 >2000000
Est. Time(days) 7 Negotiable
Customization:
Customized logo (Min. Order: 1000000 Watts)
Customized packaging (Min. Order: 1000000 Watts)

More

Graphic customization (Min. Order: 1000000 Watts) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangsu, China (Mainland)
Brand Name:
Amensolar
Model Number:
LS-M72-385-P
Type:
Standard Solar Panel
Size:
1656*992*40mm
Maximum system voltage:
1000/1500 V DC
Operating temperature:
-40℃~+85℃
Weight:
22.5kg
Maximum series fuse:
15 A
Maximum load (snow/wind):
5400 Pa / 2400 Pa
Open Circuit Voltage Voc(V):
47.66
Short Circuit Current Ioc(A):
10.3
Module Efficiency (%):
19.33
Modules per box:
20 pcs.(40mm)
Modules per 40' HQ container:
638pcs.(40mm)
Supply Ability
Supply Ability:
1000 Milliwatt/Milliwatts per Year
Packaging & Delivery
Packaging Details
Modules per unit 27pcs.(40 mm)
Modules per 40' HQ container 638 pcs.(40mm)
Port
Shanghai
Lead Time :
Quantity(Watts) 1 - 2000000 >2000000
Est. Time(days) 7 To be negotiated
Product Description
Related Products
Key Features

Electrical Specifications (STC)

Model
LS-M72-375-P
LS-M72-380-P
LS-M72-385-P
Maximum Power (Pmax)
375
380
385
Power Tolerance (W)
0~+3
0~+3
0~+3
Open Circuit Voltage(Voc)
47.66
47.77
47.89
MPP Voltage(Vmp)
38.22
38.31
38.4
Short Circuit Current(Isc)
10.03
10.41
10.52
MPP Current(Imp)
9.82
9.92
10.02
Module Efficiency (%)
19.33
19.58
19.84

Mechanical Specifications

Model
Data
Cell Type
12BB Mono 156.75×156.75mm
No. of Cells
72(6×12)
Dimensions
1656×992×40mm
Weight
22.5kg
Glass
3.2mm, Low Iron Tempered Glass
Frame
Anodized Aluminium Alloy
Junction Box
IP67/68, 3 diodes
Output Cables
4mm2, Length 900mm
Connector type
MC4 compatible

Temperature Specifications

Item
Data
Operating Condition
Data
NOCT
45℃ ±2℃
Maximum System Voltage
1000V/1500 VDC(TÜV)
Temprature Coefficient (Pmax)
-0.40%/K
rating Temperature
-40℃~+85℃
Temprature Coefficient (Voc)
-0.29%/K
Maximum series fuse rating
15A
Temprature Coefficient (Isc)
0.04%/K
-
-

Packaging Specifications

Packing unit
27pcs.(40mm)
Modules per 40'HQ container
638pcs.(40mm)

Remark

Tolerance
±3%(Vmp,Imp,Voc,Isc)
STC
Irradiance 1000W/㎡,Cell Temperature25℃,AM1.5
Company Profile
Exhibition
Certifications
Packing & Delivery
Packing Unit
27 PCS (40mm)
Modeles per 40 HQ container
638 pcs (40 mm)
FAQ


Q1: What are your main products?
Solar panel, solar inverter, energy storage battery, solar cable, solar energy system, and all the related soar power accessories.

We can provide design and construction for whole solar energy system.

Q2: Are you a factory or trading company?
We are a manufacturer with export license, and a leading company in the global solar photovoltaic field.

Q3: What certifications do you have?
TUV, CE, MCS, INTERTEK, SA, JET, CQC, ROHS, ISO, PV CYCLE, etc.

Q4: How can you provide after-sale service?
We can offer you timely and best after-sale service provided by our globalized branches and after-service centers around the world.

Q5: Could you print our logo on package and do OEM?
Yes, we can do it according to your requirement.
