Anti Rodent Fibra Optica Gyta Gyts Steel Tape Layer Mm 50/125 576 Core loose tube cable fiber optical For Conduit Aerial or Duct

  • 1 - 9 Kilometers
    $0.14
  • >=10 Kilometers
    $0.13
Length:
1~10000km
Lead Time:
Quantity(Kilometers) 1 - 10000 10001 - 100000 >100000
Est. Time(days) 7 30 Negotiable
Customization:
Customized logo (Min. Order: 1 Kilometers)
Customized packaging (Min. Order: 1 Kilometers)

More

Graphic customization (Min. Order: 1 Kilometers) Less
Samples:
$1.00 /Kilometer | 1 Kilometer (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
FEIBOER or OEM
Model Number:
GYTS
Number of Conductors:
≥ 10
Brand Name::
Feiboer or OEM
Product name:
36 core single core sc fiber optic cable multimode
Key words:
fiber optical
Package:
Plywood Reel/customized
Jacket Material:
PE PVC LSZH HDPE
Certification:
CE/ROHS/ISO9001
Central strength components:
steel wire
Application:
Long distance/LAN communication/Outdoor communication
Fiber Type:
G657/G652/G655/62.5/50/OM3/OM2
Cable Diameter:
8.8-14.6mm or on your request
Supply Ability
Supply Ability:
1000000 Kilometer/Kilometers per Month
Packaging & Delivery
Packaging Details
wooden drum ,iron-wooden drum with fumigated or not
2KM per drum,3KM per drum,4KM per drum
Port
Shenzhen,Guangzhou,Ningbo,Shanghai
Picture Example:
package-img
package-img
Lead Time :
Quantity(Kilometers) 1 - 10000 10001 - 100000 >100000
Est. Time(days) 7 30 To be negotiated
Video Description

Anti Rodent Fibra Optica Gyta Gyts Steel Tape Layer Mm 50/125 576 Core loose tube cable optic fiber For Conduit Aerial or Duct

Product Description



Loose tube stranded armored fiber optic cable (GYTS)

Product Description

The structure of GYTS optical cable is to put 250µm optical fiber into the loose tube, which is made of high modulus material, and filled with waterproof compound. In the center of the cable core is a metallic strength member,Tubes (and fillers) are stranded around the strength member into a compact and round cable core, which is filled with the waterproofing compound to protect it from water ingress. Plastic coated steel tape (PSP) is longitudinally wrapped and extruded into a polyethylene sheath to form a cable.



 Product Characteristics

•  With good mechanical properties and temperature characteristics

•  Material of loose tube has good hydrolysis resistance and high strength

•  The loose tube is filled with special gel, which protect the optical fiber

•  Specially designed compact cable structure to effectively prevent casing from retracting

•  Anti-UV PE out sheath

•  Take the following measures to ensure the waterproof performance of the optical cable

- Single steel wire center reinforced core

- Filled with special Water-blocking material in loose tube

- Complete cable core filling

- Moisture-proof layer of plastic-coated steel tape (PSP)

 Optical Fibre Performance

Type

Attenuation(+20℃)

Bandwidth

Numerical     aperture



Cut-off wavelength

@850nm

@1300nm

@1310nm

@1550nm

@850nm

@1300nm

G.652

---

---

≤0.36dB/km

≤0.22dB/km

---

---

---

≤1260nm

G.655

---

---

≤0.40dB/km

≤0.23dB/km

---

---

---

≤1450nm

50/125µm

≤3.3dB/km

≤1.2dB/km

---

---

≥500MHz·km

≥500MHz·km

0.200±0.015 NA

---

62.5/125µm

≤3.5dB/km

≤1.2dB/km

---

---

≥200MHz·km

≥500MHz·km

0.275±0.015 NA

---

 Technical Performance

Model

Fiber    count

Tube     count

Filling   rope count

Weight

(kg/km)

Tension

Long/Short term
(N)

Crush

Long/Short term
(N/100mm)



Bending Radius Static / dynamic

(mm)

GYTS-2~6Xn

2~6

1

4

96

600/1500

300/1000

10D/20D

GYTS-8~12Xn

8~12

2

3

96

GYTS-14~18Xn

14~18

3

2

96

GYTS-20~24Xn

20~24

4

1

96

GYTS-26~30Xn

26~30

5

0

96

GYTS-32~36Xn

32~36

6

0

105

GYTS-38~48Xn

38~48

4

1

111

GYTS-50~60Xn

50~60

5

0

111

Environmental Characteristics

• Transport/storage temperature: -40℃ to +70℃

Application

• Pipeline,Aerial,Direct buried
