Automatic Rotary Premade Pouch Packing Machine

FOB Reference Price:Get Latest Price
$25,000.00 - $50,000.00 / Set | 1 Set/Sets (Min. Order)
Power:
1.5kw
Model Number:
RZ8-200/300
Report Suspicious Activity
Overview
Quick Details
Type:
Multi-Function Packaging Machine
Applicable Industries:
Food & Beverage Factory
Condition:
New
Function:
Filling, Sealing
Application:
Food, Machinery & Hardware
Packaging Type:
Bags, Pouch
Packaging Material:
Plastic
Automatic Grade:
Automatic
Driven Type:
Electric
Voltage:
380V
Place of Origin:
Zhejiang, China
Brand Name:
rezpack
Dimension(L*W*H):
1475*1325*1480
Certification:
CE
Warranty:
1 YEAR
After-sales Service Provided:
Free spare parts, Online support, Engineers available to service machinery overseas
type:
Automatic Premade Pouch Rotary Packing Machine
certification:
CE
Driving power source:
380V Three-phase Five-line 50HZ
Packing speed:
20~55bags/min
Supply Ability
Supply Ability:
30 Set/Sets per Month
Packaging & Delivery
Packaging Details
before the shipment we will packing the machine in wooden case then loading in container
Port
any port in China
Product Description

Automatic Rotary Premade Pouch Packing Machine

Application Range:

1.Solid: leisure food(candy chocolate)etc;

2.Grain: condiment(monosodium glutamate, chicken essence, granulated sugar) dry fruit (nuts), capsule,grain medicine, seed, feed etc;

3.Powder: condiment, monosodium glutamate, salt, glucose,narrowly sugar, milk powder, washing powder etc;

4.Lquid: yellow wine, soy sauce, rice juice, drink, detergent etc;

5.Thick liquid: ketchup, peanut butter, sauce, chill sauce, bean butter etc;

Bag Types:

Standup bag, Portable bag, Zipper bag, 4-side sealing bag, 3-side sealing bag etc. and all kinds of compound bags.

Main Technical Parameter:

RZ8-150S Intelligent Rotary Packaging Machine

Equipment ModelRZ8-200CRZ8-300C
Bag SizeW:75~200mm L:100~300mmW:160~300mm L:100~400mm
Filling Range10~1500g10~2500g
Packing Speed20~60bags/min (depended on the product and filling weight)10~45Bags/min(depended on the product and filling weight)
Package AccuracyError≤±1%
Weight1000kg2000kg
Dimension1570mm*1440mm*1480mm (L,W,H)1830mm*1650mm*1800mm (L,W,H)
Total Power3kw3.8kw



Station Process:

1.Bag Feeding 2.Date Coding 3.Bag Opening 4.Filling 5.Filling 6.Standby 7.Heat Sealing 8.Forming & Output

Main Features:

1.Wide application : various shapes, state and nature of products (such as rice, coarse grains, nuts, spicy snack, Chinese chestnut liquid, etc.)

2. Easy to operate: PLC controller HMI system makes easy operation.

3. Easy to adjust: Synchronously adjust machine clamp, and parameters for different products can be saved and available from database when changing products.

4. High Automation: Complete all actions by end cam, whose machining technology is more simple than grooved cam, thus cost lower. The highest speed can reach 60pcs/min

5.Perfect Prevention System: when the bag is not open or not opened enough, it will be non-filling and non-sealing, so the empty bags return to the first station to refill and not wasted and it will save the production cost.

6. Stainless steel/other materials ensure sanitation and safety, meet the GMP standard.

7. Oil-free vacuum pump: avoid production environment pollution.

8. Waterproof Design: direct water-washing the machine surface, easy to clean, prolong the useful life.

9. Premade bag packing: high sealing quality, upgrade the finished product.

10. Adopt concentrated oil-supplied lubrication device inside the grooved cam. time, mechanical actions are controlled by end cam and tension springs, empty bag cycline.

Auxiliary Equipment:
