Built-in power adapter board 700tvl sony ccd zoom camera module with 30x optical focus OSD menu

Feedback Ratings
  • 1-39 Pieces
  • >=40 Pieces
- + Pieces available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
7 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Model Number:
Special Features:
zoom camera module
Image sensor:
1/3" Sony CCD
Horizontal Resolution:
700TVL,1920(H)x1080P(V)Double switch
megapixel AHD &Anolog All in one, Pan / Tilt / Zoom
Minimum Illumination:
Color:0.01Lux B/W:0.001Lux/0Lux
Optical focus:
30x Zoom, f=3.9 - 117mm, F1.6 - F3.5
Screen menu:
AWB , Digital noise reduction , Light suppression,Mirror
Signal model:
PELCO-D / SONY - VISCA,UART (RS232C - 3.3V level) or 12C (optional)
Infrared sensors:
support IR cut filter
Digital Camera
Mini Camera

Packaging & Delivery

Selling Units:
Single item
Single package size:
8X6X6 cm
Single gross weight:
0.3 kg
Picture Example:
Lead Time :
Video Description


Product Description

HD Built-in power adapter board 700tvl sony ccd zoom camera module with 30x optical focus OSD menu

zoom camera module Specification:



SONY CCD Zoom camera module function &characters:
1/3" sony  700TVL
22× 27X 30X digital focus
Double filter switching function
high-speed digital focus function,Continuous tracking autofocus
WDR,Frame accumulated,privacy mask
specialized high speed dome module,support SONY,LG protocol


Zoom Camera Module Specification:



Model No .SZ-R870E+B
Signal modelPAL/NTSC
Image sensor1/3" SONY CCD
Effective pixel976(H) x 596(V)
Horizontal resolution700TVL
Minimum illuminationColor to B/W, Color: 0.1Lux, B/W: 0.01Lux
Sync system  Internal sync
Focus length3.9~85.8mm3.2~86.4mm3~90.0mm
Optical focus22X27X30X
FocusAuto/manual, take high-performance DSP to realize complete digit and ultra-high speed focus function
Gain Control  Auto/Manual
White balanceAuto
Iris  Auto/Manual
S/N radio>60dB(Enhanced)
Electronic shutter    1/50(1/60)s~1/10000 s
Video output  1.0Vp-p 75 Ω
Power cut memory restoreYes
Language      Chinese/English
Screen menuAWB , Digital noise reduction , Light suppression,Mirror
Control  SONY/LG
Gama modulus      0.45
Interface modeNine -pin connector
Power supplyDC12V,90~120mA
Work temperature  -20°C~+70°C
Dimension      W50mmXH58mmXL90mm




Our Services
  1.  The product is based on Ex-works for 1-50pcs, FCA shenzhen for 50-500pcs, FOB shenzhen for above 500pcs.
  2.  Payment term:100% payment in advance before shIpment (T/T, Western Union ,paypal,cash or any other means at your convenience)
  3.  Delivery Time:sample order: 1-3 working day, Normal order:longer than 3 working days according to the order quanity
  4.  All the above products have CE ,FCC and ROHS certificates
  5.  Welcome OEM & ODM order,MOQ for OEM is 50pcs/model
  6.  Power adapter isn't included in above prices, it's optional
  7.  Price Validity: 30 days from issuing date.
  8.  Warranty: 2 years after receiving goods,unlimited lifetime Technique support.
  9. If quanity more than 100pcs one model, we will free supply some camera parts for preapre exchange




Company Information

Why Choose SafeEye ?


(1) 24 hours reply


(2) 2 years Warranty


(3) 100% 5 steps Quality Check


(4) Powerful R&D team,  OEM hardware and software


(5) fast leadtime: 3-4 days for sample order, 5-10 days for leadtime


Packaging & Shipping

1.The package will be shipped from China via Express air or by sea as your request. The tracking number will E-mail to you when the item sent, usually it takes 4~5 working days to arrive by air;it takes 10~45 days to arrive by sea depending on the port.


2. Air freight (we have strong cooperation with DHL, TNT, FEDEX, EMS, you can also choose your own shipping forwarder)


  • DHL (3-7 business days)
  • http://www.dhl.com
  • FedEX (3-7 business days)
  • http://www.fedex.com/cn
  • UPS (3-7 business days)
  • http://www,ups.com
  • EMS (5-9 business days)
  • http://www.17track.net/en/
  • TNT:(3-7 working days)


  • Air mail (7-25 business days)
  • The shipping way depends on your address.

What the Payment terms:

T/T,Western Union,VISA,Mastercard,Escrow, paypal and so on.
1. We can arrange to produce in advance once we get the bank slip of deposit.
2. Order value less than 20,000USD, 100% payment before production;
3. Order value more than 20,000USD, 30% deposit. 100% paid before shipment.
Q.May I print our company logo on package box and products?
A:Of course,buyer logo is welcome in our company.We have one production line for printing buyer logo.
Q.Do you provide warranty for your products?
A:Yes,we promise two years warranty for all our products.
Q.What is Minimum Order Quantity?
A:Min Order Quantity is 10pcs,but sample order is welcome.
Q: Can We to be your Agency in our Country?
A: Of Course, welcome to be SafeEye Security Products agency in your country, we will try best support for you.


  Click “send” to get the latest price list from us.
