C130 SWG/AWG18-36 heating aluminum submersible winding wire

Feedback Ratings
  • 5000-9999 Kilograms
    $3.85
  • 10000-17999 Kilograms
    $3.84
  • >=18000 Kilograms
    $3.83
Quantity:
- + Kilograms available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
8 day(s) after payment received
Customization:
Customized logo (Min. Order: 18000 Kilograms)
Customized packaging (Min. Order: 18000 Kilograms)

More

Graphic customization (Min. Order: 18000 Kilograms) Less
Contact Supplier
Samples - $3.83 /Kilogram, 1 Kilogram (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Anhui, China (Mainland)
Brand Name:
Surxin
Model Number:
AIWA
Type:
Insulated, EIWA
Application:
Heating
Conductor Material:
Aluminum
Conductor Type:
Solid
Insulation Material:
Enameled
Material:
Aluminum
Color:
Red
Delivery Time:
7-15 Days
MOQ:
18 tons
Size:
SWG/AWG 27
Insulation:
Polyamide-Imide
Certification:
ISO9001
Product name:
C130 SWG/AWG18-36 heating aluminum submersible winding wire

Packaging & Delivery

Selling Units:
Single item
Single volume:
26 cm 3
Single gross weight:
18900.0 kg
Package Type:
Use PT-15 spool, 6.5 to 7kg/each spool. 2 spools with 1 carton. Without pallet.
Picture Example:
package-img
package-img
Lead Time :
Quantity(Kilogram) 1 - 8000 8001 - 18000 >18000
Est. Time(days) 8 15 To be negotiated

C130 SWG/AWG18-36 heating aluminum submersible winding wire

Product Description

Product Parameters

TYPE

Thermal Class

Specifications Range

Application Standard

Code

Class

mm

AWG

SWG

IEC

GB/T

QZYL

(EIWA)

H

180

0.193-1.219

16#~32#*

18#~36#

60317-25

23312.3











Note: “*” for approximate American wire gauge.



Products Main Features

It is easier to make coil from aluminum enameled wire than other enameled wires. Because there is hard oxide film on the its surface, the temperature of heat-resistance is 20 higher than that of copper and insulation effect is excellent, and have a long life range. The biggest advantage is that its weight is 3 times lighter than that of copper so that the production cost can be decreased greatly. It can be soldered directly.



Main Applications

Can be used to make winding wire demanding light material, high electricity conductivity and good heat dispersing performance, especially for the winding wire for transferring high frequency signal, such household appliances as degaussing coil, high frequency transformer, common transformer and small electric motor.



The physical and mechanical performance of copper clad aluminum wire, copper wire, aluminum wire

Conductor Performance

Copper Clad Aluminum Wire

Copper Wire

Aluminum Wire

Volume ratio of copper (%)

15

109

0

Specific gravity (g/cm3)

3.63

8.89

2.70

Length ratio in same wire diameter and unit weight

2.5: 1

1: 1

3.29: 1

Conductivity (IACS)

70

100

62

Electric resistivity (Ωmm2)

0.02462

0.01724

0.02740

Tensile strength (M pa )

95-135

215-266

68-107

Elongation (%)

≥10

≥20

≥8

Winding performance

good

very good

good

Weight

good

bad

very good

Soldering performance

very good

very good

bad

Direct current resistance

good

very good

good





Company Information

About

Anhui Surxin Wire & Cable Co., Ltd. is located in Qingyang Economic Development Area in Chizhou City, Anhui Province, which is closed to one of the four Buddhism mountains, Mount. Jiuhua.

We are professional cable & wire manufacturer with all types, such as UTP(FTP), CAT5E, CAT6, Patch cord, Coaxial cable, Alarm cable, Electrical cable, Automotive cable, Enameled wire and Copper product etc. Our products have been sold to Europe, Southeast Asia, Middle East, South Africa and Australia, getting good reputations from our customers.

Contact Us

Welcome to inquire!

Phone: (+86 566) 5116666 5118666

Whatsapp:(86)18805666010

Skype: t18805666010

FAX: (+86 566) 5115818

Address: Qingyang Economic Development Area,
Chizhou City, Anhui Province, China (Mainland).
