reverse osmosis panel will be packed with standard export wooden case or packed by client's requirement
15-25 days after receive 30% deposit
reverse osmosis process uses semi permeable spiral wound membranes to separate and remove dissolved solids, organic, pyrogens, sub micron colloidal matter and bacteria from water. Feed water is delivered under a pressure of approximately 16 kg/cm2 through reverse osmosis membranes. Water permeates the minute pores of the membrane and is delivered as purified water. Impurities in the water are concentrated in the reject stream and flushed to drain. Reverse osmosis is capable of removing 90-99% of total dissolved solids (TDS), 99% of organic, including pyrogens, and 99% of all bacteria in the feed water.
What is Reverse Osmosis?
Reverse osmosis (R/O) is a water treatment process in which water is forced through a semi-permeable membrane that has very small holes or "pores". Clean water passes through and impurities that are too big to pass through the membrane are left behind and flushed away. In a word, it is a machine to make pure/ultra pure water.
How Does Reverse Osmosis Work?
Reverse osmosis systems purify water by forcing pressurized water through a very fine, plastic membrane. If the raw water being treated comes from a well or another private source, disinfection and pre-filters (to remove chlorine and/or particulates/sediment) may be needed in advance of the R/O unit to remove contaminants that can foul or damage the membrane. water filter system
How Do I Know What Size Unit to Buy?
R/O units are rated according to the amount of treated water produced per day. For example, one type of unit produces 5000 liters of treated water per day under its design conditions.You should examine water conditions and buy a larger rated unit than needed.
Material of reverse osmosis system?
We have different materials. 1. Fiber glass(FRP) filter + U-PVC pipe 2. stainless steel filter + U-PVC pipe 3. total stainless steel.
Stainless steel we also have SS304 and SS316. You can choose suitable material. water filtration machine
1). Electronic industry: Pre-filter for ultra pure water, chemical products and pure water 2). Food and beverage industry: filter for mineral water, wines and fruit juice 3). Medicine industry: filter for drug liquid, gases 4). Chemical industry: filter for organic solvent 5). Petroleum industry: filter for oil-field flooding 6). Power system 7). Metallurgical industry 8). Medical and pharmaceutical industry 9). Brackish water desalination etc
1).Can produce pure water continuously and highly automatic 2).No need chemical to regeneration, easy operation 3).RO system uses imported USA DOW membrane 4).Automatic switch on when low water level, and switch off when high water level 5).RO membrane can wash automatically and reduce pollution 6).Water shortage protection for multi-stage pump 7).Production water conductivity meter can test the monitoring quality on line continuously. 8).Low operation Cost and Long life span 9).RO-PLC program controller 10).Easily control and Maintain 11) Auto flush/backwash
Different Water TDS Compare and Usage
Bottle Water /Bag Water
cooking, domestic water , washing
irrigation, industry, animal drinking
1000L/H, we can do from 250L/H - 50,000L/H.
1 stage is 50-55%, 2 stage is 80%. And dense water from 2 stage will go to 1 stage to purify again.
city water, underground water, river water....
drinking water /bottle water/pure water
Process: raw water - raw water pump - sand filter - carbon filter - security filter - one stage high pressure pump - one stage RO system -two stage high pressure pump - two stage RO system - UV - pure drinking water water filtration machine
Raw water tank
Store water, buffering pressure, overcome instability of supplying water by pipe
Customer provide for themselves
Raw water pump /booster pump
Provide needed pressure for every pretreatment filter
get rid of turbidity, suspended mater, organic matter, colloid ect.
fiber glass /stainless steel vessel
Activated carbon filter
remove color, free chloride, organic matter, harmful matter and so on.
fiber glass /stainless steel vessel
Security filter/ pp filter/ PP sediment filter
prevent large particles, bacteria, viruses into RO membrane
High pressure pump
provide high pressure to RO membrane(at least 2.0Mpa)
CNP pumps or Grundfos pumps
RO(reverse osmosis) system
remove particles, colloids, organic impurities, heavy metal ions, bacteria, virus, heat source etc. harmful substances and 99% dissolved salts.
USA Filmtec Dow
kill bacteria in pure water
Packing & Delivery
standard export wooden case
Contact us to get lastest price
T/T, L/C, Westen Union
Machine and Clients
Our machine have been sold to all over the world.
Q: Is this machine easy to install? Will you arrange engineer to help me install?
A: This machine is very easy for install. The machine you received is assembled. You will only need to follow steps on our English instruction and video. If big capacity of machines, we can arrange engineer to help installation.
Q: How long can I get the machine?
A: It depends on specification of machine. If just standard specification, we have it in stock. Then we will arrange within 3 days. If not standard specification, different capacity may lead production time different. Shipment time to different place is also different. You can contact me to get detail information
Q: How can I pay you?
A: After we confirmed order, I will send you contract sales with our company bank information. You can transfer money to our company bank account by T/T. Or you can choose to place order online.
Q: What's the packing of machine? Is it suitable for shipment?
A: Machine will be packed by standard export plywood case. It is suitable for long time shipment by sea/air/train.
Q: How about warranty?
.A: We provide 1 year warranty. It means when there is any parts broken in one year, we will send spare parts to you for free.
Q: How can I get best price?
A: PLS just contact us to get latest price.
Why Choose Us
Guangzhou ABC Environment Equipment Co., Ltd is a scientific and technical corporation which can design, produce, sell, install, maintain environment equipments. “Professional product, best service” is our core value and make our company long term development. We devote ourselves to provide the most suitable equipment for client according to their source water quality and treated water quality requirement. Our target is to solve water problems such as lacking water and water quality bad for people in everywhere of the world. Our main products is environment technical projects including: Reverse Osmosis(RO) pure water system, sea water desalination system, ultra pure water system, ultra filtration(UF) mineral water system, filing water system, industrial water treatment system….
