CHINA best price pvc electric wire 6mm2 electric cable

$0.50 / Meter | 1000 Meters (Min. Order)
Quantity:
- + Meters available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
10 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Henan, China
Brand Name:
Aobest
Model Number:
CU/PVC/PVC 450V/750V
Type:
Insulated
Application:
Overhead
Conductor Material:
Copper
Conductor Type:
Stranded
Insulation Material:
PVC
Product name:
Copper Core PVC Insulation Wire
Conductor:
Copper Core
Insulation:
PVC Insulation Cable
Rated Voltage:
450/750V
Certification:
ISO9001
Standard:
IEC 60227
Packing:
100m/roll

Packaging & Delivery

Selling Units:
Single item
Single package size:
30X30X9 cm
Single gross weight:
5.0 kg
Package Type:
100 meter per coil or as your requirement
Picture Example:
package-img
Lead Time :
Quantity(Meters) 1 - 50000 >50000
Est. Time(days) 10 To be negotiated
Video Description

pvc electric wire 6mm:
PVC insulated wires belong to the series of laying electric wires,which is mainly suitable for laying at the fixed places.It is widely used as connectors of drive,lighting,electric equipments,instrument and telecommunication equipments with rated voltage 450/750Vor below.Part of the plastic wires are used at the equipment with AC rated voltage 300/300V or below.
1.Standards
The products adopt GB 5023.11997450/750V or below PVC insulated electric wires,JB 8734.15-1998450/750V or under PVC insulated cables,electric wires and flexible wiresand Q/ZEL 02-2002Piastic insulated electric wires and cables.GB 5023.17-1997 is identical to IEC227,and type are same as the stipulation of IEC,technical specification is just the same,and more we have extended the range of the type to fit for the requipment of the consumers.

2.Products



TypeNameLaying place and requirementLong term working temperature
227IEC01/05
BV
BLV
Copper conductor PVC insulated wiresFixed laid indoors,conduits etc.70
Aluminum Conductor PVC insulated wires
227IEC07
BV-90
Heat resistant copper conductor PVC insulated wires at 90Mainly be laid at the places of high temperature environment and can be laid indoors,conduits.90
BVRCopper conductor PVC insulated flexible wireBe for laying permanent place where flexible required70
227IEC10
BW
Copper conductor PVC insulated PVC sheathed round wiresFixed laid,fit for the places with high mechanical protection and moisture place.Can be laid in the air or underground.70
BLWAluminum conductor PVC insulated PVC sheathed round wires
BWBCopper conductor PVC insulated PVC Sheathed flat wires
BLWBAluminum conductor PVC insulated sheathed flat wires
227IEC02RV
227IEC06RV
Copper conductor PVC insulated flexible connectorMainly used at middle and linht stylemoving electronics,home appliances,power and lighting and the places where flexible required.70
227IECC42
RVB
Copper conductor PVC insualted flat flexible connector
RVSCopper conductor PVC insulated flexible twisting connector wire
227IEC52
RW
227IEC53
RW
Copper conductor PVC insulated PVC sheated round flexible connector(light and common type)
