Carcass cattle crusher complete crushing unit

FOB Reference Price:Get Latest Price
$2,000.00 - $9,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Type:
poultry waste rendering plant
Application:
dead animal harmless treatment, Poultry Farm
Motor Type:
Top China brand or customer's request
Power(W):
30kw
Capacity(t/h):
15-50tph
Place of Origin:
Hebei, China (Mainland)
Brand Name:
Chengzhu
Model Number:
CZ
Dimension(L*W*H):
Specific Model
Weight:
6.5t
Certification:
ISO9001
Product name:
Automatic poultry waste rendeing plant for sale- pre-crusher
Name:
High quality crusher for Harmless processing line
Raw material:
poultry waste/animal carcasses
Material:
carbon steel
Motor:
Top Chinese Brand or Customer's Request.
Usage:
Animal Poultry Livestock Pellet Making Machine
Function:
Aniaml Feed Puffed Pellet Machine
Color:
Blue or customized
Advantage:
High Capacity
After-sales Service Provided:
Engineers available to service machinery overseas
Warranty:
12 Months
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Suitable package to avoid the damage when shipping.
Port
Tianjin port
Lead Time :
At least 60 days after payment.

Carcass cattle crusher complete crushing unit

Product Information



   Production Information





Poultry waste reception section



There is a  Material Silo For the reception and storage of poultry wast,dead animal.

There is a Pre-crushing machine in the middle in function of chopping whole animal caicasses and large pieces with aim of 50mm size piece(easily transported)

A Material Pump is at the bottom to transport the marterial to cooker.





 Cook and Dry Section



Function: Waste raw materials(feathers,animal,fur,sick livestock,animal carcasses) through the process of high temperature and pressure to achieve the effect of sterilization and break down



Features: Big capacity of each batch,the efficiency of sterilization is complete and safe.

It could be used to break,cook,sterilization and drying.









 Oil Press Section



The material from silo are sent to the heated pot by screw conveyor, and then go into the oil press,

after oil press, we get the cake with 10-12% oil and fat ,the odor from this section collected by

pipeline and is treated together.



 Cooling Section



The cake from cooker is sent to cooling system by screw conveyor(with dust collection), the tempertaure is reduced to ±5℃ room temperature.







Meal Section



Function: To reduce the size of meal.



Features: 1.Unique crushing chamber to improve the efficiency of grinding.

2.Special rotor design program,and the harmmer sieve gap,which can meet different granularity.



Packing Section





Automaticly packing the meal.





















 Odor treatment section



To seperate solids and liquids entrained in the process vapoures from cooking /drying equipment,by washing of glasses collected from several process points.



 Final Products

Tallow: Moisture<1%

Meat and Bone Meal: Protein≥65%



The whole line consists of material buffer bin,conveyor,cooker dryer,grinding,packing and odor treatment system






Product Details





   Product Features




 Features

In order to meet individual requirements, all sizes of raw material transfer pumps can be assembled with cast iron or stainless steel pump housing.With replaceable wear parts, these wear pieces are made of special steel.YPS pumps have only four moving parts, which can be fitted with mechanical sealed bearings or standard bearings with packing boxes.



FunctionYPS pumps are used to deliver liquids that contain large particles (such as pre-crushed animal by-products, fish or pet food) and viscosity.It is suitable for all kinds of cooking equipment and other processing equipment.
CharacteristicsAccording to the type of materials and specific requirements for performance, the YPS transport pump can be driven by electric gear motor or hydraulic motor.
Product Application



Technical specifications

Unit

Modle number YPS02

Capacity

Tons/hour

5-30

The anvil clearance

mm

30

Rate of work

kW

37-75

The broken shaft

revolutions per minute

10-50

Weight

kg

6500

   Applications



Process Flow



Crusher ---->  Cooker ---->  Dryer ----> Defatting ---->  Cooling ----> Milling ----> Packing



After cleaning the feather dust, it is put into a hydrolyzed tank, hydrolyzed at high temperature and high pressure, then dried, cooled, crushed and packaged into finished products.

The hydrolyzed feather powder processing technology is relatively advanced, its outstanding characteristic is thoroughly feather Angle protein stability of spatial structure, so that it becomes soluble protein of the livestock and poultry can absorb, digest rate above 75%.Suitable for fishmeal supplement, added to fish meal, good sense, good fluidity, can improve protein reduce cost, the key is not to affect feeding effect.



Notes:

We can design a turnkey production line for our customers,the line including many machines,customer also can choose the one they need depend on their production  and the founds,so no matter what requriements you have,we will try our  best to with you





If you need more information, please click to contact us!





Packing & Shipping





Company Information



   Company Information



COMPANY

PROFILE__

Hebei Chengzhu Machinery Group Co., Ltd was founded in 1990, we specialized in contracting the project of poultry and livestock waste rending plant and slaughterhouse waste, after 20 years development and growth, we have become the company with technology research and development, processing design, product manufacturing, installation and training.

Our company has developed a new type of hydrolyzed feather dusting machine, which is based on the advanced technology of European and American countries, and combined with the new generation products developed by our company for many years.







   COMPANY

   CERTIFICATE



      Products passed

      ISO 9001













                                  MORE+





Related products





Our Service



   Our Service





Pre-sale Service:



Your inquiry related to equipment or price will be replied within 24 hours.

Well-trained and experienced staff will answer all your inquiries in English of course.

We accept OEM&ODM projects.

We have strong R&D team here to help.



After-sale Service:

1 year warranty period, please don't hesitate to contact us if you have any question with the equipment
