China cheap price small Standard Peristaltic tubing squeeze hose Pump with high quality CE ISO certified

FOB Reference Price:Get Latest Price
$900.00 - $1,050.00 / Units | 1 Unit/Units (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
BIOBASE
Model Number:
SPP-N6 Series
Structure:
peristaltic
Usage:
Water
Application:
Metering
Power:
Electric
Fuel:
electric
Pressure:
High Pressure
Drive:
N6-3L
Flow rate range:
0.211-3600ml/min
Speed range:
0.1-600rpm
Motor type:
Servo motor
Control system:
N-EMB
Display:
LED screen
Ambienttemperature:
0-40℃
Power supply:
220V/110V ±10%, 50Hz/60Hz
Consumption:
<50W
Drive external size (L*W*H)mm:
223*152*168
Standard or Nonstandard:
Standard
Theory:
Vacuum Pump
Supply Ability
Supply Ability:
1000 Unit/Units per Month
Packaging & Delivery
Packaging Details
Fumigation Wooden Package
Port
Qingdao

China cheap price small  Standard Peristaltic tubing squeeze  hose  Pump with high quality CE ISO certified

Product Description



Features:



1.Serve motor drive, precise control, strong power, low vibration and low noise.

2. N-CIR circuit system, use imported chips, computing speed fast, reliable performance, working stable.

3. N-EMB operation system, embedded software design, powerful function, friendly interface.

4.Membrane keypad control: start/stop, direction, timing test, external control mode selection.
5.Rotary encoded switch can identify the target speed intelligently.

6.Timing test function, time range is 0.5-999 seconds.

7. Selectable different external control ways. Analog signals ( 0-5V, 0-10V, 4-20mA) control speed, switch signal control start/stop and direction.RS232, RS485 communication interface, support MODBUS protocol. Convenient for external control.
9.Load-shedding memory function.
10.Strong anti-jamming feature, wide voltage design, suitable for complex power supply environment.
11.Circuit board spray with three paint, anti-dust, anti-moisture, anti-static, resist corrosion.
12.304 stainless steel housing, use seamless welding technology, avoid accidental spilled liquid on the housing infiltrate inside, to protect the inside circuit board.
13.DZ25-3L, DZ25-6L, YZ35-PPS pump head, aluminum alloy material, 304 stainless steel rollers, strong rigidity, high accuracy, reliable performance.



Parameters:



Drive

N6-3L

N6-6L

N6-12L

Flow rate range

0.211-3600ml/min

3-6000ml/min

0.0069-12l/min

Speed range

0.1-600rpm

Speed resolution

0.1rpm in the range of 0-100rpm;1rpm in the range of 100-600rpm

Flow rate accuracy

<±0.5%

Outlet pressure

0.3Mpa

Motor type

Servo motor

Circuit system

N-CIR

Control system

N-EMB

Control method

Membrane keypad

Display

LED screen

External control speed signal

0-5V(standard)

0-10V,4-20mA(optional)

Start/stop,direction singal

Passive switch signal, such as foot pedal switch

Active switch signal: 5V, 12V and 24V for option

Communication interface

RS232(standard), N232 communication protocol;RS485(optional) MODBUS protocol (RTU mode)

Ambinet temperature

0-40℃

Relative humidity

<80%

IP rate

IP31

Power supply

220V/110V±10%, 50Hz/60Hz;

Consumption

<80W

<180W

<300W

Drive external size

(L×W×H)mm

223×152×168

283×192×218

302×222×275



Product Composition and Flow Rate Range



Model

Drive

Motor Type

Pump Head

Tubing Size

Speed Range(rpm)

Flow Rate Range(ml/min)

SPP-N6-3L

N6-3L

Stepper Motor/Servo Motor

DZ25-3L

15#,24#,35#,36#

0.1~600

0.211~3600

SPP-N6-6L

N6-6L

Servo Motor

DZ25-6L

15#,24#,35#,36#



0.3~6000

SPP-N6-12L

N6-12L



YZ35

26#,73#,82#



0.69~12000





Main Products



Our main products are main divided into 4 parts:



I. Medical Isolation Equipment like Biosafety Cabinet(Class I/II/III), Laminar Flow Cabinet, Fume hood.



II. Cold-chain products like Medical Refrigerator&Deep Freezer etc;



III. Common laboratory equipment,like autoclave sterillizer,centrifuge,drying oven etc;



IV.Clean room construction, class 10,000 and class 100 clean room and laboratory construction, mobile laboratory constructed on trucks containers.



Packaging & Shipping

Making sure the goods to the customers timely and safely



Company Information



BIOBASE Advantage:



1.Established in 1999,owning more than 1000 employees &20000 square meters.

2.15 years production experience and 100 professional engineers

3.Strong quality control team and technial production

4.Certificated by   NSF49 , EN12469, ISO9001,ISO14001,CE,MET.


Certification:



FAQ



1.Why choose BIOBASE?


   We are the leading manufactuer in lab furniture and lab equipment, OEM & ODM service are offered. And we have our own overseas techinican and installation team.


2.How about the sample of Biobase product?


   We could send you the samples but the freight and the sample are charged.


3.How about Biobase payment term?


   T/T & L/C &Western Union(40% deposit, the balance before shipment)


4.How about BIOBASE delivery time?


   Within 7-15 workdays after receiving deposit.


5.How about BIOBASE validity of quotation ?


   Usually 30 days as the shipping freight and exchange rate can be fluctuant.
