China factory 500m night vision surveillance PTZ IR laser night vision

FOB Reference Price:Get Latest Price
$1,000.00 - $3,000.00 / Sets | 1 Set/Sets (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China
Brand Name:
Foshvision
Model Number:
FS-TL520-HD-8994
Video resolution:
1920*1080
Type:
CCTV Camera System
Certificate:
CE FCC ROHS
Warranty:
12 Months
Sensor:
1/2.8" Progressive Scan CMOS
Total pixels:
2.1MP
Lens:
f=4.7-94mm, 20x optical zoom
Coded format:
H.264
Protecting grade:
IP66
Power consumption:
60w
Supply Ability
Supply Ability:
500 Set/Sets per Month
Packaging & Delivery
Packaging Details
wooden/carton case
Port
Jinan
Lead Time :
7
Product Description

China factory 500m night vision surveillance PTZ IR laser night vision

Features:

● Adopting near-infrared light source to fill light, good concealment, not easy to be detected
● Specialized high definition night vision laser homogenization technology, laser spot high brightness and good homogenization of laser spot, exquisite image with no noise
● Day and night low light 2 megapixels color to black camera, realizing day and night continuous monitoring
● Super large angle continuous servo synchronous zooming laser illuminator, MMA inside optical axis fine adjustment aligned technology
● High performance embedded processor, adopting high efficiency H264 compression algorithm, clear, real time and smooth video
● Supporting dual stream, small time delay, fully satisfying different network bandwidth
● Fully supporting ONVIF、GB/T28181, providing SDK, can docking with main monitoring platform home and abroad
● Supporting WEB browsing video, providing access to NVR platform to conduct uniform parameter configuration and operation state management
● Humanized design, high intelligence, supporting 3D locating, power off memory, zooming and speed changing
● Adopting high performance power supply program, wide voltage input, low power consumption, suitable for special power supply mode such as solar energy
● IP66 protection grade,2000V anti-lightning, adapting to all kinds of complex environment
● Professionally designed shell, artistic, light, firm, anti-high temp, anti-corrosion, water proof, anti-acid rain


Specification:

Monitoring distance
Night vision
500meters
Day vision
700meters
Laser illuminator
Power
5W
Wave length
810nm
Illuminating angle
1°-20° synchronous continuous adjustment
Even light
MCIC even light technology
Visible light Camera
Sensor
1/2.8" Progressive Scan CMOS
Total pixels
2.1MP
Lens
f=4.7-94mm, 20x optical zoom
Lens aperture
F1.6-3.5
Minimum illumination
0.05Lux (color), 0.01Lux (black and white)
Electronic shutter speed
Auto and manual adjustment
Camera control
Auto gain control, auto white balance, auto backlight compensation, supporting manual and auto day and night mode switch
Video coding
Coded format
H.264
Video resolution
1920 x 1080
Bitrate
64Kbps-4Mbps
Frame rate
1-25f/s(50Hz), 1-30f/s(60Hz)
Subtitle overlay
station logo, date, time
Image adjustment
brightness, contrast, saturability
Supporting protocol
TCP/IP, HTTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, SMTP, NTP, UPnP, SNMP, FTP, 802.1x, QoS, HTTPS, IPv6 (SIP, SRTP optional)
Pan-tilt
Angle
Pan 360° continuous, tilt -90° to +90°
Speed
Pan 0°-80°/s, tilt 0°-60°/s
Presets
256
Cruising function
6 paths
Interface
Network interface
1×10Base-T/100Base-TX, RJ45
Power supply interface
1×DC 24V socket, for external power adapter
Audio interface
1×Line In, 1×Line Out
Alarm interface
1 switch input, 1 switch output
Environmental indicators
Operation temperature
-25℃ to +55℃ (optional -40℃ to +55℃)
Storage temperature
-40℃ to +65 ℃
Protecting grade
IP66
Anti-vibration
10-55Hz, 2m/s2, 0.75mm
Anti-impact
150m/s2, 11ms
Anti-salt fog
After continuous spraying for 48 hours at PH 6.5-7.2, surface does not change
Power supply
Working power supply
DC 24V±5% /2.5A, please use the appendant power supply
Power consumption
≤60W
Physical features
Size
240mm×374mm×243mm
Weight
8Kg
    Others
Application function
Real time clock, supporting manual snapshot and manual recording
Configuration
Supporting configuration management and video browsing through WEB;
Provide access to platform(NVR) to conduct parameter configuration and operating state management, supporting ONVIF2.0, GB28181


Quality assurance:
1. Specialized people. Among all employees, 50% are professional technicians, including doctorates, masters, and senior engineers.
2. Internationalized management mode. Foshvision has gained the authentication of ISO9001A-2001 quality management system, CE certificate, FCC certificate, etc.

Packaging & Shipping

PACKAGE:

Standard export carton packing or wooden case.

DELIVERY TIME:

3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
