China supplier off grid 3000W solar power inverter 230V high frequency solar inverter

  • 5-49 Pieces
    $214.00
  • 50-99 Pieces
    $178.00
  • >=100 Pieces
    $135.00
Application:
Off-Grid Solar System Hybrid Solar System
Output Power:
3000W
$
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
5 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
SAKO
Model Number:
SVP 3000W
Size:
350X285X110MM
Weight:
6.3KG
Input Voltage:
24VDC
Output Type:
Single, Quad
Type:
DC/AC Inverters
Output Voltage:
230VAC
Output Frequency:
50HZ60HZ
Product Name:
PWM hybrid solar inverter
Function:
DC to AC 220V 50Hz
Advantage:
With 2 Charger and High Efficiency
Power Max:
3KW
Efficiency:
98%
Battery Bank:
24V
Charge Current:
50A PWM
Company:
Direct Manufacturer
Experience:
24 Years
Warranty:
1 Year

Packaging & Delivery

Selling Units:
Single item
Single package size:
42.3X37.5X20.9 cm
Single gross weight:
7.7 kg
Package Type:
Standard international paper box packing.
Lead Time :
Quantity(Pieces) 1 - 1000 >1000
Est. Time(days) 5 To be negotiated
Video Description

China supplier off grid 3000W solar power inverter 230V high frequency inverter



Features
1. PWM charge controller built inside.

2. Pure sine wave, high frequency technology, wall amounted design , light weighted and easy to operate.

3. Selectable input voltage range for home appliances and personal computers.

4. Selectable charging current based on applications.

5. Configurable AC/Solar input priority via LCD setting.

6. Compitable to grid power or generator power.

7. Auto restart while AC/ Solar is recovering, auto charge and switch, unattended operation.

8. Smart battery charger and management for optimized battery performance.

9. Remote control panel is optional.

10. High Efficient DC to AC Conversion. Minimizing Energy Loss and self power consumption .

11. All around protection functions: Overload,short circuit protection,high voltage,low battery voltage,high temperature.

Product Description

 Solar Inverter 1.jpgSolar Inverter 2.jpg

TECHNICAL PARAMETER
ModelSVP-1KSVP-2KSVP-3K
The rated power1KW2KW3KW
INPUT
Voltage230 VAC
Selectable Voltage Range170-280VAC (For Personal Computers), 90-280VAC (For Home Appliances)
Frequnecy Range50Hz/60Hz (Auto sensing)
OUTPUT
AC Voltage Regulation (Batt. Model)230VAC ± 5%
Surge Power2000VA4000VA6000VA
Efficiency(Peak)90%93%
Transfer Time10ms (For Personal Computers), 20ms (For Home Appliances)
Wave formPure sine wave
BATTERY
Battery voltage12VDC24VDC
Floating Charge Voltage13.5VDC27VDC
Overcharge Protection16VDC32VDC
MPPT SOLAR CHARGER & AC CHARGER
Maximum PV Array Power420W1200W
MPPT Range Operation Vol15-33VDC18-80VDC
Maximum PV Array Open Circuit Vol.50VDC80VDC
Standby Power Consumption15W28W
Maxmum Solar Charge CurrentPWM 50A
Maxmum AC Charge Current 25A
Maxmum Charge Current50A70A
Maxmum Efficiency98%
BEST PANEL CONFIGUTATION
Max. generated from solar charger30Amp, 420W50Amp, 1200W
Best Panel configuration200Wp*2pcs (420Wp)250Wp*5pcs *30V(1250Wp)
5 Parallel



Solar Inverter 4.jpg

new products

other Products

Company Information

_03_04_05


Certifications

_06

Packaging & Shipping


FAQ



Q1: How to choose a right inverter?
A1:Tell us your demand, then our sales will recommend a suitable inverter to you.

Q2: What's the different between inverter and solar inverter?
A2: Inverter is only accept AC input, but solar inverter not only accept AC input but also can connect with solar panel to accept PV input, it more save power.

Q3: How about the delivery time?
A3: 7 days for sample; 25 days for bulk order.

Q4: What is the warranty of inverter?
A4: One year warranty on Solar product.

Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.

SVP-3KW/24V Off Grid Solar Inverter,HF Solar Inverter with PWM50A Solar Controller built-in

SVP-3KW/24V Off Grid Solar Inverter,HF Solar Inverter with PWM50A Solar Controller built-in

SVP-3KW/24V Off Grid Solar Inverter,HF Solar Inverter with PWM50A Solar Controller built-in
