Attributes
1600*2000mmWorking Table Size(mm)
CNC Routermachine type
Normalcnc or not
Shandong, Chinaplace of origin
AC380V/50HZvoltage
3000weight (kg)
warranty:1 Year
range of spindle speed(r.p.m):0 - 18000 rpm
positioning accuracy (mm):0.02 mm
number of axes:6
No. of Spindles:Multi
travel (x axis)(mm):1600 mm
travel (y axis)(mm):2000 mm
repeatability (x/y/z) (mm):0.05 mm
Spindle Motor Power (kw):2.2
brand name:Aoshuo
dimension(l*w*h):3200*2300*2200mm
key selling points:Easy To Operate
machinery test report:Provided
video outgoing-inspection:Provided
core components:Motor
Control system:Syntec/Ncstudio control system
Overall size:3000*2300*2200mm
Repositioning resolution:0.05mm
Resolution:0.02
Max.travelling speed:60000mm/min
Max.cutting speed:30000mm/min
Spindle speed:0-18000rpm/min
Servo motor:leadshine servo motor
Working voltage:AC380V/50HZ
Weight:2500kg
Selling Units:Single item
