Color temperature 3000-6500K IP66 100lm/w 165W led area work light

Feedback Ratings
  • 1-4 Pieces
    $192.00
  • 5-19 Pieces
    $189.00
  • 20-49 Pieces
    $184.00
  • >=50 Pieces
    $179.00
Model Number:
SDL101-165
Emitting Color:
Cold White Warm White White
Lamp Power(W):
165
Color:
Dark Grey
- +
available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
30 day(s) after payment received
Contact Supplier
Samples - $192.00 /Piece, 1 Piece (Min. Order): Buy Samples
Loading... Add To Cart
Report Suspicious Activity
Overview
Quick Details
Light Source:
LED
Input Voltage(V):
AC90-305V
Lamp Luminous Flux(lm):
16500
CRI (Ra>):
70
Working Lifetime(Hour):
50000
IP Rating:
IP66
Certification:
CCC, CQC, LVD
Warranty(Year):
5
Place of Origin:
Chongqing, China (Mainland)
Brand Name:
Silian
Product name:
Color temperature 3000-6500K IP66 100lm/w 165W led area work light
Product group:
LED Street Light
Rated power:
165W
Power factor:
PF>95%
Harmonic distortion:
<10%
Driver Type:
Potted driver with multi self protections
Driver conversion efficiency:
≥90%
Surge protection:
6KV+10KV
Mount pole OD:
55 to 65mm
Housing:
Die cast aluminium with corrosion resistant coating
Item Type:
Street Lights
Lamp Body Material:
Aluminum
Color Temperature(CCT):
3000-6500K
LED Light Source:
SMD
Lamp Luminous Efficiency(lm/w):
100

Packaging & Delivery

Selling Units:
Single item
Single package size:
71X45X21 cm
Single gross weight:
10.0 kg
Package Type:
carton with protetion air bags
Picture Example:
package-img
package-img
Lead Time :
Quantity(Piece) 1 - 1000 >1000
Est. Time(days) 30 To be negotiated
Product Description

1. MAIN APPLICATION

Color temperature 3000-6500K IP66 100lm/w 165W led area work light is mainly application of road and area lighting to highways, urban main roads & branch roads, country roads, factory outdoor roads, residence outdoor roads and etc.



2. DESIGN STANDARD

  • GB 7000.1-2007 Luminaires--Part 1:General requirements and tests
  • GB 7000.5-2005 Safety requirements of luminaires for road and street lighting
  • Q/SG 3-2012 Technical specification of luminaires for road and street lighting
  • GB 17743-2007 Limits and methods of measurement of radio disturbance characteristics of electrical lighting and similar equipment
  • GB 17625.1-2012 Electromagnetic compatibility - limits - limits for harmonic current emissions (equipment input current ≤ 16A per phase)
  • GB/T 18595-2001 Equipment for general lighting purposes--EMC immunity requirements



3. STANDARD CHARACTERS

  • High brightness LEDs, CRI RA>70, 100 to 130lm/w & 2700-10000K selectable
  • Patent modular technology, high thermal aluminium conduct management system ensure temperature rise within 15 degress celsius
  • Industrial grade design, zero pollution, zero glare, even light distribution>0.95
  • Power factor >0.95, total harmonic distortion <10%
  • AC90 to 305V wide application potted dirver with multi protections of short circuit, open circuit, zero load, over load, electron magnetic inteference
  • DC10 to 28V self-adaption when work with solar & wind power system
  • Dual stage built-in surge protector 6KV and 10KV
  • Aesthetical architecturelly design and make up of corrosion free high pressure die cast aluminum with well design of thermal managment system
  • IP66 ingress protection to both optical and control gear compartment
  • Long maintenace free life, 50,000 hours for whole luminare
  • Mannual / Auto intelligent monitoring & dimming control is optional alongwith control system & Zigbee controller



4. STANDARD SPECIFICATIONS

SDL101 General Specification
Order CodeSDL101-55SDL101-110SDL101-165SDL101-220SDL101-275SDL101-330
Operating Voltage(V)90 to 305V AC or 10 to 28V DC
Power Factor≥0.95
Driver Efficiency≥90%
Luminary Power(W)55110165220275330
Luminary Efficiency (lm/W)100100100100100100
Rated Lumen(lm)55001100016500220002750033000
CCT(K)3000/4000/5000/6000/6500
CRIRa≥70
Operating Temperature(℃)-40 to 55
Storage Temperature(℃)-50 to 60
Service Life (H)>50000
Ingress ProtectionIP66
Housing corrosion free high pressure die cast Aluminium with silver colour corrosion resistant coating+PC
Intelligent Dimming ControlOptional
Pole Interface(mm)Φ55 to Φ65
Mounting Angle (°)12.5°
Weight(kg)7.58.51011.51314.5
Dimension(mm)550*400*155590*400*155670*400*155710*400*155780*400*155850*400*155
Our Services





Company Information

Production and Test



Related Product

Project Reference



FAQ

 Q1. How to order a standard luminare?

Please specify order code, correlatted color temperature(CCT).



Q2. What need to be supplied to engineering for a perfect lighting solution?

Please send us parameters of mounting height, road width, mounting distance, even lux for our professional engineering and proposal of luminare with correct light distribution curve to guarantee even road & area distribution



Q3. How to realize intelligent control of each luminare?

One patent zigbee photoelectrical controller can be mouned on each single luminare; wirelessly communicate to field node controller which communicate with central control room(CCR) via Internet.



Q4. If there is deviation to our standard specifications, what else can be customized make to order(MTO)?

a. LED chips: Standard is our self packaged type, but can also customized from Cree who is our strategic partner.

b. Luminous flux: If rated flux is not in standard specification, please contact us for (Make to Order) MTO solution or propose our replacement series.

c. Solar system: solar panel, GEL battery, inverter and charge controller which compose of whole self-support power system can ordered and mounted separately by our Make to order (MTO) engineering. We have a branch company specialize in solar power stations with high technolgy.

d. Mounting pole: We can help design and outsource galvanized and alloy pole from our sub vendors.



Q5. What certificates have been approved for SDL101?

SDL101 is awarded CE, RoHSTUV-LVD, CCC and CQC, please consult us for your specific requirements.



Q6. Do you supply OEM service?

Yes, please consult us for your specific requirements.
