Cool white 10000K smd led 3528 datasheet white

FOB Reference Price:Get Latest Price
$0.01 - $0.03 / Pieces | 1000 Piece/Pieces white led datasheet 3528 (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Type:
SMD LED
Model Number:
HYZM-SMD3528W
Chip Material:
InGaN
Emitting Color:
Cool White
Luminous Intensity:
2000-2200mcd
Luminous Flux(lm):
6~7lm
Optical Attenuation(%):
0.3
Power:
0.06W
Power Dissipation:
0.001
Viewing Angle(°):
120 Degree
Color Rendering Index(Ra):
80
Color Temperature:
2600-20000K
Operating Temperature(℃):
-40 - 85
Storage Temperature(℃):
-40 - 85
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HYZM
Certification:
CE, RoHS
Chip Size:
8*12mil
Chip Brand:
Sanan
Material:
Gold Wire, Copper stand
Voltage:
3.0-3.4V
Current:
20mA
Color tolerance:
<6
Color:
W/R/G/B/Y/Purple/Amber
Package:
2000 Pcs/Anti-static vacuum Bag
Lifespan:
50000 Hours
Warranty:
3 Years
Supply Ability
Supply Ability:
1000000 Piece/Pieces per Day Cool white led 3528
Packaging & Delivery
Packaging Details
2000pcs/reel, each reel Anti-static vacuum Bag
Port
shenzhen
Lead Time :
Shipped in 3 days after payment
Specification

Dimension

Model No.
HYZM-SMD3528W
Power
0.06W
Lumens
White:6~7LM                               Red:2~3LM                               Yellow:2~3LM
Green:2~3LM                             Amber/Gold yellow:5~6LM
Blue:1~2LM                                Purple:30~50mcd
Color Temp
White:2600-20000K                         Red:620~630nm               Yellow:590~600nm
Green:520~530nm                           Blue:460~470nm               Purple:390~400nm
Voltage
W/G/B/Amber/Purple: 3.0~3.4v
Red/Yellow: 2.0~2.4v
Current
20mA
Chip Brand
Sanan
Chip Size
8*12mil,10*10mil,8*15mil etc
Lifespan
50,000 hours
Warranty
3 years
Product Description

Huanyu Dream SMD LED Chip use Gold Wire and Copper Stand only !

Cool white 10000K smd led 3528 datasheet white

We made the LED chip 3528 with gold wire and copper base, naver use alloy wire / Iron base

99.99% gold wires

High quality LED Chip internal electrode wires,
made by gold,gold wire lamp bead brightness
with better stability

Copper base

Copper stand is better to heat dissipation
we use copper base only
100% sure our products quality

Electrical / Optical characteristics 3528 datasheet white

Absolute Maximum Ratings (TA=25ºC)

Item
Symbol
Absolute Maximum Rating
Unit
Forward Current
IF
30
mA
Pulse Forward Current
IFP
150
mA
Reverse Voltage
VR
9
V
Power Dissipation
PD
350
mW
Operating Temperature
Topr
-40ºC To +85ºC
°C
Storage Temperature
Tstg
-40ºC To +85ºC
°C
Soldering Temperature
Tsld
Reflow Soldering: 260ºC
Hand Soldering : 350ºC
for 10sec.
for 3sec.

1/10 Duty Cycle, 0.1 msec Pulse Width.

Initial Electrical/Optical Characteristics (TA=25ºC)  Cool white led 3528 datasheet

Symbol
Item
Units
Min.
Typ.
Max.
Test Conditions
VF
Forward Voltage
V
3.0
3.4
IF=20mA
IR
Reverse Current
uA
-
-
1
VR=5V
Viewing Angle
º
-
120º
-
IF=20mA
ø
Luminous flux
lm
7
8
IF=20mA
TC
Color Temperature
k
2800
3200
IF=20mA
RA
Color Rendering Index
Ra
 70
75
IF=20mA

Cool white 10000K smd led 3528 datasheet white

Huanyu can manufacture the 3528 0.06W,different color such as RGB, White, warm white, Red,Green,Blue,Yellow,UV purple colors single color,and Taiwan Sanan chip,will have the one which you need.
More detail pls kindly contact us

Cautions Cool white 10000K smd led 3528 datasheet white

1)Soldering Conditions

Number of reflow process shall be less than 2 times and cooling process to normal temperature is required between first and Second soldering process.

2)Static Electricity

It is recommended that a wrist band or an anti-electrostatic glove be used when handling the LEDs.All devices, equipment and machinery must be properly grounded.Damaged LEDs will show some unusual characteristics such as the forward voltage becomes lower, or the LEDs do not light at the low current. Criteria : (VF > 2.0V at IF=0.5mA)

3)Moisture Proof Package

It is recommended that moisture proof package be used .

4)Storage

Before opening the package ,The LEDs should be kept at 30°C or less and 70%RH or less. The LEDs should be
used within a year.

5)After opening the package, The LEDs should be soldered within 24 hours (1days) after opening the package.

Application of SMD LED 3528
Indoor ligting: Spot light, Ceiling light bulb
Roadway lighting: Street light, Garden light, Tunnel light
Architectural lighting landscapes, lighting exterior illumination, etc.
Wall lamps, underwater lamps, decorative illumination, and more Underground lamps,
reading lamps, emergency lights, and interior illumination Miner's lamps, flashlights, and car lamps

Main Material 3528 smd led cool white

Color Standard/ Wavelenth

Except the 3528 led, we also supply Samsung5630,SMD5730,SMD2835 ,SMD3014,SMD5050,SMD4014 SMD3030,1W 3W high power etc smd led chip, welcome to sent inquire.
