Corrugated steel storage grain silo 500 tons grain storage steel silo

FOB Reference Price:Get Latest Price
$40,000.00 - $110,000.00 / Sets | 1 Set/Sets steel storage silo (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Capacity:
670CBM
Dimension(L*W*H):
8.3*8.3*13m
Condition:
New
Material:
Steel, Hot-galvanized steel sheets silo
Place of Origin:
Hebei, China (Mainland)
Brand Name:
GOLDRAIN
Model Number:
GR-S500
Weight:
30 ton
Installation Type:
Assembly silo,Hermetic products
Models:
Flat bottom silo and conical bottom silo
Usage:
steel storage silo
Volume:
500 TON
Supply Ability
Supply Ability:
50 Set/Sets per Year steel storage silo
Packaging & Delivery
Packaging Details
container,2*20"
Port
Tianjin port,China
Corrugated steel storage grain silo 500 tons grain storage steel silo
THE ONLY ONE WITH TRADE ASSURANCE USD 200000.00 NOW .

GOLDRAIN--------ODM Gold Supplier on Alibaba !
Trade Assurance with BV Certificate on Alibaba !



We offer silo capacity from 100 ton silo, 200 mt silo, 1000 ton silo, 1500 tons steel silo,

3000 MT Grain Silo to 5,000 ton hot-galvanized steel silo ... according to customers' requirements .

Here i introduce you the 500 MT Silo for your reference :

Product Description

 Silo is Hot-galvanized steel sheets bolted ,  From top to Bottom .



Wall sheets:
Wall Sheets are connected together with high strength bolts to establish the ring of the silos.


wall sheets are in 275gr/m2 standarts .

This difference not only prolongs the life of the coating,but also provides protection against external factors.

What is the processing steps for the steel silo wall sheets ?

Silo each part description :

1. Catwalk on the Silo Top:

Safety constructions are recommended to be used in complete grains storage systems.

These constructions are elevator towers, catwalks and catwalk supports.

All can be produced both painted and galvanised according to customer's request.

2. Steel Storage silo Roof :




Roof is made up of radiated beam, roof cover board, tension ring, ventilator scoop,

roof cap, etc.



The space age construction technology, which is adopted in the design of the silo framework, can ensure the stability of silo under the large span.

There is a guardrail around the silo eaves and there is also a manhole on top of the roof.



3. Silo body :




Inside the silo body ,the column, made by the Z-bar, is used to reinforce the silo body.

It is connected by junction panels.

Also we equip the Level System, Ventilation system, Temperature control system,

Draft fan etc in order to keep the product a good condition inside the grain silo .







4.500 Ton Grain Silo Bottom :

--------Hopper bottom /  Conical bottom :

 Hopper silos lower part has 45° and 60° degree angle and this allows the grain to

flow easily with its own fluidity.



Packaging & Shipping





Our Factory View:





Contact Person:  Candy Liu
                        Skype:  goldrainc
Telephone: 0086-311-68008837
Mobilephone: 0086-18131189696
Fax: 0086-311-68008978
Address: Army Ganxiu House, No.41 Shizhuang Road, Shijiazhuang City, Hebei Province, China
Zip Code: 050000

1. What is the types of this assembly silo?

A. Hopper bottom: Steel cone base:

The capacity is below 800t and the diameter is below 8.5m.

B. Cement cone base / Flat bottom:

The capacity is comparatively big and the diameter is below 12m, its base is general made into   cement cone  base.

2.  what is the zinc coating per sqm available ?

The silo is made of hot-galvanized steel sheet 275g/m2,350 g/m2 and 400g/m2 are options.

3. What is the usage of the fabricated silo ?

The steel silos are widely used in grain storage, animal feed, flour, starch, rice milling   factory, grease  processing, brewing, monosodium glutamate etc.
