Cost-effective factory supply 15 inch monitor square lcd without touch screen for pos customer display terminal system

FOB Reference Price:Get Latest Price
$65.00 - $75.00 / Pieces | 2 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 500 >500
Est. Time(days) 7 Negotiable
Customization:
Customized logo (Min. Order: 5000 Pieces)
Customized packaging (Min. Order: 5000 Pieces)

More

Graphic customization (Min. Order: 5000 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Taiwan
Brand Name:
INNOLUX
Model Number:
G150XNE-L03
Type:
TFT
Display Size:
15 inch
Resolution:
1024(RGB)*768 (XGA)
Display mode:
NPVA, Normally Black, Transmissive
Contrast Ratio:
2000:1
Viewing Angle:
88/88/88/88 (Typ.)(CR≥10) Left / Right / Up / Down
Interface:
20 pins LVDS (1 ch, 6/8-bit) , Connector
Backlight:
WLED , 70K hours , Embedded (LED Driver)
Brightness:
250 nits
Touch panel:
without
Application:
Industrial Application
Supply Ability
Supply Ability:
1000 Piece/Pieces per Week
Packaging & Delivery
Packaging Details
"Quantity: 16 pcs / box;
Weight: 18.0 Kgs;
Box Size: 511*420*360 mm (L*W*H)"
Port
shenzhen/hongkong
Lead Time :
Quantity(Pieces) 1 - 500 >500
Est. Time(days) 7 To be negotiated
Video Description
Product Description

Cost-effective factory supply 15 inch monitor square lcd without touch screen for pos customer display terminal system

Product details


BrandINNOLUX
ModelG150XNE-L03
Diagonal Size15.0 inch
Typea-Si TFT-LCD, LCM
Pixel Format1024(RGB)×768   [XGA]
ConfigurationRGB Vertical Stripe
Active Area304.1(H)×228.1(V) mm
Outline Dim.326.5(H)×253.5(V) ×9.6(D) mm
Bezel Area307.4(H)×231.3(V) mm
TreatmentAntiglare, Hard coating (3H)
Luminance250 cd/m² (Typ.)
Contrast Ratio2000:1 (Typ.) (TM)
View DirectionSymmetry
Response Time16/7 (Typ.)(Tr/Td)
Viewing Angle88/88/88/88 (Typ.)(CR≥10) Left / Right / Up / Down
Operating ModeNPVA, Normally Black, Transmissive
Support Color262K/16.7M   72% (CIE1931)
Light SourceWLED , 70K hours , Embedded (LED Driver)
Weight0.96/1.00Kgs (Typ./Max.)
Designed ForIndustrial Application
Frame Rate60Hz
Touch PanelWithout
Interface Type20 pins   LVDS (1 ch, 6/8-bit) , Connector
Power Supply3.3V (Typ.)
EnvironmentOperating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 70 °C



You may like



BOE 18.5" lcds full viewing angle              BOE 21.5 inch FHD lcds                 Square lcd display panels







About XIANHENGDA

Shenzhen Xianhengda Technology Co., Ltd.

Shenzhen Xianhengda has devoted itself to the manufacturing and development of high-quality products for the Industrial LCD Displays. XIANHENG has become the TOP 10 of the leading industrial display manufacturer in the field of small & medium sized displays.

With more than 5 years experience, Xianhengda became remarkably proficient in complicated order handling, especially on LVHM (Low-Volume/High-Mix) operation business model. This is our most important core competence to fulfill customers’ requirement and expectation.

We provide products and services with excellent cost performance ratio as well as the good logistics support to deliver products and services competitively. As a leader manufacturer in the display module market, Xianhengda will continue to dedicate the research & development, design, of new technology of LCD, TFT, OLED displays and embedded system.

Why choose us

WHY CHOOSE US

Efficient collaboration, fast service and customer first.

Provide professional customized solutions.



Quality certification,

long life.



Located in industrial parks that gather many industrial factories.

If the quantity of order is not very big,we could send them to you by express delivery,such as TNT,DHL,UPS OR EMS etc.

If order is big ,we will advise you use Air Shipping or Sea Shipping through your nominated forwarder agent.Our long-term cooperated agent also available.



Packaging & Shipping

PACKAGE:

Standard export carton packing.

DELIVERY TIME:

3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.


FAQ

FAQ

1. Could I have prices of your products?

Welcome. Pls feel free to send us an email here. You will get our reply in 24 hours

2. Can we print our logo/website/company name on products?

Yes, please advise the size and Pantone Code of the logo.

3. What's the lead time for regular order?

14-21 days for order quantity lower than 5000pc; For more quantity, usually 30 days.

4. Can I get a discount?

Yes, for the order quantity more than 500 pcs, please contact us to get the best price.

5. Do you inspect the finished products?

Yes, each step of production and finished products will be came out inspection by QC department before shipping.

Contact us


CONTACT US

SHENZHEN XIANHENGDA TECHNOLOGY CO., LTD

Web: www.xhpanel.com

E-mail: cmo(at)xianheng99.com

Tel/Whatsapp/Wechat: +86-18588855562

Add:

 Room 402, 1st building, Diaoyutai industrial park, Gaofeng community, Dalang subdistrict, Longhua, Shenzhen, China(Mainland)
