DC TIG 315A welder machine

FOB Reference Price:Get Latest Price
$70.00 - $130.00 / Piece | 1 Piece/Pieces (Min. Order)
Model Number:
TIG-315
Customization:
Customized logo (Min. Order: 1000 Pieces)
Customized packaging (Min. Order: 1000 Pieces)

More

Graphic customization (Min. Order: 1000 Pieces) Less
Report Suspicious Activity
Overview
Quick Details
Warranty:
1 year
After-sales Service Provided:
Online support, Video technical support, Engineers available to service machinery overseas
Place of Origin:
Guangdong, China
Brand Name:
DELIXI
Pulse Frequency:
50/60 HZ
Motor Type:
DC MOTOR
Rated Duty Cycle:
60%
Material / Metal Processed:
Carbon Steel, Stainless Steel, Low alloy steel
Condition:
New
Certification:
CE CCC
Dimensions:
585*310*415
Pilot Arc Current:
20-315A
Usage:
Welding
Voltage:
380V±15%
Arc Current:
315A
Rated Input Voltage:
1 ph AC380V±15%
Max. Load Power Capacity:
13.4 KVA
Output Polarity:
DC TIG
Rated Duty Cycle @40°C (TIG):
300
Applicable Industries:
Manufacturing Plant, Advertising Company
Frequency(HZ):
50/60
Rated input power(KVA):
13.4
Output current(A):
20-315
Current at 60% duty cycle(A):
300
Current at 100% duty cycle(A):
233
No-load voltage(V):
60
Efficiency(%):
85
Protection class:
IP21S
Weight(KG):
17
Power(W):
13.4KVA
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month welder machine
Packaging & Delivery
Packaging Details
welder machine 1pcs in a carton
Port
Ningbo shanghai ,Guangzhou
Product Description

 DELIXI DC Inverter 380V Triple Phase TIG 315 Welding Machine



Input voltage380V±15%1. TIG torch with 5m cable;
2. Earth clamp with 2m cable;
Frequency(HZ)50HZ
Rated input power(KVA)13.4
Output current(A)20-315
Current at 60% duty cycle(A)300
Current at 100% duty cycle(A)233
No-load voltage(V)60
Efficiency(%)85
Power factor0.93
Insulation classF
Protection classIP21S
Usable electrode(mm)2.5-3.5
Weight(KG)17
Measurement(MM)585*310*415



Features

1. Advanced IGBT inverter technology, low consumption and high output

2. Adopt high frequency and pulse to ensure 100% arc starting

3.Digital control improves the reliability

4.Sufficient welding current, high cost performance

5. Effective welding process with 2T/4T selections

6. Both TIG and MMA functions

7. Wide range of power grid adaptation(AC323-437V), high duty cycle, suitable for factory to work continually

8. High no load voltage, smooth and stable welding performance with minimal spatter

9. High speed fan brings effective dissipation and high duty cycle

10. Over-current, over-voltage and over-heat protection
