DC-WP145B ATC 9KW 24000rmp ISO30 Wood Engraving CNC machine Spindle motor

Feedback Ratings
  • 1-4 Sets
    US $1599.00
  • 5-9 Sets
    US $1500.00
  • 10-99 Sets
    US $1400.00
  • >=100 Sets
    US $999.00
Quantity:
- + Sets available
0piecesselected, US $in total
View Details
Shipping fee:
Depends on the order quantity.
Lead Time:
3 day(s) after payment received
Contact Supplier
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
DECI
Model Number:
DC-WP145B
Application:
truning, milling, drilling, boring, for CNC machine to truning, milling , engraving
Maximum Torque:
7.16nm
Drive:
Motor
Operating Speed:
24000RPM/Min
Power:
9.0kw
Precision:
0.002mm-0.01mm
Max Frequency:
800Hz
Max Speed::
24000Rpm
Power::
380v(3~)
Max currency::
17A
Machining material::
all kinds of steels, and some aluminum
Certificate:
ISO9001:2008

Packaging & Delivery

Selling Units:
Single item
Single package size:
35X35X55 cm
Single gross weight:
30.0 kg
Package Type:
FOAM PACKING WITH CARTON BOX, OVERSEAS WOOD PALLENT TO PROTECT
Lead Time :
Quantity(Set) 1 - 1 >1
Est. Time(day) 3 To be negotiated
Product Description



ATC Square Engraving CNC machine Spindle motor new design, high precision .



ATC Square Engraving CNC machine Spindle motor is to meet high rapid wood, plastic engraving developing and requirements . With loss cost and high precision ,the square engraving spindle motor widely applied to CNC machines with engraving function.



 Advance/Features :

· Reasonable structure desgin ,simple and compact configuration ,easy to take apart.

· High precision.high inflexibility ,high efficiency,long operation life.

· With high grade size .shape,.position precision,and quality of surface .

· Enough abrasive resistance ,vibration resistance,stable size.

· Work stable ,low noise,enough fatigue strength

· Special design for wood engraving.

· Easy to install and less maintance.







Usage of spindle motor :



Widely used in CNC drilling and milling equipment, precision carving, engraving and milling machinery bar, computer gongs precision grinding machines, CD profiling batch flower machine, optical processing equipment, watches and equipment.





Specificiations

               EEJA DC-WP145B  Specification

 Parameters
 Motor Power: 9.0KW Rated voltage: 380v(3~)
 Max rotate speed : 24000Rpm/min Max currency: 17A
 Max Frequency: 800Hz Torque: 7.16NM
Specification
 Cone surface spring at shaft end: ≤0.001mmTooling Releasing  Air curtain: 5.6-6.0 Kgf/cm²
 Tooling Exchange Method: ATCAir curtain pressure at front end: 2.5~3.0 Kgf/cm²
 Tooling Pulling Force: ≥2900Tooling Back Air Pressure: -
 Tooling Connection: ISO30Cooling: Water air cooling optional
 Encoder: Sine-Cosine 1VPP(Optional)Coolant Pressure: 2.5~3.0 Kgf/cm²
 Approach Switch:PNP OnBearing Lubrication Method: Grease
Balance Level : G1Tooling Instalation Method:T slot
Vibration Value: ≤0.8Weight:29.6kg
 Structure
 Motor property curves
 Applications
DC-WP145B application .jpg
Why Choose Us

                        Why choose EEJA

100% REFUND IF SPINDLE
MOTOR NOT WORK

ALIBABA TRADE ASSURANCE
AVAILABLE
EUROPE QUALITY
CHINA PRICE
Studer,TAKISAWA,DOOSAN,
SUNNEN CNC machines,
precision ±0.002mm
professional team provide
one stop solution
help you reduce time
All main parts come
from famous suppliers
FAG,GMN,SKF
TOP 500 company supplier,
strong quality control
good cooperation service sense
 EEJA DECI spindle motor Properties spindle properties.jpg

 EEJA Patents & Certifications certification.jpg

Company Information

                      EEJA  Company Information

Factory Profile
our company_spindle.jpg
Machinery In EEJA
Machinery in our faclity.jpg
Contact With us

                         Contact With EEJA

Want to locate EEJA ?

NO.1/2 LianHe Rood ,Luo Cun town,
Nanhai District, Foshan City, guangDong,china

  • Tel: +86 20 87791732
  • Mobile/Whatsapp/Wechat: +86 13415719773
  • Name: Eliza,Fan
  • Email:  sales3(@)eejaxt.com
EEJA DECI Spindle

         EEJA  DECI SPINDLE MOTOR LIST

Metal cut Spindle motor
 Maximum PowerOperating Speed Max FrequencyTooling Exchange MethodTooling ConnectionMaximum TorqueRated voltageMax currencyCooling MethodWeightRemarks
DC-1036A5.5KW36000Rmp1200HzATCISO25-ER203.98 N.M380(3~)V/AC21 AWater Cooling26KG
DC-1036A-HSK32E5.5KW36000Rmp1200HzATCHSK32E-ER203.98 N.M380(3~)V/AC21 AWater Cooling26KG
DC-1230A7.5KW30000Rmp1000HzATCBT305.73 N.M380(3~)V/AC25 AWater Cooling26KG
DC-1230A-HSK40E7.5KW30000Rmp1000HzATCHSK40E-ER255.73 N.M380(3~)V/AC25 AWater Cooling26KG
Grinding CNC machine Spindle motor
 Maximum PowerOperating Speed Max FrequencyTooling Exchange MethodTooling ConnectionMaximum TorqueRated voltageMax currencyCooling MethodWeightRemarks
DC-100MA2.5KW60000Rmp1000HzHTCM8X10.56 N.M350(3~)V/AC11 AWater Cooling9.3KG
DC-120MA5.5KW24000Rmp400HzHTCM16X1.52.19 N.M350(3~)V/AC18 AWater Cooling18.5KG
Engraving CNC machine spindle motor
 Maximum PowerOperating Speed Max FrequencyTooling Exchange MethodTooling ConnectionMaximum TorqueRated voltageMax currencyCooling MethodWeightRemarks
DC-0840A3.7 KW40000Rmp1333HzATCISO20-ER161.19 N.M380(3~)V/AC17 AWater Cooling7.8KG
DC-0840A-HSK25E3.7 KW40000Rmp1333HzATCHSK25E1.19 N.M380(3~)V/AC17 AWater Cooling7.8KG
DC-80A3.7 KW40000Rmp1333HzATCφ10 CHUCK1.19 N.M380(3~)V/AC17 AWater Cooling7.8KG
DC-62F

1.8KW/

1.5K

60000Rmp1000HzATCφ3-φ6 Chuck0.28 N.M200(3~)V/AC10 AWater Cooling3.0 KGTool path smaller
DC-60B

1.8KW/

1.5K

60000Rmp1000HzATCφ3-φ6 Chuck0.28 N.M200(3~)V/AC10 AWater Cooling3.0 KG
DC-60D11.8KW/1.5K60000Rmp1000HzATCER110.28 N.M200(3~)V/AC10 AWater Cooling3.0 KG
Square Engraving CNC machine Spindle motor
 Maximum PowerOperating Speed Max FrequencyTooling Exchange MethodTooling ConnectionMaximum TorqueRated voltageMax currencyCooling MethodWeightRemarks
DC-WP145A9.0 KW24000Rmp800HzATCISO307.16 N.M380(3~)V/AC17 AWater/Air23KG
DC-WP145AH9.0 KW24000Rmp800HzATCER327.16 N.M380(3~)V/AC17 AWater/Air21.8KG
DC-WP145B9.0 KW24000Rmp800HzATCISO307.16 N.M380(3~)V/AC17 AWater/Air21.8KGBLOWING FUNCTION
DC-WP145B-HSK63F12 KW24000Rmp800HzATCHSK63F9.55 N.M380(3~)V/AC23 AWater/Air28.2KGBLOWING FUNCTION
Dental Engraving Spindle motor
 Maximum PowerOperating Speed Max FrequencyTooling Exchange MethodTooling ConnectionMaximum TorqueRated voltageMax currencyCooling MethodWeightRemarks
DC-38A0.5KW40000Rmp666HzATCφ4 CHUCK0.12 N.M66.7(3~)V/AC8.0 AAir Cooling1.9KG
Direct spindle
 O.DOperating Speed Bearing Tooling Exchange MethodTooling Connectionaxial rigidityradial stiffness Cooling MethodWeightRemarks
DC-1024ZAφ100mm24000Rmp4*7008ATCBT30≥0.06 N/m≥0.0075N/mmWater Cooling14.5kg
polishing Spindle motor
 Maximum PowerOperating Speed Max FrequencyTooling Exchange MethodTooling ConnectionMaximum TorqueRated voltageMax currencyCooling MethodWeightRemarks
DC-100PG11.3KW6000Rmp200HzHTCFLANGE2 N.M380(3~)V/AC5AWater Cooling3.4KGSINGLE HEAD
DC-100PG21.3KW200Hz5AHTCFLANGE2 N.M380(3~)V/AC5AWater Cooling3.9KG
