DC6-36V Angular colmn type SN04-Y AC two wires 90-250V NO Embedded metal detection inductive approach switch sensor

FOB Reference Price:Get Latest Price
  • 50 - 199 Pieces
    $4.40
  • >=200 Pieces
    $4.20
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang China (Mainland)
Brand Name:
CHEN
Model Number:
SN04-Y
Usage:
Position Sensor
Theory:
Inductance Sensor
Output:
Switching Transducer
Working power supply:
DC three-wire type DC6-36V
Detection distance:
5mm±10% (To A3 iron as the standard)
Material of the check surface:
Heat resistant ABS
Detection of objects:
Iron, copper, steel; aluminum, nickel and other metal objects
Output current:
200mA
Object material:
brass chrome plated
Protection function:
polarity protection, surge absorption, short circuit protection
Tube buck:
≤2.5V
Protection class:
IP67
Current consumption:
8mA/12V 15mA/24V
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
carton
Port
Ningbo or Shanghai

DC6-36V Angular colmn type SN04-Y AC two wires 90-250V NO Embedded metal detection inductive approach switch sensor

Product Description






Product name

Output form

Non-embedded

Embedded







Inductive proximity

switch



DC three wires 6-36V

  NPN type

NO



SN04-N

NC



SN04-N2

PNP type

NO





NC



SN04-P

DC two wires6-36V

NO



SN04-P2

NC





AC two wires90-250V

NO

SN04-Y

SN04-D

NC
