Diatomite Micro Powder Packaging Machine

FOB Reference Price:Get Latest Price
$6,700.00 - $10,500.00 / Set | 1 Set/Sets (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Application:
Machinery & Hardware, Powder Packaging
Packaging Material:
Powder
Type:
Other, Valve Type
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
Clirik
Model Number:
CKF-86CH/159CH/200C/1000C
Power:
4KW
Voltage:
380V, 50HZ
Weight:
420KG
Automatic Grade:
Automatic
Certification:
CE&ISO
Packaging Type:
Bags
Driven Type:
Electric
Dimension(L*W*H):
800x1400x1850 mm
Bag weight:
3-50KG/Bag
Accuracy:
±0.2-0.5%
Filling Speed:
3-5 Bags/min, (25KG/Bag)
Air consumption:
P≥0.6Mpa, Q≥0.4m3/min
Supplier:
Shanghai Factory
Material:
Stainless Steel
Speed:
Variable Automaticly
Certificates:
CE&ISO9001:2008
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
Non-fumigation Wooden Box
Port
Shanghai
Lead Time :
15 Days after Receiving the Deposit

Product Description
Model   CKF-86CH  CKF-159CH  CKC-200C  CKC-1000C
Bag Weight(kg/bag) 1-60  3-50  1-50 1-2000
Packing Accuracy  ±0.1~0.3%    ±0.2~0.5%   ±0.2~0.5%    ±0.2~0.5%
Packing Speed  3-5  Bags/min(25kg)   3-5  Bags/min(25kg)   3~5 Bags/min(25kg)   1-2000KG
Power  8KW(380V, 50HZ)  4KW(380V, 50HZ)   3Kw(380V, 50Hz)   3Kw(380V, 50Hz)
Air ConsumptionP0.6MPa;Q≥0.4m³/min  P0.6MPa;Q≥0.4m³/min

P0.6MPa;Q≥0.4m³/min

  P0.6MPa;Q≥0.4m³/min
Weight  900KG   420KG   550KG   850KG
Dimension  850 × 1500× 2155mm   800x1400x1850 mm    3300× 2000 × 2700mm   1800x1800x2500mm

Micro powder packing machine usually has two types: valve type and opening type, it is adopted with technology of

electronically automatic measurement, variable-feed and frequency-converted function; it can be designed to meet

customer’s specific requirements according to raw materials characteristics, fineness and flow ability etc. The

packing machine is widely used in calcite (GCC), black carbon, talc, feldspar, kaolin, bentonite, AL(OH)3, carborundum,

quartz, barite, food etc.

CKC-200C


Packaging & Shipping

Packaging: Conventional Packaging suitable for long distance transportation.

Shipping: 15 days.


Our Services

1.one year guarantee for whole machine except for wear parts;

2.24 hours technical support by email;

3.calling service;

4.user manual available.




Company Information

222

Certificates


FAQ

1. Are you a trading company or a factory?

---We are factory sell directly, and welcome to visit our factory in Pudong New District, Shanghai, China.

2. Can you guarantee the quality of your products?

---We have passed CE&ISO9001:2008, and our packing machines have been sent to Eastern Europe, Middle East,            Africa, South Asia, Southeast Asia, Oceania, America, etc.

3.How many years have you been manufacturing the machine?

---Since the foudation of our company, we have been manufacturing the machine, which updated many times, now the       machine runs stable and of high quality.
