Different Models of aluminum Half metal Ball

FOB Reference Price:Get Latest Price
$0.70 - $1.00 / Kilograms | 500 Kilogram/Kilograms (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shandong, China (Mainland)
Brand Name:
Taian zhong rui
Model Number:
3.96mm 4.76mm 5mm 6mm 6.35mm
Material:
Stainless Steel
Product Name:
High Quality SGS Solid Steel Ball Metal 3.96mm 4.76mm 5mm 6mm 6.35mm
solid steel ball Grade:
G40,G80,G100,G200,G500,G1000,G2000
SizeTolerance::
+/- 0.001mm-0.02mm
solid steel ball Size:
1/16''-2 Inch
solid steel ball Application:
Drawer Slide,bearing,caster,bicycle etc
Hardness::
Hardness: 60 - 90 HRB
solid steel ball Surface:
High Polished,Mirror shining
solid steel ball Standard:
ANSI/ASME Std. 10A-2001
Certification:
ISO9001:2008/TS-16949:2009/ISO14001
Application::
Precision machinery , bearings ect,.
Supply Ability
Supply Ability:
10 Ton/Tons per Day
Packaging & Delivery
Packaging Details
1,10kg/box packing,then 100 boxes in one wooden case
2,25kg polybag then in carton packing
3.250kg steel drum then 4 drums in one steel pallet pcking
4,5kg/box,then 100 boxes in one wooden case packing
Port
Qingdao/Tianjin
Lead Time :
10 days per container
Product Description

Different Models of aluminum Half metal Ball

Golden steel ball supplier on Alibaba

Specification

Basic Information
MaterialLow carbon steel – 1010/1015, W.10301, C10/C15
Metric Size0.6mm - 60mm
Inch Size1/64" - 4"
GradeISO 3290 G100 G200 G500 G1000 G1000
Chemical AnalysisC=0.10-0.20%, Mn=0.60-0.90%, Si=0.10-0.20%, S=max 0.50%, P=max 0.040%



Mechanical Properties


Hardness for low carbon steel balls, as measured on the balls surface is Rockwell "C" 60 (minimum) and subject to correction factors. See chart for minimum case depth.


Case depth reported is the effective case measured to the HRC 50 position (ref. ABMA Std. 10-83). Minimum thickness considerations apply to case depth.



Application



Soft: Caddies, wrought iron work, curtain mechanisms, steel shots, munitions, stirrers and mixers in not aggressive environments, welding appliances.



Hardened: Furniture rails and rollers, drawers and rolling bearings, locks, oilers and greasers, skates, caddies, toys, belt and roller conveyors, tumble finishing.




OEM

Distinctively Shaped Ball: We offer a variety of flat, diagonally cut, cone and pin shaped balls that are typically used as hardened polishing and shaping tools.


 For example, the diagonally cut and shaped balls can be used to polish surfaces with sharp angles.



Flat balls are typically used to polish uniformly shaped surfaces such as soins. Sizes and materials can be made available to suit your needs.

Contact us to find the product that's just right for you.



Drilled Ball: Zhongrui offers a full range of sizes, hole depths (including thru-

hole), diameters and materials.

Typical applications include body jewelry, earring posts, rings, seal slides, valves, and automotive engine push rods.



Plated Ball: Platings are used to enhance the physical properties of precision balls. These may include added hardness (titanium nitride),

corrosion resistance (molybdenum disulfide), noise supression (rubber), and

electrical characteristics (gold). zhongrui  offers a myriad of plating to meet your needs.



Hollow Ball: Hollow balls are typically used for weight sensitive applications such as aircraft ball transfer units, liquid float systems, and custom ball valve

We provide 201, 304, 316 stainless steel hollow balls in a variety of sizes


Company Introduction

Company Brief Introdcution:

-- Taian Zhongrui Steel Ball !!



  • Since year 2000, more than 15 years experience and specialized in steel balls and ball related products.

  • High precision instruments and technical staffs.

  • Offer the good quality service and product with short delivery times.

  • Specailized in Carbon Steel Ball!!!!!!!!!!!!!!!!!








Quality&Report

Quality Assurance



After precision washing, oiling & before packing sample balls from the batch are sent for final audit to check for surface roughness, roundness, waviness, lot size variation and hardness in a sophisticated laboratory, according to specified control plans and dock audit procedures. Once all requirements are met, a test certificate is then prepared for the customer. Our sophisticated laboratory is equipped with high precision, worldwide respected machines and equipment and is managed by properly trained and qualified personnel.

Our Advantages

 1) Professional Manufacturer of Carbon Steel Ball
2) Easy Storage
3) Factory Price & Best Quality
4) Accept Customized Order
5) Fast Delivery
6) OEM Service
7) Emergency Stocks
8) We promise all your enquiries and messages will get our reply within 12 hours
9)  High polished, high precision, easy storage
10) Anti-rust Way: Provide dry packaging & slushing oil packaging.
11)  In the process of shipping, we use anti-rust oil or VCR paper to prevent the balls rust















Packaging & Shipping

PACKAGE:

Package

1. pp bag + carton
2. pp bag + carton + woven bag
3. pp bag + woven bag
Note: package can be customized

DELIVERY TIME:

3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.

Production Processing Line

HEADING


Ball blanks are cold or hot headed from rolls of wire or bar stock depending on their size and the material. The heading machine cuts off a short cylinder of the material and a moving die with a concave spherical cup drives the cylinder into a matching cup in a fixed die. The result is a spherical shape which is the ball blank.



FLASHING



The flashing operation removes the slight belt and small protrusions left on the surface faces by rolling them between the two hard alloy plates under high pressure.



HEAT TREATMENT



The balls are hardened, if required, by heating them to a high temperature (over 1500 degrees Fahrenheit) in an atmospherically controlled furnace and then quenching them into a liquid bath. They are then tempered to reduce their brittleness by heating them to a low temperature (around 325 Fahrenheit). Samples are checked for hardness.  The grain size and metallurgical structure are inspected under a high power microscope.000



GRINDING



The hardened balls are precision ground by rolling them between the faces of a fixed iron plate and a very hard fine-grit grinding wheel.



LAPPING/POLISHING


The next step is the lapping operation.  The hardened ground balls are rolled between two cast iron plates.  One plate is fixed while the other is rotated at a very low speed.  The real secret of the extreme quality of precision balls happens here. At this stage the sphericity and size have been established and are carefully inspected by ABMA customer requirements.

The final production operation is polishing which adds the shinny luster to the finished ball. The balls are then inspected visually and/or Aviko inspected.
